Protimeter Hygromaster2 Instruction Manual
2. Safety Considerations (cont.)
•
Use only laser pointers meeting the following criteria:
•
Labeled with FDA certification stating "DANGER: Laser Radiation"
for Class 3R lasers or "CAUTION: Laser Radiation" for Class 2 lasers.
•
Classified as Class 2 or 3R according to the label. Do not use Class
3b or Class 4 products.
•
Operates at a wavelength between 630 nm and 680 nm.
•
Has a maximum

3. Product Components and Accessories

The Hygromaster2 instrument measures air temperature, relative humidity
and surface temperature. To measure all the above mentioned parameters,
Hygromaster2 uses different sensors, along with a variety of accessories for
convenient measurements. The following external connectors are found on
the instrument (see Figure1 on page 3):
A - This edge connection socket is for use with a Hygrostick
Short Quikstick probe.
B - This jack connection socket is for use with the Direct Contact Surface
Temperature Sensor.
C - This USB socket is for connection to a PC when using the optional
Hygromaster2 logging software.
2
output less than 0.4 mW, the lower the better.
, Quikstick or
®
INS7750 Rev. A
