User's Manual
dynaEdge DE-100/DE-105/DE-10*
Series

Advertisement

Table of Contents
loading

Related Manuals for Toshiba dynaEdge DE-100 Series

Summary of Contents for Toshiba dynaEdge DE-100 Series

  • Page 1 User's Manual dynaEdge DE-100/DE-105/DE-10* Series...
  • Page 2 Memory media ..................4-9 Wireless WAN device ................4-11 GPS Function ..................4-13 USB Type-C™ Adapter ................ 4-13 Security lock ..................4-18 Optional TOSHIBA Accessories ............4-19 Sound System ..................4-19 Chapter 5 Utilities and Advanced Usage Utilities and Applications ..............5-1 Special features ..................
  • Page 3 TOSHIBA HWSetup ................5-6 TOSHIBA PC Health Monitor ..............5-7 TOSHIBA Setup Utility ................5-9 Chapter 6 Troubleshooting Problem-solving process ..............6-1 Hardware and system checklist ............6-4 TOSHIBA support ................6-11 Chapter 7 Appendix Specifications ..................7-1 AC Power Cord and Connectors ............7-2 Information for Wireless Devices ............

  • Page 4: Copyright, Disclaimer And Trademarks

    Copyright, Disclaimer and Trademarks Copyright © 2017 Toshiba Client Solutions Co., Ltd. All Rights Reserved. Under the copyright laws, this manual cannot be reproduced in any form without the prior written permission of TOSHIBA. No patent liability is assumed, with respect to the use of the information contained herein.

  • Page 5: Regulatory Information

    Only peripherals complying with the FCC class B limits can be attached to this equipment. Operation with non-compliant peripherals or peripherals not recommended by TOSHIBA is likely to result in interference to radio and TV reception. Shielded cables must be used between the external devices and the computer’s Universal Serial Bus (USB 3.0) port, USB Type-C™...

  • Page 6: Fcc Conditions

    Belt clips, holsters and other body-worn accessories must not contain metallic components to satisfy RF Exposure requirements. Contact Address: TOSHIBA America Information Systems, Inc. 9740 Irvine Boulevard Irvine, California 92618-1697 Telephone: (949) 583-3000 This information is only applicable for the countries/regions where it is required.

  • Page 7: Eu Declaration Of Conformity

    EMC (Electromagnetic Compatibility) standards. However, TOSHIBA cannot guarantee that this product still observes these EMC standards if options or cables not produced by TOSHIBA are connected or implemented. In this case the persons who have connected/implemented those options/cables have to provide assurance that the system (PC plus options/cables) still fulfils the required standards.

  • Page 8: Canadian Notice

    Note that Canadian Department of Communications (DOC) regulations provide, that changes or modifications not expressly approved by TOSHIBA could void your authority to operate this equipment. This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.
  • Page 9 Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.
  • Page 10 For more detailed information about the collection and recycling programmes available in your country, please visit our website ( www.toshiba.eu/recycling ) or contact your local council office or the retail outlet where you purchased the product. User's Manual...
  • Page 11 Evaluation, Authorization and Restriction of Chemicals), entered into force on 1 June 2007, with phased deadlines to 2018. Toshiba will meet all REACH requirements and is committed to provide our customers with information about the presence in our articles of substances included on the candidate list according to REACH regulation.
  • Page 12 Toshiba meets all requirements of Turkish regulation 28300 “Restriction of the use of certain hazardous substances in electrical and electronic equipment”.

  • Page 13: Video Standard Notice

    Video Standard Notice THIS PRODUCT IS LICENSED UNDER THE AVC, THE VC-1 AND MPEG-4 VISUAL PATENT PORTFOLIO LICENSE FOR THE PERSONAL AND NON-COMMERCIAL USE OF A CONSUMER FOR (I) ENCODING VIDEO IN COMPLIANCE WITH THE ABOVE STANDARDS ("VIDEO") AND/OR (II) DECODING AVC, VC-1 AND MPEG-4 VIDEO THAT WAS ENCODED BY A CONSUMER ENGAGED IN A PERSONAL AND NONCOMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO PROVIDER LICENSED BY MPEG LA TO PROVIDE SUCH...
  • Page 14 Products derived from this software may not be called "OpenSSL" nor may "OpenSSL" appear in their names without prior written permission of the OpenSSL Project. Redistributions of any form whatsoever must retain the following acknowledgment: "This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit"...

  • Page 15: Freetype License Issues

    This can be in the form of a textual message at program startup or in documentation (online or textual) provided with the package. Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met: Redistributions of source code must retain the copyright notice, this list of conditions and the following disclaimer.
  • Page 16 Copyright 1996-2002, 2006 by David Turner, Robert Wilhelm, and Werner Lemberg Introduction ============ The FreeType Project is distributed in several archive packages; some of them may contain, in addition to the FreeType font engine, various tools and contributions which rely on, or relate to, the FreeType Project. This license applies to all files found in such packages, and which do not fall under their own explicit license.
  • Page 17 authors (David Turner, Robert Wilhelm, and Werner Lemberg) as the `FreeType Project', be they named as alpha, beta or final release. `You' refers to the licensee, or person using the project, where `using' is a generic term including compiling the project's source code as well as linking it to form a `program' or `executable'.

