MIDI Implementation

❍Vibrato Delay (Controller number 78)
Status 2nd byte
BnH 4EH
n = MIDI channel number:
vv = Vibrato Delay value (relative change):00H - 7FH (-64 - 0 - +63)
❍Portamento Control (Controller number 84)
Status 2nd byte
BnH 54H
n = MIDI channel number:
kk = source note number:
* A Note-on received immediately after a Portamento Control message will change
continuously in pitch, starting from the pitch of the Source Note Number.
* If a voice is already sounding for a note number identical to the Source Note Number,
this voice will continue sounding (i.e., legato) and will, when the next Note-on is
received, smoothly change to the pitch of that Note-on.
* The rate of the pitch change caused by Portamento Control is determined by the
Portamento Time value.
❍Effect 1 (Reverb Send Level) (Controller number 91)
Status 2nd byte
BnH 5BH
n = MIDI channel number:
vv = Reverb Send Level:
❍Effect 3 (Chorus Send Level) (Controller number 93)
Status 2nd byte
BnH 5DH
n = MIDI channel number:
vv = Chorus Send Level:
❍RPN MSB/LSB (Controller number 100, 101)
Status 2nd byte
BnH 65H
BnH 64H
n = MIDI channel number:
mm = upper byte (MSB) of parameter number specified by RPN
ll = lower byte (LSB) of parameter number specified by RPN
<<< RPN >>>
Control Changes include RPN (Registered Parameter Numbers), which are extended.
When using RPNs, first RPN (Controller numbers 100 and 101; they can be sent in any
order) should be sent in order to select the parameter, then Data Entry (Controller numbers
6 and 38) should be sent to set the value. Once RPN messages are received, Data Entry
messages that is received at the same MIDI channel after that are recognized as changing
toward the value of the RPN messages. In order not to make any mistakes, transmitting
RPN Null is recommended after setting parameters you need.
This device receives the following RPNs.
RPN Data entry
MSB, LSB MSB, LSB Notes
00H, 00H mmH, llH Pitch Bend Sensitivity
mm: 00H - 18H (0 - 24 semitones)
ll: ignored (processed as 00H)
Up to 2 octave can be specified in semitone steps.
00H, 01H mmH, llH Channel Fine Tuning
mm, ll: 20 00H - 40 00H - 60 00H
(-4096 x 100 / 8192 - 0 - +4096 x 100 / 8192 cent)
00H, 02H mmH, llH Channel Coarse Tuning
mm: 10H - 40H - 70H (-48 - 0 - +48 semitones)
ll: ignored (processed as 00H)
00H, 05H mmH, llH Modulation Depth Range
mm, ll: 00 00H - 06 00H ( 0 - 16384 x 600 / 16384 cent)
7FH, 7FH ---, --- RPN null
RPN and NRPN will be set as "unspecified." Once this
setting has been made, subsequent Parameter values that
were previously set will not change.
mm, ll: ignored
2
3rd byte
vvH
0H - FH (ch.1 - 16)
3rd byte
kkH
0H - FH (ch.1 - 16)
00H - 7FH (0 - 127)
3rd byte
vvH
0H - FH (ch.1 - 16)
00H - 7FH (0 - 127)
3rd byte
vvH
0H - FH (ch.1 - 16)
00H - 7FH (0 - 127)
3rd byte
mmH
llH
0H - FH (ch.1 - 16)
●Program Change
Status 2nd byte
CnH ppH
n = MIDI channel number:
pp = Program number:
●Pitch Bend Change
Status 2nd byte
EnH llH
n = MIDI channel number:
mm, ll = Pitch Bend value:
■Channel Mode Messages
●All Sounds Off (Controller number 120)
Status 2nd byte
BnH 78H
n = MIDI channel number:
* When this message is received, all notes currently sounding on the corresponding
channel will be turned off.
●Reset All Controllers (Controller number 121)
Status 2nd byte
BnH 79H
n = MIDI channel number:
* When this message is received, the following controllers will be set to their reset values.
Controller
Pitch Bend Change
Channel Pressure
Modulation
Breath Type
Expression
Hold 1
Sostenuto
Soft
Hold 2
RPN
NRPN
●All Notes Off (Controller number 123)
Status 2nd byte
BnH 7BH
n = MIDI channel number:
* When All Notes Off is received, all notes on the corresponding channel will be turned
off. However, if Hold 1 or Sostenuto is ON, the sound will be continued until these are
turned off.
●OMNI OFF (Controller number 124)
Status 2nd byte
BnH 7CH
n = MIDI channel number:
* The same processing will be carried out as when All Notes Off is received.
●OMNI ON (Controller number 125)
Status 2nd byte
BnH 7DH
n = MIDI channel number:
* The same processing will be carried out as when All Notes Off is received. OMNI ON
will not be turned on.
●MONO (Controller number 126)
Status 2nd byte
BnH 7EH
n = MIDI channel number:
mm = mono number:
* The same processing will be carried out as when All Notes Off is received.
0H - FH (ch.1 - 16)
00H - 7FH (prog.1 - prog.128)
3rd byte
mmH
0H - FH (ch.1 - 16)
00 00H - 40 00H - 7F 7FH (-8192 - 0 - +8191)
3rd byte
00H
0H - FH (ch.1 - 16)
3rd byte
00H
0H - FH (ch.1 - 16)
Reset value
±0 (center)
0 (off)
0 (off)
0 (min)
127 (max)
0 (off)
0 (off)
0 (off)
0 (off)
unset; previously set data will not change
unset; previously set data will not change
3rd byte
00H
0H - FH (ch.1 - 16)
3rd byte
00H
0H - FH (ch.1 - 16)
3rd byte
00H
0H - FH (ch.1 - 16)
3rd byte
mmH
0H - FH (ch.1 - 16)
00H - 10H (0 - 16)
