Page 1: Installation Guide
Peninsula Phone S eries Installation Guide Models: Analog cordless handset - HSH801 Analog cordless charging base - HSH802 Analog cordless 2-line telephone base - HSH803... -
Page 2: Important Safety Instructions
21. CAUTION: Keep small metallic objects such as pins and staples away from the handset receiver. 22. CAUTION: There may be a risk of explosion if a wrong type of handset battery is used (HSH801). Use only the supplied rechargeable battery or replacement battery pack (BT198555/BT298555). - Page 3 Installation Cordless handset - HSH801 Handset battery installation Push the hole at the back of the handset using a pen, then slide the battery compartment outwards. Push to unlock Insert the small tabs of the battery into the slots inside the battery compartment. Make sure the metallic contact is correctly oriented as shown below.
- Page 4 Cordless charging base - HSH802 Charging base installation The charging stand is designed for desktop use. Install the charging stand as shown below. Line and power from wall Charging base Plug one end of a RJ45 line cord to the power jack of the charging base.
- Page 5 Cordless 2-line telephone base - HSH803 T elephone base installaion The telephone base is designed for desktop use. Install the telephone base as shown below. Plug one end of a RJ45 line cord to L1+L2 jack and plug the other Plug on end of the RJ14 cord end of a RJ45 line cord to line to UART jack and the plug the...
- Page 6 Cordless 2-line telephone base - HSH803 T elephone base installation The telephone base can be installed to the wall. Install the telephone base as shown below.
- Page 7 FCC, ACTA and IC regulations FCC Part 15 This equipment has been tested and found to comply with the requirements for a Class B digital device under Part 15 of the Federal Communications Commission (FCC) rules. These requirements are intended to provide reasonable protection against harmful interference in a residential installation.
- Page 8 A member of THE VTECH GROUP OF COMPANIES. Distributed in the U.S.A. by VTech Communications, Inc., Beaverton, Oregon 97008. Distributed in Canada by VTech Technologies Canada Ltd., Richmond, B.C. V6W 1L5. VTech is the registered trademark of VTech Holdings Limited.
- Page 9 The Peninsula DECT Phone (with Touch Screen) Function Flow...
- Page 10 Home Screens Telephone Call, Hotel Services, Restaurants & Bars, Privacy & Language Setting Remark: On the HOME screen there are include : • Room No (programmed) • Hotel Tel No (preset) • Room Fax No (interface from Opera via TC3 / ESD) *for the room is not check in the Room Fax No will displayed General Fax No. Screen Attributes: The touch screen will dim out every 3 minutes for each following stages: From 100% 50% From 50% 25% From 25% OFF *take 9 minutes before the screen completely go OFF either on the docking station or not. The Dect Phone have no movement / proximity sensor, however when the Dect Phone pull out from the docking the screen will turn 100% on. *But if the Dect Phone screen off and not plug into the docking station, the guests need to press ...
- Page 11 Telephone Call (Room to Room via Short‐Cut Key) Remark: The Dect Phone will automatically add prefix for the following telephone call: • Room to Room • Local Call • International Call • VOIP The guest can delete the phone number if made a mistake, but the prefix cannot be “deleted”. Phone line only occupied when the guest press the green “CALL” button. *Voice Mail will call out automatically...
- Page 12 Telephone Call (International Call via Short‐Cut Key) Remark: The Dect Phone will automatically add prefix for International Call, same for Local Call, VOIP. Guest can delete the phone number if made a typo, however the prefix cannot be “deleted”. Again phone line only occupied when the guest press the green “CALL” button except Voice Mail.
- Page 13 Telephone Call (Make phone call via keypad) Remark: The guests can also make phone call via select the keypad directly, no prefix will be added, and no phone line will occupy until guest press the green “CALL” button.
- Page 14 Telephone Call (Make phone call via green “Call” Button with Dial Tone) Remark: The guests can make phone call by press the green “CALL” button, at the same time the line will be occupied and the phone number cannot delete. It will be the same if the guest press the “Speaker” hard‐key to make telephone call, the line will be occupied too.