  • Page 18: Disposing Of The Computer And The Computer's Battery

    General Precautions TOSHIBA computers are designed to optimize safety, minimize strain and withstand the rigors of portability. However, certain precautions should be User's Manual...
  • Page 19 observed to further reduce the risk of personal injury or damage to the computer. Be certain to read the following general precautions and to note the cautions included in the text of the manual. Provide adequate ventilation Always make sure that your computer and AC adaptor have adequate ventilation and are protected from overheating when the power is turned on or when an AC adaptor is connected to a power outlet (even if your computer is in Sleep Mode).

  • Page 20: Cleaning The Computer

    Heat injury Avoid prolonged physical contact with the computer. If the computer is used for long periods, its surface can become very warm. While the temperature will not feel hot to the touch, if you maintain physical contact with the computer for a long time, for example if you rest the computer on your lap, your skin might suffer a low-heat injury.

  • Page 21: Safety Icons

    Be careful not to subject the computer to impact or shock. A failure to follow this instruction could result in damage to computer, computer failure, or loss of data. Never transport your computer with any cards installed. This might damage either the computer and/or the card resulting in computer failure.

  • Page 22: Equipment Checklist

    This chapter provides an equipment checklist, and basic information to start using your computer. If you use an operating system that was not pre-installed by TOSHIBA, some of the features described in this manual might not function properly. To start using this device as a Windows computer, connect the following...

  • Page 23: Conventions

    Conventions This manual uses the following formats to describe, identify, and highlight terms and operating procedures. Start The word "Start" refers to the " " button in Windows 7. Click Left-click the connected mouse once. Right-click Right-click the connected mouse once. Double-click Left-click the connected mouse twice.

  • Page 24: Connecting The Ac Adaptor

    AC power to DC power and reduces the voltage supplied to this computer. It is recommended to use the TOSHIBA AC adaptor that was included with your computer, or use AC adaptors specified by TOSHIBA to avoid any risk of fire or other damage to the computer. Use of an incompatible AC adaptor might cause fire or damage to the computer possibly resulting in serious injury.
  • Page 25 Figure 2-1 Connecting the power cord to the AC adaptor (2-pin plug) Figure 2-2 Connecting the power cord to the AC adaptor (3-pin plug) Either a 2-pin or 3-pin adaptor/cord is included with the computer depending on the model. Connect the DC output plug of the AC adaptor to the DC IN 19V jack on your computer.

  • Page 26: Turning On The Power

    Figure 2-4 Connecting the USB-C™ Adapter and other peripherals 1. USB Type-C™ (USB3.1 Gen1) port 2. USB Type-C™ adapter plug Product appearance depends on the model you purchased. Turning on the power This section describes how to turn on the power. The Power button ring LED indicates the status.

  • Page 27: Turning Off The Power

    Figure 2-5 Turning on the power 1. Power button Product appearance depends on the model you purchased. Initial setup The Windows Startup Screen is the first screen displayed when you turn on the power. To install the operating system properly, follow the on-screen instructions on each screen.

  • Page 28: Restarting The Computer

    Turn off any peripheral devices connected to your computer. Do not turn the computer or peripheral devices back on immediately. Wait a short period to avoid any potential damage. Restarting the computer Certain conditions require that you restart the computer, for example if you change certain computer settings.
  • Page 29 USB keyboard for a short amount of time. Note that USB keyboard keys can only be used if the Wake-up on Keyboard option is enabled within the TOSHIBA HWSetup. If the computer enters Sleep Mode while a network application is active, the application might not be restored when the computer is next turned on and the system returns from Sleep Mode.

  • Page 30: Hibernation Mode

    Hibernation Mode The Hibernation Mode feature saves the contents of memory to the internal storage drive when the computer is turned off so that, the next time it is turned on, the previous state is restored. Note that the Hibernation Mode feature does not save the status of any peripheral devices connected to the computer.

  • Page 31: System Recovery

    Data save in Hibernation Mode When you turn off the power in Hibernation Mode, the computer takes a moment to save the current data in memory to the internal storage drive. After you turn off the computer, and the content of memory has been saved to the internal storage drive, turn off the power to any peripheral devices.
  • Page 32 Insert the first blank disc into the external optical disc drive tray, or insert the USB Flash Memory into one available USB port. Click Start -> All Programs -> TOSHIBA -> Support & Recovery -> Recovery Media Creator. Follow the on-screen instructions to finish creating the Recovery Media.

  • Page 33: Recovery Partition

    Recovery Media. However, if you have already created a Recovery Media, you can use it to restore the recovery partition. If you have not created Recovery Media, contact TOSHIBA support for assistance. Restoring the pre-installed software from the Recovery Partition A portion of the total internal storage drive space is configured as a hidden recovery partition.
  • Page 34 If you set up your internal storage drive again later, do not change, delete, or add partitions in a manner other than specified in the manual, otherwise you might find that space for the required software is not available. In addition, if you use a third-party partitioning program to reconfigure the partitions on your internal storage drive, you might find that it becomes impossible to set up your computer.

