- Page 1 Vertical Edge 9200 Series Quick Installation Guide Please read this user guide carefully before operating your set. Retain it for future reference.
-
Page 2: Important Safety Information
Caution: Use only Vertical Communications approved batteries and desktop chargers to avoid the damage to the phone. Using other batteries or chargers voids your warranty and may cause an explosion. - Page 3 [EU] European Union Declarations of Conformity Vertical Communications declare that the equipment specified in this document bearing the “ CE” mark conforms to the European Union Radio and Telecommunications Terminal Equipment Directive(R&TTE 1999/5/EC), including the Electromagnetic Compatibility Directive(2004/108/EC) and Low Voltage Directive(2006/95/EC).
- Page 4 Vertical Edge 9200 Series Phone (1) This device may not cause harmful interference; and (2) This device must accept any interference received, including interference that may cause undesired operation. (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le...
- Page 5 Fixed or Flexible buttons or by selecting a menu item using the Soft buttons. Edge 9200 8-Button Phone does not support Soft button menu. So you have to assign the Flexible button using Feature code if you need to be operated.
-
Page 6: Phone Layout And Functions
Vertical Edge 9200 Series Phone 1.2 Phone Layout and Functions Figure 1 Edge 9200 8-Button Phone Figure 2 Edge 9200 24-Button Half Duplex Phone... - Page 7 Vertical Edge 9200 Series Phone Figure 3 Edge 9200 24-Button Full Duplex Phone Figure 4 Edge 9200 40-Button Phone...
- Page 8 Edge 9200 40-Button Phone has 2*12-flexible buttons. Soft keys: Soft keys are interactive, changing function based on the status of Edge 9200 24-Button & 40-Button Phone. Edge 9200 8-Button Phone does not support Soft keys. Navigation key for Edge 9200 40-Button Phone ...
-
Page 9: Dss Console
Vertical Edge 9200 Series Phone Fixed buttons Edge 9200 8-Button Phone does not support some buttons: Flash, Directory, and Headset among the below buttons. Flash button: U se to seize the new line without on-hook. So you can make a call by dialing the desired number. -
Page 10: Wall Mount
Vertical Edge 9200 Series Phone Edge 9200 series have 3 connection ports (refer to following figure). Each port is for connecting to: Handset, Ear Mic. headset, and the line cable. 1) Connect the telephone cord (curly cord) to the handset and the other end to the handset jack at the bottom of the telephone. - Page 11 Vertical Edge 9200 Series Phone LDP-9200 series phones can be mounted on the wall as needed. The following instructions describe the wall mount installation. Note the foot-stand must be removed. If installed, remove the foot-stand from the Phone and DSS.
-
Page 12: Dss (Direct Station Selection) Console Installation
A DSS console can be installed with Edge 9200 series phone. As we described the available DSS for each phone, the available DSS is as below: Edge 9200 8-Button Phone: no DSS Edge 9200 24-Button Phone: Edge 9200 48-Button Direct Station Selection ...
