❍Effect 1 (Reverb Send Level) (Controller number 91)
Status 2nd byte
BnH 5BH
n = MIDI channel number:
vv = Reverb Send Level:
* These messages are transmitted when Reverb value is set in External Layer.
❍Effect 3 (Chorus Send Level) (Controller number 93)
Status 2nd byte
BnH 5DH
n = MIDI channel number:
vv = Chorus Send Level:
* These messages are transmitted when Chorus value is set in External Layer.
❍RPN MSB/LSB (Controller number 100, 101)
Status 2nd byte
BnH 65H
BnH 64H
n = MIDI channel number: 0H - FH (ch.1 - 16)
mm = upper byte (MSB) of parameter number specified by RPN
ll = lower byte (LSB) of parameter number specified by RPN
<<< RPN >>>
Control Changes include RPN (Registered Parameter Numbers), which are extended.
When using RPNs, first RPN (Controller numbers 100 and 101; they can be sent in any
order) should be sent in order to select the parameter, then Data Entry (Controller numbers
6 and 38) should be sent to set the value. Once RPN messages are received, Data Entry
messages that is received at the same MIDI channel after that are recognized as changing
toward the value of the RPN messages. In order not to make any mistakes, transmitting
RPN Null is recommended after setting parameters you need.
This device transmits the following RPNs.
RPN Data entry
MSB, LSB MSB, LSB
00H, 00H mmH, llH
00H, 01H mmH, llH
00H, 02H mmH, llH
00H, 05H mmH, llH
7FH, 7FH ---, ---
●Program Change
Status 2nd byte
CnH ppH
n = MIDI channel number:
pp = Program number:
* When Rec Mode is ON (EDIT: Utility: Rec Setting: Rec Mode), these messages are
transmitted when Tone is selected.
●Pitch Bend Change
Status 2nd byte
EnH llH
n = MIDI channel number:
mm, ll = Pitch Bend value:
3rd byte
vvH
0H - FH (ch.1 - 16)
00H - 7FH (0 - 127)
3rd byte
vvH
0H - FH (ch.1 - 16)
00H - 7FH (0 - 127)
3rd byte
mmH
llH
Notes
Pitch Bend Sensitivity
mm: 00H - 18H (0 - 24 semitones)
ll: ignored (processed as 00H)
Channel Fine Tuning
mm, ll: 20 00H - 40 00H - 60 00H
(-4096 x 100 / 8192 - 0 - +4096 x 100 / 8192 cent)
Channel Coarse Tuning
mm: 10H - 40H - 70H (-48 - 0 - +48 semitones)
ll: ignored (processed as 00H)
Modulation Depth Range
mm, ll: 00 00H - 06 00H
(0 - 16384 x 600 / 16384 cent)
RPN null
RPN and NRPN will be set as "unspecified."
Once this setting has been made, subsequent
0H - FH (ch.1 - 16)
00H - 7FH (prog.1 - prog.128)
3rd byte
mmH
0H - FH (ch.1 - 16)
00 00H - 40 00H - 7F 7FH (-8192 - 0 - +8191)
■Channel Mode Messages
●MONO (Controller number 126)
Status 2nd byte
BnH 7EH
n = MIDI channel number:
* These messages are transmitted when Mono/Poly value is set to MONO in External
Layer.
●POLY (Controller number 127)
Status 2nd byte
BnH 7FH
n = MIDI channel number:
* These messages are transmitted when Mono/Poly value is set to POLY in External
Layer.

■System Realtime Messages

●Timing Clock
Status
F8H
* This message will be transmitted if the Clock Out parameter (EDIT: SYSTEM: Clock Out)
is ON.
●Start
Status
FAH
* This message is sent on START operation when START/STOP function is selected on
Foot Controller or S1/S2 button.
●Stop
Status
FCH
* This message is sent on STOP operation when START/STOP function is selected on Foot
Controller or S1/S2 button.
●Active Sensing
Status
FEH
* This message is transmitted at intervals of approximately 250 msec.

■System Exclusive Messages

Universal Non-realtime System Exclusive Message and Data Set 1 (DT1) are the only
System Exclusive messages transmitted by the RD-700NX.
●Universal Non-realtime System Exclusive Message
❍Identity Reply Message
Receiving Identity Request Message, the RD-700NX send this message.
Status Data byte
F0H 7EH, dev, 06H, 02H, 41H, 2BH, 02H,
00H, 00H, 00H, 01H, 00H, 00H
Byte Explanation
F0H Exclusive status
7EH ID number (Universal Non-realtime Message)
dev Device ID (use the same as the device ID of Roland)
06H Sub ID#1 (General Information)
02H Sub ID#2 (Identity Reply)
41H ID number (Roland)
50H 02H Device family code (RD-700NX)
00H 00H Device family number code (RD-700NX)
00H 01H 00H 00H Software revision level
F7H EOX (End of Exclusive)
MIDI Implementation
3rd byte
01H
0H - FH (ch.1 - 16)
3rd byte
00H
0H - FH (ch.1 - 16)
Status
F7H
7