  • Page 35: Grand Tour

    Chapter 3 The Grand Tour This chapter identifies the various components of the computer. It is recommended that you become familiar with each before you operate the computer. Legal Footnote (Non-applicable Icons) For more information regarding Non-applicable Icons, refer to the Legal Footnotes section.
  • Page 36 Figure 3-1 Grand tour of the computer 1. Wireless communication antennas 9. Power button ring LED (not shown) 2. Universal Serial Bus (USB 3.0) port 10. Power button 3. USB Type-C™ (USB3.1 Gen1) port 11. DC IN/Battery indicator 4. Headphone/Microphone jack 12.
  • Page 37 Universal Serial Bus One Universal Serial Bus port, which complies to (USB 3.0) port the USB 3.0 standard, is provided on the computer. The USB 3.0 port is compliant with USB 3.0 standard and backward compatible with USB 2.0 devices. USB Type-C™...
  • Page 38 Fingerprint Sensor This sensor enables you to enroll and sign in with a fingerprint. Some models are equipped with a Fingerprint Sensor. Security lock slot A security cable can be attached to this slot and then connected to a desk or other large object in order to deter theft of the computer.

  • Page 39: Internal Hardware Components

    Internal Storage Drive The capacity of the internal storage drive varies depending on the model. To check which type of internal storage drive is included in your model, open the TOSHIBA PC Diagnostic Tool by clicking Start -> All Programs -> TOSHIBA -> Support & Recovery ->...
  • Page 40 Under certain unusual conditions of prolonged non-use and/or exposure to high temperatures, the SSD might be vulnerable to data retention errors. Legal Footnote (Internal Storage Drive Capacity) For more information regarding Internal Storage Drive Capacity, refer to the Legal Footnotes section.

  • Page 41: Power Condition Descriptions

    Power Condition Descriptions The computer operating capability and battery charge status are affected by different power conditions, including whether an AC adaptor is connected and what the battery charge level is. DC IN/Battery indicator Check the DC IN/Battery indicator to determine the status of the battery pack and the power status with the AC adaptor connected.

  • Page 42: Using The Control Buttons

    Chapter 4 Operating Basics This chapter describes the basic operations of your computer, and highlights the precautions that must be taken when using it. Using the Control buttons The Control buttons on the computer might support the following operations: Arrow buttons Press the up/down/left/right button to navigate within the connected screen.

  • Page 43: Points To Note About The Fingerprint Sensor

    By enrolling the ID and password onto the fingerprint authentication feature, it is no longer necessary to input the password from the keyboard. Fingerprint feature enables you to: Sign-in to Windows Unlock the password-protected screen-saver. Figure 4-1 Using the Fingerprint Sensor 1.

  • Page 44: Battery

    Remove static electricity from your fingers by touching any metal surface. Static electricity is a common cause of sensor failures, especially when the weather is dry. Clean the sensor with a lint-free cloth. Do not use detergent or any other chemicals to clean the sensor. Avoid the following finger conditions for enrollment or recognition as they might result in fingerprint enrollment errors or a drop in the fingerprint recognition success rate...

  • Page 45: Care And Use Of The Battery Pack

    If the RTC battery becomes completely discharged, the system will lose this information and the real- time clock and calendar will stop working. You can change the Real-Time Clock settings in the TOSHIBA Setup Utility. Refer to Real-Time Clock for further information.

  • Page 46: Charging The Battery

    Use only the computer connected to an AC power source or optional TOSHIBA Battery charger to charge the battery pack. Never attempt to charge the battery pack with any other charger. Charging Time The following table shows the approximate time required to charge an exhausted battery fully.

  • Page 47: Monitoring Battery Capacity

    The DC IN/Battery indicator might show a rapid decrease in battery operating time when you try to charge a battery under the following conditions: The battery has not been used for a long time. The battery has completely discharged and been left in the computer for a long time.

  • Page 48: Extending Battery Life

    The environmental temperature - operating time decreases at low temperatures System Sleep Mode settings System Hibernation Mode settings How frequently you turn the computer off and on Battery pack exhausted time When you turn off the power of your computer with the battery pack fully charged, the battery pack is exhausted within the following approximate period.

  • Page 49: Removing The Battery Pack

    operating your computer away from an AC power source for an extended period of time. This section explains how to remove and install the battery pack, and begins with the removal process which is detailed through the following steps. Do not remove the battery pack while the computer is in Sleep Mode, as data is stored in RAM, so if the computer loses power it might be lost.

  • Page 50: Memory Media

    Ensure that the battery pack is securely in place and the battery lock is in its locked ( ) position. Turn your computer over. Memory media The computer is equipped with a memory media slot that can accommodate some kinds of memory media with various memory capacities so that you can easily transfer data from devices, such as digital cameras and Personal Digital Assistants.

