Summary of Contents for Bakers Pride DANTE XXE
- Page 1 OPERATION MANUAL DANTE SERIES GAS CHARBROILERS SERIES: XXE B U I LT BY C R A F T S M E N . T E S T E D BY T I M E ®...
- Page 2 CHARBROILER OPERATION MANUAL Models: WARNING Dante XXE Improper installation, adjustment, alteration, Bakers Pride Oven Company, LLC is a wholly owned service or maintenance can cause property subsidiary of Standex International Corporation. damage, injury or death. Read the installation, operating and maintenance instructions...
-
Page 3: Table Of Contents
XXE CHARBROILER OPERATION MANUAL TABLE OF CONTENTS INSTALLATION INSTRUCTIONS OPERATING INSTRUCTIONS INSTALLATION LIGHTING PROCEDURE CLEARANCES BROILING GAS CONNECTION MAINTENANCE BURNERS SERVICE RADIANTS CARE & CLEANING TOP GRATES CLEANING TOOLS LIGHTING INSTRUCTIONS TROUBLESHOOTING CHART GREASE PAN MANIFOLD & VALVE ASSEMBLY VIEWS GRIDDLE PLATE PARTS LIST AND EXPLODED VIEWS ADDITIONAL INSTALLATION INSTRUCTIONS... -
Page 4: Clearances
XXE CHARBROILER OPERATION MANUAL INSTALLATION INSTRUCTIONS Acceptable Clearances: When making gas pipe connections, pipe joint compound resistant to the action of liquefied petroleum (A) USA and Canada. Due to intense heat generated gases should be used. by radiation, in USA and Canada these broilers should be installed in non-combustible locations The broiler and its individual shutoff valve must be only, including the areas above the grate level. -
Page 5: Lighting Instructions
XXE CHARBROILER OPERATION MANUAL INSTALLATION INSTRUCTIONS Lighting: Water is usually added to the grease pan to reduce flare- up and flash back. The grease drip will extinguish as it Each burner has a standing pilot burner which must be hits the water. lit before the burners can be lit. -
Page 6: Operating Instructions
Bakers never be used on the cast iron grates. Pride. Contact Bakers Pride for more information. (B) Front - Sample supplied with the unit or any reputable stainless steel cleaner can be used. -
Page 7: Troubleshooting Chart
Incorrect gas type. Supply correct type gas. Incorrect gas supply pressure. Call local gas supplier. Incorrect orifices. Call Bakers Pride authorized service center. Primary air not adjusted properly. Adjust air shutter. Pilot will not remain lit Pilot flame adjusted incorrectly. -
Page 8: Manifold & Valve Assembly Views
XXE CHARBROILER OPERATION MANUAL MANIFOLD & VALVE ASSEMBLY VIEWS Figure 1: XXE Series - Front View Figure 2: XXE Series - Side View... -
Page 9: Parts List And Exploded Views
XXE CHARBROILER OPERATION MANUAL PARTS LISTS AND EXPLODED VIEWS Dante Series Model Number Serial Number Type of Gas XXE-4 Natural XXE-6 LP XXE-8 Other XXE-10 XXE-12 Note: When ordering, ALWAYS specify Part #, Model #, Serial #, Voltage/Phase & type of Gas. - Page 10 XXE CHARBROILER OPERATION MANUAL PARTS LISTS AND EXPLODED VIEWS EXPLODED VIEW – XXE-4, 6, 8, 10, 12 Note: When ordering, ALWAYS specify Part #, Model #, Serial #, Voltage/Phase and Gas Type.
- Page 11 Grease Pan (XX-10) 19 1/4", 1 used G1461K Outer Back (XXE-4) T1036T Grease Pan (XX-12) 19 1/4", 3 used G1462K Outer Back (XXE-6) U1043A Name Plate, 13 1/4", Bakers Pride G1463K Outer Back (XXE-8) S1394A Leg, 4" Adjustable (Each) G1464K Outer Back (XXE-10) S1394X Leg, 4"...
- Page 12 XXE CHARBROILER OPERATION MANUAL PARTS LISTS AND EXPLODED VIEWS EXPLODED VIEW – XXE-4, 6, 8, 10, 12 Burner / Accessories Item Part No. Description Item Part No. Description R1085P Manifold Assy (XXE-4) N1010A Ferrule, 3/16" R1086P Manifold Assy (XXE-6) R3130A Orifice Hood #44, Nat (XXE) R1087P Manifold Assy (XXE-8)
-
Page 13: Warranty
Bakers Pride Factory Authorized Service Center. This Warranty is in lieu of all other warranties, expressed or implied, and all other obligations or liabilities on the manufacturer’s part. Bakers Pride shall in no event be liable for any special, indirect or consequential damages, or in any event for damages in excess of the purchase price of the unit. - Page 14 Food Service Equipment Group The Standex Food Service Equipment Group (FSEG) is a manufacturer of innovative commercial food service equipment offering a wealth of refrigeration and cooking expertise. Products include walk-in coolers and freezers; hot and cold display cabinets, cases, and storage systems; commercial ovens, rotisseries, and cooking equipment;...
