Trigon Elektronik Exxceed Manual page 8

The following settings are available:
Level
Volume Start
Balance
Out
DAC
(6) Sensor Key MONO
This button can be used to switch the mono function on or off. If MONO is activated,
a dot appears in the lower right corner of the display before the "MONO" label. In
addition, the last LED of the volume indicator lights up.
(7) On/Off Key
If the main power switch (11) on the back of the device is switched on, the Exxceed is
switched on or off. Tap your finger on the circle icon under the label On / Off. Within
the circle, an LED is lit and as soon as you remove the finger, the Exxceed turns on
or off. When the power is off, the LED above the keypad will turn red (standby) and
green when the keypad is in the state.
During the power-up process, the color of this LED flashes between yellow and
green. As soon as the switch-on process is completed, the LED is constantly green.
REMARK: We have equipped the Exxceed with a very power saving standby power
supply. The power consumption in standby mode is less than 1 watt. You can always
connect the Exxceed to the power supply in standby mode without switching it off
completely with the mains switch (11).
If, however, you do not want to use the Exxceed for a longer period of time (holidays,
etc.), you can also switch off the power supply completely with the switch (11).
In the case of severe storms with a risk of lightning, it is also recommended to
disconnect the mains connection, ie pull the mains plug!
(8) Volume knob and volume indicator, mute function
This button is used to adjust the volume. The adjusted volume is indicated by the
LED's arranged around the volume knob.
S e ttin g s
Level
Volume Start
Balance
Out
DAC
(3.2.1)
(3.2.2)
(3.2.3)
(3.2.4)
(3.2.5)
Unity Gain
Power Management
Color
Name
Unity Gain
Power Management
Color
Name
8
(3.2.6)
(3.2.7)
(3.2.8)
(3.2.9)