  • Page 51: Media Care

    To format all areas of the memory card, including the protected area, you must obtain an appropriate application that applies the copy protection system. Media care Observe the following precautions when handling the card. Do not twist or bend cards. Do not expose cards to liquids or store in humid areas or lay media close to containers of liquid.

  • Page 52: Wireless Wan Device

    Press the memory media gently until it clicks into place. Figure 4-4 Inserting memory media 1. Memory media slot 2. Memory media Make sure that the memory media is oriented properly before you insert it. If you insert the media in wrong direction, you might not be able to remove it.

  • Page 53: Installing A Sim Card

    Installing a SIM card To install a SIM card, do the following: Click Start, and click Shut down. Ensure that the Power button ring LED indicator is off. Remove the AC adaptor and all cables and peripherals connected to the computer. Turn the computer upside down and remove the battery pack.

  • Page 54: Gps Function

    Depending on the model you purchased, one USB-C™ to HDMI™/VGA Travel Adapter might be provided. Always use the TOSHIBA USB Type-C™ adapter that is included with your computer or TOSHIBA accessories. Disconnect any devices and cables from the USB Type-C™ adapter when connecting/disconnecting the AC adaptor or the USB Type-C™...

  • Page 55: Lan Port

    The USB Type-C™ port (Power Delivery Charging) on this adapter does not function on your computer. It is used for connecting AC adaptor for some other TOSHIBA computers only. LAN port The LAN port on the USB Type-C™ adapter supports Ethernet LAN (10...

  • Page 56: Lan Cable Types

    LAN cable types The computer must be configured properly before connecting to a LAN. Logging onto a LAN using the computer’s default settings might cause a malfunction in LAN operation. Check with your LAN administrator regarding set-up procedures. If you are using Gigabit Ethernet LAN (1000 megabits per second, 1000BASE-T), be sure to connect with a CAT5e cable or higher.
  • Page 57 Plug one end of the cable into the LAN port on the USB Type-C™ adapter. Press gently until you hear the latch click into place. Figure 4-7 Connecting the LAN cable 1. USB Type-C™ port 3. LAN port 2. USB Type-C™ adapter 4.
  • Page 58 Figure 4-8 Connecting the HDMI™ output port 1. USB Type-C™ port 3. HDMI™ output port 2. USB Type-C™ adapter 4. HDMI™ cable USB Type-C™ adapter appearance varies depend on the model you purchased. Do not plug/unplug an HDMI™ device under the following conditions: The system is starting up.

  • Page 59: Security Lock

    VGA monitor port An external analog monitor can be connected to the VGA monitor port on the USB Type-C™ adapter. To connect an external analog monitor, do the following: Connect the USB Type-C™ adapter to the USB Type-C™ port on your computer.

  • Page 60: Optional Toshiba Accessories

    You can purchase different types of USB Type- Adapters C™ adapters as accessories from TOSHIBA. Please contact your reseller or TOSHIBA dealer regarding which type is available in your region. Not all the accessories are available in your region. Contact your reseller or TOSHIBA dealer for more information.

  • Page 61: Microphone Level

    To launch the Volume Mixer utility, right-click on the speaker icon on the Windows Taskbar, and then select Open Volume Mixer from the sub menu. To adjust the volume level of headphones, move the Speakers slider. To adjust the volume level of an application that you are using, move the slider for the corresponding application.
  • Page 62 Default Format You can change the sample rate and bit depth of sound. Headphone/Microphone selection To change the type of headphone or microphone, do the following: Plug a headphone or microphone into the headphone/microphone combo jack. Double-click on the circle button in the right side of the Realtek HD Audio Manager main screen.

  • Page 63: Utilities And Applications

    To access this utility, click Start -> All Programs -> TOSHIBA -> Tools & Utilities -> eco Utility. For details on TOSHIBA eco utility, see the help file.

  • Page 64: Special Features

    -> TOSHIBA -> Support & Recovery -> Applications and Drivers. Special features The following features are either unique to TOSHIBA computers or are advanced features which make the computer more convenient to use. Access each function using the following procedures.
  • Page 65 Internal storage drive This feature automatically cuts off power to the internal storage drive when it is not accessed for automatic power off a specified time, with power being restored when the internal storage drive is next accessed. This can be specified in the Power Options. System automatic This feature automatically shuts down the system Sleep/Hibernation...

  • Page 66: Toshiba Password Utility

    Windows password. User Password To start the utility, click the following items: Start -> All Programs -> TOSHIBA -> Tools & Utilities -> Password Utility -> User Password User authentication might be required to validate user rights when using TOSHIBA Password Utility to delete or change passwords, etc.
  • Page 67 Refer to TOSHIBA Setup Utility section for further information. If you forget your HDD/SSD User Password, TOSHIBA will NOT be able to assist you, and your internal storage drive will be rendered COMPLETELY and PERMANENTLY INOPERABLE. TOSHIBA will NOT be held responsible for any loss of any data, any loss of use or...

  • Page 68: Toshiba Hwsetup

    TOSHIBA HWSetup TOSHIBA HWSetup is the TOSHIBA configuration management tool available through the Windows operating system. To run TOSHIBA HWSetup, click Start -> All Programs -> TOSHIBA -> Tools & Utilities -> HWSetup. User's Manual...

