OPERATOR'S / PARTS
MANUAL
Dump Trailer
Model
PUMA-347M
No. C2152
02/06

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PUMA-347M and is the answer not in the manual?

Questions and answers

Related Manuals for pronovost PUMA-347M

Summary of Contents for pronovost PUMA-347M

  • Page 1 OPERATOR'S / PARTS MANUAL Dump Trailer Model PUMA-347M No. C2152 02/06...
  • Page 2 Copyright © Les Machineries Pronovost Inc., 2006 All rights reserved. Printed in Canada.
  • Page 3 Basic Start-up Procedures ................. 9 Maintenance ......................10 Storage ........................11 Specifications ......................12 Parts List ........................13 Dump Trailer PUMA-347M ................13 Electric circuit PUMA-347M ................. 15 Hub 1000 ......................16 Cylinder 30TR12 .................... 17 Manual hydraulic pump #53056 ..............18 Torque Chart ......................

  • Page 5: Introduction

    INTRODUCTION CONGRATULATIONS! Thank you for choosing PRONOVOST. We are NOW take a moment to enter the model, serial confident this equipment will meet your requirements number and the date of purchase of your Trailer in the in terms of quality, performance and reliability.

  • Page 6: Safety

    SAFETY GENERAL SAFETY SAFETY IN OPERATION WHEN YOU SEE THIS SYMBOL 1) WARNING! Do not overload your trailer, do not exceed the load capacity indicated in the specifications on page 12. 2) Be sure there are no obstructions around the equipment and that no one stands near the equipment when in use.

  • Page 7: Safety With Maintenance

    SAFETY (cont'd) SAFETY WITH MAINTENANCE SAFETY IN TRANSPORT 1) Perform maintenance according to 1) Be alert while driving on the road. Never carry recommendations contained in this manual. passengers in the trailer. 2) Before performing any work under the raised platform, always install the safety prop provided.

  • Page 8: Decals

    DECALS SAFETY DECALS MAINTENANCE DECALS The safety decals are affixed wherever special safety The maintenance decals indicate the points requiring precautions are indicated. Locate them on the lubrication. Refer to maintenance section for more equipment and read them carefully. If a decal is details.

  • Page 9: Start-Up

    START-UP BASIC START-UP PROCEDURES 5) Verify for adequate tightness of all fastening devices. Refer to torque chart on page 19. 1) Lubricate all grease fittings with a good quality 6) Install panels. multi-purpose grease. 7) Check oil level in hydraulic reservoir. Use 2) Lubricate panel release mechanism with good DEXTRON III or equivalent.

  • Page 10: Maintenance

    MAINTENANCE Before performing any work under the raised 7) Check tire pressure every 50 hours of operation, platform, always install the safety prop provided. adjust according to recommendation indicated on the tires. 1) Wipe off all grease fittings with a clean cloth before adding grease in order to avoid injecting 8) Check brakes once a year and adjust or repair if dirt or sand.

  • Page 11: Storage

    STORAGE 1) Store in a cool, dry place. 4) Clean your trailer. 2) Install wooden blocks under the axles to keep the 5) Thoroughly inspect all parts of the trailer. Replace tires off the ground and cover them if left exposed or repair worn or defective parts.

  • Page 12: Specifications

    SPECIFICATIONS MODEL PUMA-347M Gross vehicle weight rating 2 860 lbs Box (interior dimensions) 51" x 86" Side and front panel 18" x 14G (welded) Back panel (removable) 12" x 14G with integrated ramps opening from top or bottom Free height 13"...
  • Page 13 TRAILER PUMA-347M 170-04061 - 13 -...
  • Page 14 TRAILER PUMA-347M (cont'd) REF. PART # DESCRIPTION 120-05601 Frame ...................... 51601 Pivot plates ....................51599 Spring backplates ..................54010 Springs ..................... 54151 U Bolt 1/2 NF x 2 1/2" x 5 3/4" round + 2 nylon locknut ....... 110-30212 Right tandem frame ...................

  • Page 15: Electric Circuit Puma-347M

    ELECTRIC CIRCUIT PUMA-347M 170-04151 REF. PART # DESCRIPTION 54104 Harness ....................54144 Male connector (16-14GA) ................52077 Yellow parking light ................... 52070 License plate light ..................54101 Red parking and signal light ................. 190-08521 Conductor for license plate light ..............
  • Page 16 HUB H1000 REF. PART # DESCRIPTION Std. Cotter pin 3/16" x 1 1/2" ................53019 Dust cap 1.973 dia..................51529 Castle nut 1" NF noir ................. 53021 Oil seal no. CR523696 ................53022 Roller bearing: cone no. L44643 ..............53023 Roller bearing: cup no.

  • Page 17: Cylinder 30Tr12

    CYLINDER 30TR12 14 ¼" 22¼" REF. PART # DESCRIPTION See RK30TR O-ring....................... See RK30TR Back-up ring ....................See RK30TR O-ring....................... See RK30TR O-ring....................... See RK30TR O-ring....................... See RK30TR Back-up ring ....................See RK30TR Wiper ....................... - - - Yoke (for 3" tube) ..................338-46000 Nut ¾"...
  • Page 18 MANUAL PUMP #53056 (106.3.20) REF. PART # CODE # DESCRIPTION 53032 502.2.441 Screw for reservoir mounting ..........53033 507.3.182 Reservoir gasket ..............53034 106.4.29 PMSS 45 Hand-Pump only (no body) ........53035 514.3.89 Pump main body ..............53036 502.3.566 Screw M8 x 25 ..............53037 507.3.208 Pump gasket ...............

  • Page 19: Torque Chart

    TORQUE CHART TORQUE SPECIFICATION TABLE Thread UNC and UNF Grade 2 Grade 5 Grade 8* Bolt size Torque Torque Torque Pound feet Newton meters Pound feet Newton meters Pound feet Newton meters Inches min. max. min. max. min. max. min. max.

  • Page 20: Warranty

    WARRANTY PRONOVOST warrants this product to the initial All PRONOVOST spare parts purchased are covered purchaser for the period of one year from the date of by a three (3) month warranty. purchase against defects in materials and workmanship. This warranty becomes void and nul if the equipment...
  • Page 24 Ce manuel est aussi disponible en français. Veuillez téléphoner. INNOVATION - EXCELLENCE LES MACHINERIES PRONOVOST INC. 260, route 159, Saint-Tite, Quebec, Canada, G0X 3H0 Tel.: (418) 365-7551, Fax: (418) 365-7954 www.pronovost.qc.ca...