- Page 15 Hotel Services (example: make phone call to operator) Remark: All Hotel Services calls are pre‐set and it will automatically call out and connect. The guest is not request to press the green “call” button. Display Sequence: confirmed by PHK • Bell Service • Concierge • Housekeeping • Front Desk • Room Service • Operator • Transportation • Laundry • The Peninsula Spa...
- Page 16 Restaurants & Bars (example: make a phone call to Gaddi’s) Remark: All Restaurants & Bars calls are pre‐set and it will automatically call out and connect. The guest is request to press the green “call” button. Display Sequence: confirmed by PHK •Felix •Gaddi's •Chesa •The Verandah •Spring Moon •Imasa •The Lobby •The Bar •Salon de Ning...
- Page 17 Phone Privacy (Block & Unblock) Remark: Guest can enable Phone Privacy, a confirmation message will prompt to the guest. When it is confirmed , an “Phone Privacy Enabled” will display on the screen until it release… also for release the privacy another message will prompt to the guest to unblock the calls. ...
- Page 18 Mute & Hold Remark: For "MUTE“ & “HOLD” feature enabled, the screen bottom menu will change the color, means the function active, press the menu again will resume.
- Page 19 Language Selection (English, Traditional Chinese, Simplified Chinese, Japanese & French for PHK) Remark: Guest can either press the screen / hard‐key to change the phone language. *For PHK the languages available to select are: • English • Traditional Chinese • Simplified Chinese • Japanese & • French *Feedback from Directors review to include the “Flag” icon in case some guests cannot read the language on default screen. *HSH standard languages total are 11 and they include: • English • Traditional Chinese • Simplified Chinese • Japanese • French • Russian • Korean • German •...
- Page 20 New Voice Mail (with voice mail instructions) Remark: For new voice mail, the voice mail hard‐key will be changed to red color & flash. The guest can press "Voice Mail" hard‐key, it will call voice mail box directly. Once the call is connected, the voice mail instruction will show on the screen.
- Page 21 Volume Control (Ringer & Speaker) Remark: The volume control key will control the volume to BOTH Phone Ringer & Phone Speaker. Also an animate icons display on the phone status bar. There are 4 levels of volume control, 100%, 75%, 50% & 25%. *it will never go silence *next time when the guest change the volume Control the Dect Phone will change base on the last volume level setting...
- Page 22 Incoming Call (Room Audio will auto‐mute and resume when call finish) Remark: For ALL incoming call, where the Room Audio is on, ESD systems will automatically MUTE the room audio, when the call finish the Room Audio will be resumed. *also in a phone conversation when the guest place the Dect Phone back to Docking Station the Speaker will active automatically.
- Page 23 Conference Call Remark: Conference call to be initiated from the same hand‐set, one line must be occupied. The guest need to “Hold” the current line then select the “New Call” to start another call. At this time the L1 on the status bar require to be FLASH as indicated is on‐hold, the new call can be dialed via the quick key / key pad. When the other line are connected the guest to press “Conference” to merge two calls. Together. *Guest also able to toggle between “Hold” between Line 1 and Line 2 but the held line the L? indicator to be FLASH…...
- Page 24 Join Line (from another hand set) hand set Other hand set(s) Remark: When one phone line is in used, the another hand‐ set can join the same call by press the green “call” button automatically. *If the guest want to make another Telephone Phone call who need to either via Quick‐Keys or Keypad.
- Page 25 Get Line 2 with Line 1 in use (from another hand set) Other hand set(s) Other hand set(s) hand set hand set Remark: When one phone line is in used, the another hand‐set can make phone call by press the “New Call” button. * The guests can also make phone call via select the keypad directly, no prefix will be added, and no phone line will occupy until guest press the green “CALL” button.
- Page 26 All Lines Occupied (the other hand sets not able to call out) Remark: When both phone lines are in used, the other hand‐sets cannot make any phone call, except the Phone Privacy setting or change Language. Also a message will be promoted to the guest saying “All lines are in used. Please try again later.”...