  • Page 69: Toshiba Pc Health Monitor

    The TOSHIBA HWSetup window contains a number of tabs to allow specific functions of the computer to be configured. In addition, there are also three buttons: OK, Cancel and Apply. Accepts your changes and closes the TOSHIBA HWSetup window. Cancel Closes the window without accepting your changes.
  • Page 70 TOSHIBA standard limited warranty terms and limitations apply. Starting the TOSHIBA PC Health Monitor The TOSHIBA PC Health Monitor can be opened by clicking Start -> All Programs -> TOSHIBA -> Support & Recovery -> PC Health Monitor. The TOSHIBA PC Health Monitor main screen is displayed.

  • Page 71: Toshiba Setup Utility

    TOSHIBA Setup Utility TOSHIBA Setup Utility is a BIOS setup utility that provides you a menu- based user interface so that you can easily view and change BIOS settings. To enter the BIOS setup utility, do the following: Save your work.

  • Page 72: Problem-Solving Process

    In reality many problems can be solved simply, but a few might require help from TOSHIBA Support. If you find you need to consult others, be prepared to describe the problem in as much detail as possible.

  • Page 73: Analyzing The Problem

    Always try to make detailed notes of your observations and keep them in a permanent error log - this helps you to describe your problems to TOSHIBA Support. In addition, if a problem recurs, the log you have made helps to identify the problem faster.

  • Page 74: If Something Goes Wrong

    Before using a peripheral device or application software that is not an authorized TOSHIBA part or product, make sure that the device or software can be used with your computer. Use of incompatible devices might cause injury or might damage your computer.

  • Page 75: Hardware And System Checklist

    By holding down one of the following keys during startup, your computer can load the following advanced options. Advanced option TOSHIBA Setup Utility Boot Menu 0 (zero) Recovery options If your computer starts to load the Operating System instead of desired advanced options, do the following: Click Start.

  • Page 76: Overheating Power Down

    If the computer has reached room temperature and it still does not start, or if it starts but shuts down quickly, contact TOSHIBA Support. AC power If you have trouble turning on the computer with the AC adaptor connected, check the status of the DC IN/Battery indicator.
  • Page 77 The RTC battery should be replaced only by your dealer or by a TOSHIBA service presentative, and then set the date/time in the TOSHIBA Setup Utility by using the following steps: Launch the TOSHIBA Setup Utility.
  • Page 78 Real-Time Clock (RTC) information might be cleared if the power is turned on by pressing the power button. You should set the system date/time manually in TOSHIBA Setup Utility. If it still does not operate properly, you should contact your reseller or dealer.

  • Page 79: Pointing Device

    If you are still unable to resolve the problem, contact TOSHIBA Support. Pointing device If you are using a USB mouse, you should also refer to both the mouse section and the documentation supplied with your mouse.

  • Page 80: Usb Device

    If you are still unable to resolve the problem, contact TOSHIBA Support. USB device In addition to the information in this section, also refer to the documentation supplied with your USB device.

  • Page 81: External Monitor

    Display error occurs Check that the cable connecting the external monitor to the computer is firmly attached. If you are still unable to resolve the problem, contact TOSHIBA Support. Problem Procedure Cannot access LAN Check for a firm cable connection between the LAN port and the LAN hub.

  • Page 82: Toshiba Support

    TOSHIBA Support. TOSHIBA support If you require any additional help using your computer or if you are having problems operating the computer, you might need to contact TOSHIBA for additional technical assistance. Before you call Some problems you experience might be related to software or the operating system so it is important that you investigate other sources of assistance first.
  • Page 83 - they are your best resource for current information and support. TOSHIBA technical support If you are still unable to solve the problem and suspect that it is hardware- related, refer to the information listed in the accompanying warranty booklet.

  • Page 84: Specifications

    Chapter 7 Appendix Specifications This section summarizes the technical specifications of the computer. Physical Dimensions The following physical dimensions do not include parts that extend beyond the main body. The physical dimensions vary depending on the model you purchased. Size Approximately 165 (w) x 85 (d) x 20 (h) millimeters (not including parts that extend beyond the main body) Environmental Requirements...

  • Page 85: Ac Power Cord And Connectors

    External RGB monitor port pin assignment Signal Name Description Red Video Signal Green Video Signal Blue Video Signal Reserved Reserved Ground Ground Ground Ground Power Supply Ground Reserved Reserved Serial Data Signal HSYNC Horizontal Sync Signal VSYNC Vertical Sync Signal Serial Clock Signal I/O (I): Input to computer I/O (O): Output from computer...

  • Page 86: Certification Agencies

    Certification agencies China: U.S. and Canada: UL listed and CSA certified No. 18 AWG, Type SVT or SPT-2 Australia: Japan: DENANHO Europe: Austria: Italy: Belgium: CEBEC The Netherlands: KEMA Denmark: DEMKO Norway: NEMKO Finland: FIMKO Sweden: SEMKO France: LCIE Switzerland: Germany: United Kingdom: In Europe, two conductors power cord must be VDE type, H05VVH2-F or...

