5 Verification and Performance Tests

Recommended Test Equipment

Recommended Test Equipment
The test equipment recommended for the performance verification
procedures is listed below. If the exact instrument is not available,
substitute calibration standards of equivalent accuracy.
Table 5-1 Recommended test equipment for performance verification procedures
Application Recommended equipment
Zero offset and gain verification procedures
Shorting plug — Dual banana plug with
Zero calibration copper wire short between the two input
terminals
DC voltage Calibrator
DC current Calibrator
AC voltage Calibrator
AC current Calibrator
Resistance Calibrator
Function/Arbitrary
Frequency waveform
generator
Capacitance Calibrator
Output verification procedures
Constant voltage
programming Digital multimeter
and readback
Digital multimeter
Constant voltage
load effect (load
Electronic load
regulation)
140
Recommended
accuracy requirements
Fluke 5520A < 20% of instrument 1 year specification
Fluke 5520A < 20% of instrument 1 year specification
Fluke 5520A < 20% of instrument 1 year specification
Fluke 5520A < 20% of instrument 1 year specification
Fluke 5520A < 20% of instrument 1 year specification
Keysight 33250A < 20% of instrument 1 year specification
Fluke 5520A < 20% of instrument 1 year specification
Keysight 3458A 8½ digit resolution
Keysight 3458A 8½ digit resolution
• Voltage range: 30 V
Keysight 6060B • Current range: 5 A
• Open and short switches
dc
U3606A User's and Service Guide
