WIRING PODVIEW

®
PodView ® and EchoPod
between PodView ® and EchoPod
®
EchoPod
Note: Wiring is identical for all EchoPod
1. Connect the Red and Black wires of both PodView
2. Connect the Green and White wires of PodView
® . Note: Isolate the Green and White wires from active power to prevent a short of the
EchoPod
configuration circuit.
Electrical Connections, Usage and Safety
Where personal safety or significant property damage can occur due to a spill, the installation must
•
have a redundant backup safety system.
Wiring should always be completed by a licensed electrician.
•
The indicator supply voltage should never exceed 28 VDC.
•
Protect the indicator from electrical spikes by isolating the power.
•
Design a fail-safe system for possible indicator and/or power failure.
•
Never use the indicator in environments classified as hazardous.
•
| 4
® require a 12 to 28 VDC power supply to operate. The maximum cable distance
® is 15' (4.5m). Follow the below steps to wire PodView
® series. Only use the Red, Black, Green and White wires.
® ®
and EchoPod to the 12-28 VDC power supply.
®
to the corresponding Green and White wires of
® with EchoPod ® .
®
PodView