  • Page 87: Information For Wireless Devices

    If you experience any such problem, immediately turn off either one of your ® Bluetooth or Wireless LAN. ® If you have any questions about using Wireless LAN or Bluetooth Module, visit http://www.pcsupport.toshiba.com In Europe, visit http://www.toshiba-europe.com/computers/tnt/bluetooth.htm User's Manual...

  • Page 88: Wireless Devices And Your Health

    Because wireless products operate within the guidelines found in radio frequency safety standards and recommendations, TOSHIBA believes wireless products are safe for use by consumers. These standards and recommendations reflect the consensus of the scientific community and result from deliberations of panels and committees of scientists who continually review and interpret the extensive research literature.

  • Page 89: Card Specifications

    If this occurs, the outsider might illegally access your system, eavesdrop, or cause the loss or destruction of stored data. TOSHIBA is not liable for the loss of data due to eavesdropping or illegal access through the wireless LAN and the damage thereof. Card Specifications Compatibility IEEE 802.11 Standard for Wireless LANs...

  • Page 90: Radio Regulatory Information

    Range is also impacted due to "obstacles" in the signal path of the radio that might either absorb or reflect the radio signal. Radio Frequency Interference Requirements This device is restricted to indoor use due to its operation in the 5.15 to 5.25GHz frequency range.
  • Page 91 Europe Restrictions for Use of 2400.0-2483.5MHz Frequencies in Europe Azerbaijan: Limited No license needed if used indoor implementation and power not exceeding 30mW (14.77dBm). Italy: Implemented The public use is subject to general authorisation by the respective service provider. Russian Limited Using SRD (Short Range Device) Federation:...
  • Page 92 Using SRD with DSSS (Direct Sequence Spread Spectrum) and other than FHSS wideband modulation. Maximum EIRP density is 2mW/MHz. Maximum100mW (20dBm) EIRP is permitted to use. Maximum EIRP density is 20mW/MHz. Maximum 100mW (20dBm) EIRP is permitted to use with the following condition: It is permitted to use SRD for outdoor applications only for...
  • Page 93 Software Version ® Intel PROSet/Wireless WiFi Software 19.x and previous versions Maximum Power Output (2400 - 2483.5 MHz) IEEE802.11 b/ Maximum 100mW (20dBm) EIRP g/n mode (2400 - 2483.5 MHz) BLE / Maximum 10mW (10dBm) EIRP Bluetooth (5150 - 5725 MHz) IEEE802.11 a/n/ Maximum 200mW (23dBm) EIRP ac mode The low band 5.15 - 5.35 GHz is for...
  • Page 94 The term “IC” before the equipment certification number only signifies that the Industry Canada technical specifications were met. USA-Federal Communications Commission (FCC) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 95 If this equipment causes RF interference to other radio stations, promptly change the frequency being used, change the location of use, or turn off the source of emissions. Contact an authorized TOSHIBA service provider if you have problems with interference caused by this product to Other Radio Stations.

  • Page 96: Device Authorization

    (1)(2) (3)(4) 2.4 : This equipment uses a frequency of 2.4 GHz. DS : This equipment uses DS-SS modulation. OF : This equipment uses OFDM modulation. 4 : The interference range of this equipment is less than 40 m. : This equipment uses a frequency bandwidth from 2,400 MHz to 2,483.5 MHz.
  • Page 97 ® Intel Dual Band Wireless-AC 8260 The Name of the radio equipment: 8260D2W DSP Research, Inc. Approval Number: D150070003 The following restrictions apply: Do not disassemble or modify the device. Do not install the embedded wireless module into other device. Information about Intel ®...
  • Page 98 Enter a new password. Password must comply with the following requirements concerning character types and length: Must be between 8 and 32 characters long. Must contain at least one number (“0”, “1-9”). Must contain a mix of lower-case (“a”, “b”, “z”, etc.) and upper-case (“A”, “B”, “Z”, etc.) letter.
  • Page 99 When using the computer with the AC adaptor connected and the AMT function set to enabled, power might still be supplied to the system memory even when the computer power is turned off, or the computer is in Sleep Mode or Hibernation Mode. When connecting the AC adaptor, the computer is powered and can be turned on.

  • Page 100: Legal Footnotes

    5°C to 30°C (41 -86°F) or >25°C (77°F) at high altitude (all temperature references are approximate and might vary depending on the specific computer model - contact TOSHIBA support for details). CPU performance might also vary from specifications due to design configuration.

  • Page 101: Battery Life

    Published battery life numbers are achieved on select models and configurations tested by TOSHIBA at the time of publication. Recharge time varies depending on usage. Battery might not charge while computer is consuming full power.

