SEPAMAT F
Installation and user manual
WATER, WE ´RE IN OUR ELEMENT
www.intewa.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SEPAMAT F 20 and is the answer not in the manual?

Questions and answers

Summary of Contents for Intewa SEPAMAT F 20

  • Page 1 SEPAMAT F  Installation and user manual  WATER, WE ´RE IN OUR ELEMENT www.intewa.com ...
  • Page 2   Introduction and scope of application       Safety instructions ............................2     Scope of delivery ............................. 3     Technical Data ..............................4     Device overview and dimensions ............................5     Standards, directives, tests ..............................6  ...
  • Page 3: Introduction And Scope Of Application

    Introduction and scope of application Congratulations on purchasing your SEPAMAT F. The SMT F is designed as a separation unit, for use in single-family homes, apartment buildings, offices and industry. The DVGW certified, fully automatic and ready-to-connect separation unit fulfills the separation of drinking water from category 5 liquids according to DIN EN 1717.
  • Page 4: Scope Of Delivery

     Do not install the water-handling units in locations where the temperature may drop below 0°C.  Do not install any electrical products in flood-prone areas.  The operator is responsible for adherence of the safety and installation guidelines. Scope of delivery Separation unit Wall mounting material, SEPAMAT F...
  • Page 5: Technical Data

    Technical Data SEPAMAT F 20 SEPAMAT F 40 Dimensions (H x W x D): 595 x 550 x 265 mm 595 x 550 x 265 mm Weight: 32 kg 33 kg Nominal voltage / frequency: 230 V AC / 50 Hz...
  • Page 6: Device Overview And Dimensions

    4.1 Device overview and dimensions Right side view Front view Left side view 1. Multistage centrifugal pump SEPAMAT F20 / 40 2. Pump terminal box with basic controller 3. Vent cock 4. Pressure line shut-off valve (3/4“ female) 5. Pump controller 6.
  • Page 7: Standards, Directives, Tests

    The above mentioned device corresponds with the basic safety and health requirements of the EC directives for machines. Any modification of the device not coordinated by INTEWA will void the warranty. This equipment specifically fulfils the requirements of the following EU directives:...
  • Page 8: Overview Of Components

    Overview of components The SEPAMAT F has a modular design. Each component can be separately changed. 5.1 Components of the pump controller The pump controller (see section 4.1) monitors the pressure and volume flow rate in the pressure line system. The direction of flow is marked by an arrow on the housing.
  • Page 9: Components Of The Basic Controller

    BR brn BR bl BR GND (2) BR schw (9) Wiring of the pump controller 5.2 Components of the basic controller The basic controller will be found in the terminal box of the pump [1], where all the electrical components of the SEPAMAT F are connected, as well as the motor capacitor required for start-up [2].
  • Page 10 Pos. Board code Pos. Board code Connection description Connection description KH PE -free- SS PE -free- BR PE Protective pump controller PU PE Protective pump controller Protective mains connection NE PE LP PE -free- N-Mains connection 230 V, blue NE bl NE br L1- Mains connection 230 V, brown -free-...
  • Page 11 5.3 Components of the multistage pump Exploded view of SEPAMAT F 20/40 centrifugal pump RM F 20 RM F 40 RM F-SC 20 RM F-SC 40 Nr. KIT RM F 20-A RMF 40-A KIT REF. REF.Nr. COMPONENT DESCRIPTION SMT F 20...
  • Page 12: Components Of The Separation Chamber

    5.4 Components of the separation chamber The floating valve (2) keeps the water level constant in the separation chamber. The maximum water level (6) should be approx. 2 cm below the overflow rim (4) when the floating valve is closed (backside of the container).
  • Page 13: Installation Instructions

    Installation instructions 6.1 Wall mounting The SEPAMAT F is mounted on a wall with the supplied wall bracket. The lid and lateral distances indicated should be adhered to when mounting, to provide clear maintenance access. The SEPAMAT F is wall mounted in such a way, that the groove in the top back panel of the unit hangs off the affixed wall bracket.
  • Page 14: Connection To The Mains Water Line

    The provided rubber clamping device is to be fit on the back side of the unit in the lower corners. The unevenness of the wall can be balanced by various screwing depths. 6.2 Connection to the mains water line The connection to the mains water supply is done with the provided flexible hose and stopcock. Screw the gland screw into the container connection and carefully tighten with a fixed wench.
  • Page 15: Installation Of The Pressure Line Set

    6.4 Installation of the pressure line set The pressure line set (see section 3) establishes the connection between the pump and pressure line system. The pressure line set is connected to the pump controller. The flexible hose and the shut-off valve then connect to the pressure line set and the pressure line.
  • Page 16 Note: The position of the backwater level must be taken into consideration while connecting to a drainage system, in order to prevent backflow of drainage water from the open sewer line (design according to the DIN EN 1717) entering the SEPAMAT F.
  • Page 17: Start-Up And Use

    Start-up and use 7.1 Start-up in mains water mode 1. Check that all lines are connected. Select maintenance mode = Switch position II. 2. Open the mains water line stopcock so that the separation chamber is filled with water. Note: In maintenance mode the pump primed with water automatically over the mains water tank.
  • Page 18: Display

    6. Open the pressure line shut-off valve and flush the air from the consumer line (e.g. by flushing the toilet several times or opening the garden tap). Close all the fixtures. The pump will now automatically switch off when the maximum system pressure is reached.
  • Page 19: Maintenance

    5.2 12 Warranty / Guarantee INTEWA GmbH guarantees this unit for 24 months from the date of purchase. Kindly keep the sales receipt as proof of purchase. Within the guarantee period, INTEWA GmbH reserves the right to either repair or replace faulty parts at its own discretion.
  • Page 20: Contact / Device Number

    13 Contact / Device number For customers in Germany: For any queries, ordering of spare parts, as well as in case of service, kindly contact INTEWA GmbH directly, quoting your product‘s model and identification numbers and the purchase invoice details, at: INTEWA GmbH Jülicher Straße 336...
