TURBO HD
D7T Series Dome Camera
User Manual
UD02018B
User Manual
Thank you for purchasing our product. If there are any
questions, or requests, do not hesitate to contact the
dealer.
This manual applies to the model listed below.
This manual may contain several technically incorrect
places or printing errors, and the content is subject to
change without notice. The updates will be added to
the new version of this manual. We will readily improve
or update the products or procedures described in the
manual.
Model
DS-2CS54D7T-IRS
DS-2CS58D7T-IRS
0101001060615
Advertisement
Table of Contents
Related Manuals for HIKVISION DS-2CS54D7T-IRS
Summary of Contents for HIKVISION DS-2CS54D7T-IRS
-
Page 1: User Manual
This manual applies to the model listed below. Model DS-2CS54D7T-IRS DS-2CS58D7T-IRS This manual may contain several technically incorrect places or printing errors, and the content is subject to change without notice. The updates will be added to the new version of this manual. -
Page 2: Regulatory Information
Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. - Page 3 Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions” Warnings: Serious injury or death may occur if any of the warnings are neglected.
-
Page 4: Chapter 1 Introduction
Do not aim the camera at the sun or extra bright places. Blooming or smearing may occur otherwise (which is not a malfunction), and affect the endurance of sensor at the same time. The sensor may be burned out by a laser beam, so ... -
Page 5: Chapter 2 Installation
Power Cable (12 V DC) Video Cable Audio Cable Model I Video Power (12 V DC) Audio Model II Figure 1. 2 Power Cable and Video Cable Chapter 2 Installation Installation Preparation Before you start: Make sure that the device in the package is in good ... - Page 6 Figure 2. 2 Remove the Upper Cover 4. Fix the mounting base to the ceiling with the supplied screws. Note: In the supplied screw package, both self-tapping screws and expansion blots are contained. If the wall is cement, expansion blots are required ...
- Page 7 7. Install the upper cover back by tightening the torx screws. Figure 2. 6 Install the Upper Cover Note: The camera is in optimum surveillance angle by default. Slightly adjust the pan tilting angle according to the actual environment. The upper cover should be installed before having ...
-
Page 8: Main Menu
SETUP FORMAT MAIN MENU VIDEO RESET &NIGHT SETTING SAVE CONTRAST &EXIT BRIGHTNESS COLOR SHARPNESS EXPOSURE MODE COLOR GAIN GAIN SMART MIRROR Figure 3. 2 Main Menu Overview 3.1 Format Move the cursor to FORMAT, and click Iris+ to enter the FORMAT sub menu. - Page 9 balances the brightness level of the whole image and provides clear images with details. GAIN It optimizes the clarity of the image in poor light conditions. The GAIN level can be set as HIGH, MIDDLE, or LOW. Select OFF to disable the GAIN function. Note: The noise will be amplified when the GAIN is on.
- Page 10 DAY TO NIGHT Set the value from 1 to 10. The higher the value, the earlier the color status switches to B/W status. NIGHT TO DAY Set the value from 1 to 10. The higher the value, the earlier the B/W status switches to color status.