  • Page 102: Glossary

    Total Available Graphics Memory is the total of, as applicable, Dedicated Video Memory, System Video Memory and Shared System Memory. Shared System Memory varies depending on system memory size and other factors. Wireless LAN The transmission speed over the wireless LAN and the distance over which wireless LAN can reach might vary depending on surrounding electromagnetic environment, obstacles, access point design and configuration, and client design and software/hardware configurations.
  • Page 103 DVD-R DL: Digital Versatile Disc Recordable Dual Layer DVD-ROM: Digital Versatile Disc-read Only Memory DVD-RW: Digital Versatile Disc-rewritable DVD+R DL: Digital Versatile Disc Recordable Double Layer FAT: File Allocation Table FCC: Federal Communications Commission FHD: Full High Definition gigabyte GBps: gigabytes per second High Definition HD+:...
  • Page 104 ROM: Read-Only Memory RTC: Real-Time Clock S/P DIF: Sony/philips Digital Interface Format Secure Digital SDHC: Secure Digital High Capacity SDXC: Secure Digital Extended Capacity SDRAM: Synchronous Dynamic Random Access Memory SSD: Solid-State Drive TFT: Thin-film Transistor URL: Uniform Resource Locator USB: Universal Serial Bus WAN:...
  • Page 105 Index External monitor problems 6-10 AC adaptor additional 4-19 connecting 2-3 DC IN 19V jack 3-4 Graphics Processing Unit 3-6 HW Setup Battery accessing extending life 4-7 window monitoring capacity 4-6 real time clock 4-4 save mode 5-3 Battery pack replacing 4-7 cable types 4-15 connecting 4-15...
  • Page 106 Problems automatic power off 5-3 AC power 6-5 Analyzing the problem 6-2 Battery 6-5 Dual Pointing device 6-8 External monitor 6-10 TOSHIBA PC Diagnostic Hardware and system Tool 5-1 checklist 6-4 HDD 6-7 Memory Media Card 6-7 Overheating power down 6-5...
  • Page 107 Instruction Manual for Safety and Comfort...
  • Page 108 Table of Contents Introduction ..................4 Safe Use of Product, Components and Accessories ............5 Power ....................5 Communication..................12 Main Unit .....................15 Systems/Peripherals................22 Computer User Comfort Recommendations .......27 Good Working Posture ................27 Viewing Recommendations ..............28 Using the product with an external keyboard, mouse or monitor ..28 Typing style..................29 Taking breaks and varying tasks............29 Mobile computing tips ................30...
  • Page 109 FROM THE USE OF THE PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY THEREOF. While Toshiba has made every effort at the time of publication to ensure the accuracy of the information provided herein, such information is subject to change without notice.
  • Page 110 Introduction Thank you for purchasing this Toshiba product. All of the Safety Instructions contained in this Manual must be read carefully and must be fully understood before you attempt to use your product, in order to avoid potential hazards that could cause bodily injury, property damage, or damage the product.
  • Page 111 Power Safe Use of Product, Components and Accessories Power WARNING Handling of the battery ■ Never attempt to dispose of a battery by burning or by throwing it into a fire, and never allow exposure to a heating apparatus (e.g., microwave oven).

  • Page 112: Battery Safety

    Power WARNING ■ Never allow a battery to become wet. A wet battery will overheat or ignite causing rupture or fire, possibly resulting in death or serious injury. ■ Never store a battery in an area of high humidity. This could cause a fire or explosion possibly resulting in serious injury.
  • Page 113 AC adaptor (if connected) and shut off your product. Do not turn on your product’s power again until an authorized Toshiba service provider has checked it for safety. Continuing to use your product could cause a fire or battery rupture possibly resulting in serious injury.
  • Page 114 (including AC adaptor). Disassembly, modification, tampering or repairing your product could cause fire or electric shock, possibly resulting in serious injury. Please contact an authorized Toshiba service provider for any repair service. Disconnect the power cable/cord before moving your product ■...
  • Page 115 ■ Always use the TOSHIBA AC adaptor that was provided with your product, or use AC adaptors specified by TOSHIBA to avoid any risk of fire or other damage to your product. Use of an incompatible AC adaptor could cause fire or damage to your product possibly resulting in serious injury.

  • Page 116: Inserting The Battery

    Power WARNING Only use approved power cables/cords ■ Always use or purchase power cables/cords that comply with the legal voltage and frequency specifications and requirements in the country of use. Failure to do so could result in a fire or electric shock, possibly resulting in serious injury.
  • Page 117 Power NOTE Handling of the battery ■ Never attempt to install batteries in reverse polarity. For more information on batteries, please refer to your product User's Manual. Storing your product ■ If you do not intend to use your product for a long period of time, disconnect the power plug from the plug socket and store your product in a plastic bag to avoid dust accumulation.
  • Page 118 Communication Communication WARNING Turn Wi-Fi , Bluetooth and Wireless WAN Functionalities off ® ™ for Cardiac Pacemakers ■ Turn Wi-Fi, Bluetooth and Wireless WAN Functionalities off when near a person who may have a cardiac pacemaker implant or other medical electric device.
  • Page 119 Communication Turn Wi-Fi or Bluetooth or Wireless WAN Functionalities off in aircraft ■ Turn off the Wi-Fi or Bluetooth or Wireless WAN functionality in aircraft or in places that generate or can generate radio interference. Radio waves can potentially affect them, causing an accident due to malfunction. Check if a car has adequate electromagnetic compatibility when using your product in a car ■...
  • Page 120 LAN without the restrictions inherent in cabling. Toshiba strongly recommends that you take appropriate steps to ensure that the proper security is in place whenever you use a wireless connection to protect your privacy and guard against identity and/or data theft.

