- Page 1 AQUALOOP ‐ direct ultrafiltration unit Assembly and operating instructions Code: AL‐direct Item no.: 230196 WASSER IST UNSER ELEMENT www.intewa.de ...
-
Page 2: Table Of Contents
8.1 Mechanical cleaning ........................ 13 8.2 Dry cleaning .......................... 1 5 8.3 Storage ............................ 17 9 Spare parts and cleaning agents ...................... 17 10 Warranty ............................. 1 8 11 Contact .............................. 1 8 Appendix .............................. 1 9 Appendix 1.1 LOG reduction ........................ 1 9 Appendix 1.2: Declaration of conformity of the membrane .............. 20 AQUALOOP-direct, manual version 1.0b_en... -
Page 3: Introduction
1 Introduction AQUALOOP direct (AL‐direct) is a direct filtration unit with an ultrafiltration membrane. The membrane technology retains even the smallest particles in the water, such as microorganisms, bacteria and viruses larger than 0.02 μm. AL‐direct can be operated either with geodetic pressure or with the aid of a pressure pump. The following waters, among others, can be filtered: Rainwater River water ... -
Page 4: Safety Instructions
(e.g. increase in turbidity), the system must be stopped, cleaned and checked immediately. The operator is responsible for compliance with the safety and installation regulations. The following points must be observed for installation and operation: Check the product for visible defects before installation. If there are any defects, the product must not be installed. All products must be checked regularly to ensure that they are in good condition. AQUALOOP-direct, manual version 1.0b_en... -
Page 5: Scope Of Delivery
3 Scope of delivery 1. 15‐litre filter housing incl. UF membrane bundle 2. Connection unit for input side with: Pipe section incl. seal / clamping ring and T‐piece with 2/3 union fitting Ball valve ¾" ready for connection with 1/3 screw connection Ball valve ¾" ready for connection with 1/3 screw connection 3. Connection unit for output side with: Pipe section bent 90° with seal/clamping ring, ball valve ¾ " ready for connection with 1/3 screw connection 2/3 Screw connection loose 4. Venting connection fitting: Ball valve ¼ " loose 3 4 1 2 AQUALOOP-direct, manual version 1.0b_en... -
Page 6: Functional Description
(4) and the clear water from all three central pipes is fed to the outlet nozzle (5) via the distributor (5). 1.) Raw water inlet 2.) Filtration housing 3.) UF membrane (1 of 3) 4.) Centre tube (1 of 3) 5.) Distributor 3/1 6.) Clear water outlet Fig.: Filtration principle, illustrated on a UF membrane AQUALOOP-direct, manual version 1.0b_en... -
Page 7: Technical Data
Yes Max. filtration capacity: 60 l/min at 3.5 bar differential pressure Temperature range: 0 ‐ 40 °C Max. Transmembrane pressure: 3 bar Max. backwash pressure: 0.5 bar Max. free chlorine at 25°C or lower: 5000 ppm at 9.5 pH during chem. cleaning Max. cleaning performance (free chlorine): 1.0 million ppmh (cumulative hours) Membrane bundle: PE O‐ring seal of the centre pipes: Ø 26mm x 3.5 mm Lifetime: Max. 10 years Bacteriological test certificate: Laboratory HUS Salzburg Hygiene Declaration of Conformity *: Yes Test standard: EN ISO 9308‐1 STANDARD Retention of viruses / bacteria up to: Log 4/Log7** *A declaration of conformity for the ultrafiltration membrane PE 1700/400 can be found in Appendix 1.2 **A measurement example of a load test performed showing the log reduction value of AL diaphragms can be found in Appendix 1.1 AQUALOOP-direct, manual version 1.0b_en... - Page 8 Fig.: Overview with dimensions AQUALOOP-direct, manual version 1.0b_en...
-
Page 9: Operating Variants
Table: Exemplary flow rate of pre‐cleaned rainwater depending on the height ∆H Height Flow rate Flow rate ∆H (max. = new condition) (in operation*) 0.5 m ( 50 mbar) 2.1 L/min ≙ 3,000 L/day 0.6 L/min ≙ 864 L/day 1.0 m (100 mbar) 6.0 L/min ≙ 8,640 L/day 1.8 L/min ≙ 2,592 L/day 2.0 m (200 mbar) 9.6 L/min ≙ 13,824 L/day 3.0 L/min ≙ 4,420 L/day 3.0 m (300 mbar) 13.2 L/min ≙ 19,008 L/day 3.6 L/min ≙ 4,800 L/day * The flow rate is strongly dependent on the raw water quality and the particulate clogging condition of the membranes Image: AL‐direct with geodetic filtration AQUALOOP-direct, manual version 1.0b_en... -
Page 10: Operation With Pump Pressure
(in operation)* 60 / 3,6 60 ‐ 12 500 litres/day 4 years 3.5 bar 3.5 bar 60 / 3,6 60 ‐ 12 1000 litres/day 2 years 3.5 bar 60 / 3,6 60 ‐ 12 1500 litres/day 1 year *Note: The flow rates are approximate as they are highly dependent on the raw water quality and the clogging condition of the membrane. AQUALOOP-direct, manual version 1.0b_en... -
Page 11: Operation In Parallel Connection
(= new condition) (in operation) 1 x AL‐direct 60 / 3,6 60 ‐ 12 1500 litres/day 3.5 bar 2 x AL‐direct 3.5 bar 120 / 7,2 120 ‐ 24 3000 litres/day 4 x AL‐direct 3.5 bar 240 / 14,4 240 ‐ 58 6000 litres/day *Note: The flow rates are approximate as they are highly dependent on the raw water quality and the clogging condition of the membrane. AQUALOOP-direct, manual version 1.0b_en... -
Page 12: Installation And Commissioning
(or for ventilation during maintenance) so that the water can drain away. V1 V4 ‐ Outlet valve The clear water pressure pipe system to the consumers is connected to this connection. When commissioning the filtration unit for the first time, the filter unit must be flushed (see Commissioning) AQUALOOP-direct, manual version 1.0b_en... - Page 13 Commissioning 1. Close all valves except for inlet valve V1 and start the pressure pump 2. Carefully open vent valve V3 to allow the air to escape until water emerges. Then close vent valve V3 again. 3. Open the outlet valve V4 so that the filtered water can be pressed to the consumers. The AL‐direct ultrafiltration unit is now ready for filtering. Note: When using the ultrafiltration unit for the first time, discard the first approx. 30 litres of filtered water until clear water comes out of the system. In this case, connect a hose to the outlet and drain the water, otherwise skip this step. AQUALOOP-direct, manual version 1.0b_en...
