Summary of Contents for Technicolor DWA1230
- Page 1 DWA1230 Quick Setup Guide...
-
Page 2: Before You Start
1. Before you start Carefully read the Safety Instructions and Regulatory Notices document included in your package before continuing with the installation of your DWA1230. 2. Check the content of your package Besides this Quick Setup Guide, your package contains the following items:... - Page 3 3. Connect the DWA1230 to the Broadband service DSL2 DSL1 1 Take both DSL cables. 2 Plug one DSL cable into the DSL 1 port and plug the other one in the DSL2 port. 3 Plug the other end of both DSL cables into your telephone wall sockets.
- Page 4 DWA1230. 3 Connect the other end of the Ethernet cable to your device. 4 Connect your other Ethernet devices. 5 We recommend you to first configure the DWA1230 (see “7. Configure your DWA1230 to your needs (optional)” on page 6) before connecting your “5.2.
-
Page 5: Connect Your Wireless Devices
5 After maximum two minutes, the WPS LED will be in either of the following states: • Solid green: the registration was successful. • Blinking red: the DWA1230 could not find your wireless device. Try again or connect your wireless devices manually. • Manually: Configure your wireless device with the Network Name and Wireless Key printed on the bottom label of your DWA1230. - Page 6 DWA1230. 3 Connect the other end of the coaxial cable to the coaxial wall jack or splitter. 6. Check your Internet connection If the Internet (@) LED on the front panel of your DWA1230 is: Green • then your Internet connection is already configured and ready for use. All devices that are connected to the DWA1230 can now access the Internet.
- Page 7 DWA1230 (either wired or wirelessly). Browse to the Admin Settings address. 3 The DWA1230 user interface appears. By default, you are logged in as guest. This means that some items are hidden. To view all items, click Sign In and enter the Admin User Name as user name and the Admin Password as password.
- Page 8 *DSL37756460* DSL37756460 TECHNICOLOR 1-5, rue Jeanne d’ A rc Copyright 2017 Technicolor. All rights reserved. DMS3-QIG-25-477 v1.0. 92130 Issy-les-Moulineaux All tradenames referenced are service marks, trademarks, or registered France trademarks of their respective companies. Specifications subject to change www.technicolor.com without notice.