  • Page 121: Main Unit

    Main Unit Main Unit WARNING Turning off your product where electronic devices are regulated or controlled ■ When you have to turn off your product aboard an aircraft or in places where electronic devices are regulated or controlled, always completely shut down your product.
  • Page 122 Main Unit WARNING Choking hazards ■ Never leave small parts such as covers, small batteries, small memory cards, caps and screws within the reach of infants or small children. Swallowing a small part may cause choking and suffocation resulting in death or serious injury.
  • Page 123 Never touch the LCD if it is damaged or broken, as the liquid contained within the display may leak, possibly resulting in serious injury. Contact an authorized Toshiba service provider immediately for replacement of the damaged LCD and dispose of any damaged LCD in compliance with local laws and/or regulations.
  • Page 124 Main Unit CAUTION Avoid placing your product on unstable surfaces ■ Never place your product on a shaky table, uneven, tilted surface or other unstable location. your product may fall, causing damage to your product or possibly injury. Depending on the direction and/or angle of tilt of your product, your product could automatically shut down to avoid overheating.
  • Page 125 If dust contaminates your product, do not turn on the power. Take it to an authorized Toshiba service provider before you use it. Clean any dust accumulated on your product’s air vents ■...
  • Page 126 Main Unit CAUTION Never place or drop heavy objects onto your product ■ Never place a heavy object on your product and be careful not to drop a heavy object onto your product. It could damage your product or cause system failure.
  • Page 127 Use your product at temperatures and humidity levels within the recommended environmental ranges. These ranges may vary depending on the specific product model - please refer to your product documentation or Toshiba website for details. ■ Always avoid abrupt changes of temperature or humidity.

  • Page 128: Headset And Earphone Volume Level Notice

    Systems/Peripherals Systems/Peripherals DANGER Do not disassemble or repair your optical drive ■ The product may contain a Optical Disk Drive (ODD), such as a CD- ROM, CDR/W, DVD, Blu-ray Disc™ drive or similar which have built-in laser device. To prevent any risk of exposure to laser radiation, do not disable or open any ODD assembly for any reason.

  • Page 129: Connecting Peripheral Devices

    ■ Before using a peripheral device or application software that is not an authorized Toshiba part or product, make sure the device or software can be used with your product. Use of incompatible devices may cause injury or may damage your product.

  • Page 130: Replacing The Memory Module

    Systems/Peripherals CAUTION Replacing the memory module ■ Turn off the power and disconnect the AC adaptor when installing or replacing a memory module. ■ If you use your product for an extended period of time, the memory modules and the circuits located close to the memory modules will become hot.
  • Page 131 Systems/Peripherals CAUTION Periodic back up of stored data ■ It is a good idea to periodically back up the internal hard disk or other main storage device to external media. General storage media is not durable or stable over long periods of time and under certain conditions may result in data loss.

  • Page 132: Erasing Data

    Systems/Peripherals NOTE Anti-virus software ■ Use a virus-check program and make sure it is updated regularly. Use AC power when playing video of DVD/Blu-ray™ ■ When playing video of DVD/Blu-ray™, always connect the AC adaptor to a power plug socket or power source to ensure maximum performance.

  • Page 133: Good Working Posture

    Good Working Posture Computer User Comfort Recommendations Good Working Posture ■ Adjust your chair height: your feet should be flat on the floor and the bottom of your thighs should be evenly supported by the seat. If your feet cannot reach the floor, use a foot rest. Avoid pressure points behind the knee or under the thigh.
  • Page 134 Viewing Recommendations ■ Rest your eyes periodically by focusing on objects that are farther away. Viewing Recommendations ■ Some individuals may experience health-related complications when exposed to certain images or flashing lights (for example when playing videos or games). Discontinue use and consult a physician if you experience any health-related complications.

  • Page 135: Typing Style

    Typing style / Taking breaks and varying tasks Typing style ■ The top of the monitor should be at or slightly below eye level. A monitor that is too high or too low can cause awkward head and neck postures and may lead to discomfort in the neck muscles. ■...

  • Page 136: Mobile Computing Tips

    Mobile computing tips Mobile computing tips / Transporting the product / Seeking additional help Mobile computing tips ■ When using the product at airports, on airplanes or trains, or at meetings, make sure that you take the time to consider the points just mentioned.

  • Page 137: Check List

    Check list Check list ❏ Is your chair comfortable - does it support your back and arms well? ❏ Are your feet flat on the ground? ❏ Is there adequate space under your desk for your legs? ❏ Are the keyboard and mouse at elbow level? ❏...

This manual is also suitable for:

Dynaedge de-10 seriesDynaedge de-105 series

Table of Contents
