- Page 1 OPERATOR'S / PARTS MANUAL Dump Trailers Models PUMA-7000 PUMA-10000 No. C1704 No. C1704 02/03 02/03 No. C1704 No. C1704 No. C1704 02/03 02/03 02/03...
- Page 2 Copyright © Les Machineries Pronovost Inc., 2003 All rights reserved. Printed in Canada.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Section Item Page Introduction ........................ 5 Safety .......................... 6 General Safety ....................6 Safety in Operation ................... 6 Safety with Maintenance .................. 7 Safety in Transport ................... 7 Safety in Storage ....................7 Decals .......................... 8 Safety Decals ....................8 Maintenance Decals .................. -
Page 5: Introduction
INTRODUCTION CONGRATULATIONS! Thank you for choosing PRONOVOST. We are NOW take a moment to enter the model, serial confident this equipment will meet your requirements number and the date of purchase of your Trailer in the in terms of quality, performance and reliability. -
Page 6: Safety
SAFETY GENERAL SAFETY WHEN YOU SEE THIS SYMBOL sulfuric acid. Avoid contact with skin, eyes or clothing. SAFETY IN OPERATION 1) WARNING! Do not overload your trailer, do not exceed the load capacity indicated in the specifications on page 13. 2) Be sure there are no obstructions around the ATTENTION! equipment and that no one stands near the... -
Page 7: Safety With Maintenance
SAFETY (cont'd) SAFETY WITH MAINTENANCE SAFETY IN TRANSPORT 1) Perform maintenance according to 1) Be alert while driving on the road. Never carry recommendations contained in this manual. passengers in the trailer. 2) Before performing any work under the raised 2) It is prohibited to circulate on public roads with rear platform, always install the safety prop panel tied off to side of trailer. -
Page 8: Decals
DECALS SAFETY DECALS The safety decals are affixed wherever special safety precautions are indicated. Locate them on the equipment and read them carefully. If a decal is damaged, lost or illegible, install a new one. The following photos indicate where each one must be installed. -
Page 9: Maintenance Decals
DECALS MAINTENANCE DECALS The maintenance decals indicate the points requiring lubrication. Refer to maintenance section for more details. Figure 4 Part no.: A 105 Figure 5 Part no.: A 106 - 9 -... -
Page 10: Start-Up
START-UP BASIC START-UP PROCEDURES 6) Verify for adequate tightness of all fastening devices. Refer to torque chart on page 21. 1) Lubricate all grease fittings with a good quality 7) Check oil level in hydraulic reservoir. Use multiuse grease. DEXTRON III or equivalent. 2) Lubricate panel release mechanism with good 8) Check battery charge regularly to insure proper quality oil. -
Page 11: Maintenance
MAINTENANCE Before performing any work under the raised 7) Check brakes once a year and adjust or repair if platform, always install the safety prop provided. necessary. 1) Wipe off all grease fittings with a clean cloth 8) Open, clean and lubricate wheel bearings once a before adding grease in order to avoid injecting year. -
Page 12: Storage
STORAGE 1) Store in a cool, dry place. 4) Clean your trailer. 2) Install wooden blocks under the axles to keep the 5) Thoroughly inspect all parts of the trailer. Replace tires off the ground and cover them if left exposed or repair worn or defective parts. -
Page 13: Specifications
SPECIFICATIONS MODEL PUMA-7000 PUMA-10000 Gross weight 7 000 lbs 10 000 lbs Interior dimensions of box 72” x 120” 72” x 120” Front and sides panels (welded) 24" x 14G 24" x 14G Rear panel (removable) 24" x 14G 24" x 14G... -
Page 14: Parts List
TRAILER PUMA-7000 170-02903 - 14 -... - Page 15 TRAILER PUMA-7000 (cont'd) REF. PART # DESCRIPTION 120-03772 Main frame ....................120-03732 Dump box ....................110-16551 Clevis pin ....................110-16972 Rear panel frame ..................110-16991 Rear panel ....................110-16951 Rear panel lock ..................51615 Ball hitch 2 5/16" ..................52069 Emergency brake sw itch ................
- Page 16 TRAILER PUMA-7000 (cont'd) REF. PART # DESCRIPTION 54004 1/2" NPT vent plug ..................9355-6x6 Elbow 45 deg. male - female 3/8" ..............C3159-4 1/4" NPT plug ................... 300-44490 Bolt 5/8" NC x 4 1/2" + nylon locknut ............Std. «U» bolt 1/2" NF x 3" x 7" + 2 nylon locknuts ..........51599 Spring back plate ..................
-
Page 17: Dump Trailers Puma-1000
TRAILER PUMA-10000 170-02923 - 17 -... - Page 18 TRAILER PUMA-10000 (cont'd) REF. PART # DESCRIPTION 120-03912 Main frame ....................120-03902 Dump box ....................110-16551 Clevis pin ....................110-16972 Rear panel frame ..................110-16991 Rear panel ....................110-16951 Rear panel lock ..................51615 Ball hitch 2 5/16" ..................52069 Emergency brake switch ................
- Page 19 TRAILER PUMA-10000 (cont'd) REF. PART # DESCRIPTION 3069-8x8 Fitting ...................... 190-04431 Hose 3/8" x 25 3/4" + 2 fittings 6U 108 ............. C3159-4 Plug 1/4" NPT ................... 9355-6x6 Elbow 45 deg. male - female 3/8" ..............190-04441 Hose 3/8" x 93" + 1 fitting 6U 106 + 1 fitting 6U 108 ........
-
Page 20: Electric Circuit
ELECTRIC CIRCUIT PUMA-7000 & PUMA-10000 170-02931 REF. PART # DESCRIPTION 52065 Connector 7 poles (female) ................. 54013 PUMA conductor cable kit ................52069 Emergency brake switch ................51614 Battery 12 volts 850 Amp ................52077 Yellow parking light ................... 52076 Red parking light .................. -
Page 21: Torque Chart
TORQUE CHART TORQUE SPECIFICATION TABLE Thread UNC and UNF Grade 2 Grade 5 Grade 8* Bolt size Torque Torque Torque Pound feet Newton meters Pound feet Newton meters Pound feet Newton meters Inches min. max. min. max. min. max. min. max. -
Page 22: Warranty
WARRANTY PRONOVOST warrants this product to the initial All PRONOVOST spare parts purchased are covered purchaser for the period of one year from the date of by a three (3) month warranty. purchase against defects in materials and workmanship. This warranty becomes void and nul if the equipment... - Page 24 Ce manuel est aussi disponible en français. Veuillez téléphoner. INNOVATION - EXCELLENCE LES MACHINERIES PRONOVOST INC. 260, route 159, Saint-Tite, Quebec, Canada, G0X 3H0 Tel.: (418) 365-7551, Fax: (418) 365-7954 www.pronovost.qc.ca...
