●POLY (Controller number 127)
Status 2nd byte
BnH 7FH
n = MIDI channel number:
* The same processing will be carried out as when All Notes Off is received.

■System Realtime Message

●Timing Clock
●Active Sensing
Status
FEH
* When Active Sensing is received, the unit will begin monitoring the intervals of all
further messages. While monitoring, if the interval between messages exceeds 420 ms,
the same processing will be carried out as when All Sounds Off, All Notes Off and Reset
All Controllers are received, and message interval monitoring will be halted.

■System Exclusive Message

Status Data byte
F0H iiH, ddH, ......,eeH
F0H: System Exclusive Message status
ii = ID number: an ID number (manufacturer ID) to indicate the manufacturer whose
Exclusive message this is. Roland's manufacturer ID is 41H.
ID numbers 7EH and 7FH are extensions of the MIDI standard;
Universal Non-realtime Messages (7EH) and Universal Realtime
Messages (7FH).
dd,...,ee = data: 00H - 7FH (0 - 127)
F7H: EOX (End Of Exclusive)
Of the System Exclusive messages received by this device, the Universal Non-realtime
messages and the Universal Realtime messages and the Data Request (RQ1) messages and
the Data Set (DT1) messages will be set automatically.
●Universal Non-realtime System Exclusive Messages
❍Identity Request Message
Status Data byte
F0H 7EH, dev, 06H, 01H
Byte Explanation
F0H Exclusive status
7EH ID number (Universal Non-realtime Message)
dev Device ID (dev: 10H - 1FH, 7FH, the initial value is 10H (17))
06H Sub ID#1 (General Information)
01H Sub ID#2 (Identity Request)
F7H EOX (End Of Exclusive)
* When this message is received, Identity Reply message (p. 7) will be transmitted.
❍GM1 System On
Status Data byte
F0H 7EH, 7FH, 09H, 01H
Byte Explanation
F0H Exclusive status
7EH ID number (Universal Non-realtime Message)
7FH Device ID (Broadcast)
09H Sub ID#1 (General MIDI Message)
01H Sub ID#2 (General MIDI 1 On)
F7H EOX (End Of Exclusive)
* Not received when the Rx GM/GM2 System On parameter (EDIT: System: Rx GM/GM2
System ON) is OFF.
3rd byte
00H
0H - FH (ch.1 - 16)
Status
F7H
Status
F7H
Status
F7H
❍GM2 System On
Status Data byte
F0H 7EH 7FH 09H 03H
Byte Explanation
F0H Exclusive status
7EH ID number (Universal Non-realtime Message)
7FH Device ID (Broadcast)
09H Sub ID#1 (General MIDI Message)
03H Sub ID#2 (General MIDI 2 On)
F7H EOX (End Of Exclusive)
* Not received when the Rx GM/GM2 System On parameter (EDIT: System: Rx GM/GM2
System ON) is OFF.
❍GM System Off
Status Data byte
F0H 7EH, 7F, 09H, 02H
Byte Explanation
F0H Exclusive status
7EH ID number (Universal Non-realtime Message)
7FH Device ID (Broadcast)
09H Sub ID#1 (General MIDI Message)
02H Sub ID#2 (General MIDI Off)
F7H EOX (End Of Exclusive)
* Not received when the Rx GS Reset parameter (EDIT: System: Rx GS Reset) is OFF.
●Universal Realtime System Exclusive Messages
❍Master Volume
Status Data byte
F0H 7FH, 7FH, 04H, 01H, llH, mmH
Byte Explanation
F0H Exclusive status
7FH ID number (universal realtime message)
7FH Device ID (Broadcast)
04H Sub ID#1 (Device Control)
01H Sub ID#2 (Master Volume)
llH Master Volume lower byte
mmH Master Volume upper byte
F7H EOX (End Of Exclusive)
* The lower byte (llH) of Master Volume will be handled as 00H.
* The Master Volume parameter (EDIT: System: Master Volume) will change.
❍Master Fine Tuning
Status Data byte
F0H 7FH, 7FH, 04H, 03H, llH, mmH
Byte Explanation
F0H Exclusive status
7FH ID number (universal realtime message)
7FH Device ID (Broadcast)
04H Sub ID#1 (Device Control)
03H Sub ID#2 (Master Fine Tuning)
llH Master Fine Tuning LSB
mmH Master Fine Tuning MSB
F7H EOX (End Of Exclusive)
mm, ll: 00 00H - 40 00H - 7F 7FH (-100 - 0 - +99.9 [cents])
❍Master Coarse Tuning
Status Data byte
F0H 7FH, 7FH, 04H, 04H, llH, mmH
Byte Explanation
F0H Exclusive status
7FH ID number (universal realtime message)
7FH Device ID (Broadcast)
04H Sub ID#1 (Device Control)
04H Sub ID#2 (Master Coarse Tuning)
llH Master Coarse Tuning LSB
mmH Master Coarse Tuning MSB
F7H EOX (End Of Exclusive)
ll: ignored (processed as 00H)
mm: 28H - 40H - 58H (-24 - 0 - +24 [semitones])
MIDI Implementation
Status
F7H
Status
F7H
Status
F7H
Status
F7H
Status
F7H
3