-
Page 14: Maintenance And Storage
Do not damage any membrane fibres. If this does happen, simply knot any torn fibres at the end. 8. Re‐insert the membrane bundles into the housing in reverse order. Before closing the cover, make sure that the union screws of the membrane bundles have not come loose. AQUALOOP-direct, manual version 1.0b_en... - Page 15 If this does happen, simply knot any torn fibres at the end. 6. Rinse the inside of the housing clean. 7. Re‐insert the membrane bundles into the housing in reverse order. Before closing the cover, make sure that the union screws of the membrane bundles have not come loose. AQUALOOP-direct, manual version 1.0b_en...
-
Page 16: Dry Cleaning
All components must therefore be thoroughly rinsed with water after acid cleaning and before adding the chlorine solution! Observe and follow the warning and safety instructions for the chemicals used! Protective gloves, protective clothing and safety goggles must be worn during the cleaning process! We recommend mixing the cleaning solution with standard household cleaning agents as follows: 1) Acidic cleaning against precipitation, e.g. limescale with citric acid Concentration of the cleaning solution 1% citric acid a.) Citric acid in powder form Dissolve 100 g per 10 litres of warm, clean water (30°C) b.) Citric acid as a solution available in drugstores Add 200 ml per 10 litres of warm, clean water (30°C) 2) Alkaline cleaning against chlorine‐based biofouling NHCl Concentration of the cleaning solution 0.25% chlorine ‐ Observe the concentration and mix the cleaning fluid according to the mixing table below. AQUALOOP-direct, manual version 1.0b_en... - Page 17 If the desired filtration performance is not achieved after chem. If the desired filtration performance is not achieved after dry cleaning, the cleaning process can be repeated. Cleaning steps for cleaning with alcohol (only if oil and grease are suspected): 1. Fill the container with 10 litres of alcohol. 2. Immerse the membrane in the alcohol. 7. Leave the membranes in the cleaning solution for a minimum of 1 hour and a maximum of 24 hours. During this time, move the membrane up and down several times so that the cleaning fluid is exchanged in the membrane fibres. 3. After the cleaning time, drain the cleaning solution into a channel via valve V2. 4. Rinse the system clean at least twice with 20 litres of water (two buckets) each time. 5. As with the initial start‐up, the first 30 litres of the filtrate must also be discarded. AQUALOOP-direct, manual version 1.0b_en...
-
Page 18: Storage
The special, hydrophilic membrane material makes it easy to recommission. The membrane material softens completely when reused in water. Caution: The fibres are brittle when dry! 9 Spare parts and cleaning agents Article description Code Art. no. AQUALOOP membrane bundle 6m²* AL‐MEM6qm 230014 AL‐direct gasket set AL‐Direct Gaskets 230019 Clamping ring seals, 1 xØ220mm and 2 x Ø50 mm Citric acid powder 0.35kg AL‐Acid0.35 230405 Chlorine cleaner 5%, 1.5 litres AL‐Chlor‐5%‐1.5L 230420 *After exceeding a service life of 10 years, the membrane bundles must be replaced. AQUALOOP-direct, manual version 1.0b_en... - Page 19 10 Guarantee INTEWA GmbH provides a 24‐month warranty for the ultrafiltration unit from the date of delivery. Please keep the proof of purchase as proof of this date. Within the warranty period, INTEWA GmbH shall provide warranty at its discretion by repair or replacement. The warranty does not cover damage caused by improper use, wear and tear or manipulation by third parties. The warranty does not cover defects that only insignificantly impair the value or usability of the appliance. ...
-
Page 20: Appendix
>6,57 Enterococcus Date Raw water after Filter 1 LRV / 100 ml / 250 ml 13.05.2017 304250 0 >5,88 Pseudomonas aeruginosa Date Raw water after Filter 1 LRV / 100 ml / 250 ml 22.05.2017 >1000 0 >3,40 AQUALOOP-direct, manual version 1.0b_en... -
Page 21: Appendix 1.2: Declaration Of Conformity Of The Membrane
Appendix 1.2: Declaration of conformity of the membrane AQUALOOP-direct, manual version 1.0b_en... - Page 22 AQUALOOP-direct, manual version 1.0b_en...
