Contec AD12-64(PCI) Manual

Ver.3.00
PCI-bus Analog Input Board
AD12-64(PCI)
T his b oard is interface boar d of t he P CI bus conf ormit y
which input s analog signal and perform s conversi on (AD
t ranslat ion) t o a digit al s ignal.
Conver sion speed : 10µsec/ch, resolut ion: AD t ranslation is
made in 12bits.
By using attached API function library API-PAC(W32), the
applicat ion software for Wi ndows can b e creat ed by t he
various program ming languages which are support ing
Win32A PI funct ion s, such as Visual Bas ic, and Vis ual C/
C++.
Features
- Mult i-c hannel analo g input capability
64 sin gle-ended a nalog inputs or 32 di fferent ial analog
input s . Single-ended or different ial input is select ed by
soft ware.
- Mult i-c hannel analo g input
Analo g input of a single and 64 input s, and 32 differe nt ial
input s is p ossible.
Select ion of a s ingle and input , and a differe nt ial inpu t can
be set up by software.
- Input range setup by sof t ware
Input range can b e chosen fr om t he fol lowing ranges for
every channel, an d can be se t up by sof t ware.
10V, 5V, 2.5V, 1.25V, 0-+10V, 0-+5V, 0-+ 2.5V,
± ± ± ±
0-+1 .25V
- Input range setup by sof t ware
A sampling t o t h e arbit rary t iming by soft ware or t he
periodic samplin g which synchroniz ed wit h t he sa mpling
clock can be performed.
T he se lect ion of e xt ernal sam pling clock signal whic h uses
t he d igit al signal inputted from t h e internal sampling clock
which uses t he cl ock generat or of board loading, and t he
out sid e is possi ble for a sampling clock.
- Digit al I/O funct ion
It has four digital input s of T T L level, and four d igit al
outputs, and t he monit or of e xt ernal apparatus and c ont rol
can b e perfor med.
- Option apparat us
By usi ng option apparat us, connect ion can be p er formed
easily .
Pleas e refer t o "cable connect or" a nd "accessories" about an
option.
Accessories (Option)
Accessories (Option)
Solderless relay terminal unit : EPD-96 *
* Option cable PCB96PS-1. 5 is requi red sep ara t ely .
Cable & Connector (Option)
Cable (option)
96pin half 96p i n shield c able :
96pin half 96p in flat ca ble :
96pin half 96p i n shield c able :
Connector (Option)
96pin half pitch (female) connect or 5piece set :
Packing List
- Board [AD12-64(PCI)] - 1
- User's Guide - 1
- CD-ROM [API-PAC(W32)] - 1
AD12-64(PCI)
PCB96P S-1.5
PCA96 P-1.5
PCA96P S-1.5
CN5-H96F
