  • Page 5 I N S TA L L AT I O N MA N UA L Single Lever Pull-Down Kitchen Faucet KPF-1630 www.kraususa.com I toll free: 1.800.775.0703 I © 2013-2014 Kraus USA Inc.
  • Page 6 Thank you for your purchase We would like to take this opportunity to thank you for choosing Kraus. We hope that you are completely satisfied with your purchase, and enjoy it for years to come. If you have any questions, or require technical assistance, please contact us at 800-775-0703 and one of our representatives will be happy to help.

  • Page 7: Prior To Installation

    Prior to Installation: • Make sure you have all necessary parts by checking the diagram and parts list. If any part is missing or damaged, please contact Kraus Customer Service at 800-775-0703 for a replacement • Turn off the cold and hot water at the angle stops and turn on the old faucet to release any built up pressure •...
  • Page 8 Diagram and Parts List...
  • Page 9 Diagram and Parts List Tools you will need 1. Spray Head 2. Faucet Body Adjustable Wrench 3. Deck Plate Assembly A. Deck Plate B. Base Plate 4. Mounting Hardware A. Rubber & Metal Washer B. Mounting Nut Silicone Sealant C. Mounting Screws (optional) 5.
  • Page 10 Faucet Installation Procedure 8.3” 8.3” (211.4mm) (211.4mm) 3.95” 3.95” (100.5mm) (100.5mm) M33X1.5 M33X1.5 Installer Tip: Shut off main water supply before installing new faucet...
  • Page 11 STEP1 STEP 2A STEP 2B Step 1: Remove mounting hardware Remove the mounting screws (4C), mounting nut (4B), and rubber & metal washer (4A) from the mounting pipe STEP 2A STEP 2B Step 2A: Faucet installation - with deck plate For three-hole installation: STEP 4 STEP 5...
  • Page 12 STEP 2B STEP 3 Step 2B: Faucet installation - without deck plate For single-hole installation: Deck plate (3A), base plate (3B), and silicone sealant are NOT required STEP 3 Step 3: Install faucet and mounting hardware Insert faucet body (2) into hole in countertop or deck plate assembly (3).
  • Page 13 STEP 4 STEP 5 Step 4: Secure mounting hardware Adjust direction of faucet body (2) so that handle is on right side of faucet. Tighten mounting nut (4B) until snug. Tighten mounting screws (4C) to nut with a Phillips screwdriver until snug STEP 5 STEP 6 Step 5: Attach spray hose and counterweight...

  • Page 14: Step 8 Check For Leaks

    STEP 6 STEP 7 Step 6: Connect waterlines Connect waterlines (not included) to hot and cold copper lines (8). Connect waterlines (not included) to angle stops. Tighten both ends of waterlines with a wrench until snug. Turn on hot and cold angle stops and check for leaks STEP 4 STEP 5...

  • Page 15: Replacement Parts

    Replacement Parts a. Aerator b. Spray Head Check Valve Spray Hose Hose Guide Hexagon Nut Handle Button Set Screw Metal Handle Cartridge Cover Locking Nut 10. Cartridge 11. Cartridge Housing Cold 12. Deck Plate Water Water 13. Base Plate 14. Rubber & Metal Washer 15.

  • Page 16: Troubleshooting

    Trouble - Shooting If you have followed the instructions carefully and your faucet still does not work properly, take the following corrective steps: P R O B L E M C A U S E A C T I O N Leakage under faucet Locking nut has come Remove button located...
  • Page 17 Maintenance - Cartridge Replacement Step 1: Remove button located at the top of the handle. Loosen the set screw with a hex wrench. Remove the handle and unscrew cartridge cover by hand Step 2: Unscrew the locking nut with an adjustable wrench.

  • Page 18: Conditions And Exclusions

    If Kraus is unable to provide a replacement and repair is not practical or cannot be made in timely fashion, Kraus may elect to refund the purchase price in exchange for the return of the product.
  • Page 19 NON-APPLICABILITY OF THIS WARRANTY By the purchase and use of our products, you agree that Kraus is not liable for incidental, consequential or special damages associated with the return, replacement, installation or use of your product. This includes freight costs,...
  • Page 20 www.kraususa.com...
  • Page 21 I N S TA L L AT I O N MA N UA L Soap Dispensers KSD-30 KSD-33 KSD-35 KSD-41 KSD-42 SD-20 SD-25 www.kraususa.com I Toll Free: 1.800.775.0703 I © 2014-2015 Kraus USA Inc. I REV. August 16, 2016...
  • Page 22 Thank you for your purchase We would like to take this opportunity to thank you for choosing Kraus. We hope that you are completely satisfied with your purchase, and enjoy it for years to come. If you have any questions, or require technical assistance, please contact us at 800.775.0703 and one of our representatives will be happy to help.
  • Page 23 Toll-Free: 800.775.0703 or Customerservice@kraususa.com The step-by-step guidelines in the installation instructions are a general reference for installing a Kraus Sink. Should there be any discrepancies, Kraus cannot be held liable. It is recommended to install all Kraus products by hiring a licensed professional.

  • Page 24: Tools Required

    GDA-1 Diagram and Parts List: a. Pump b. Dispenser Base c. Rubber Washer A d. Rubber Washer B e. Mounting Nut f. Dispenser Bottle TOOLS REQUIRED: *Adjustable Wrench...
  • Page 25 Step 1 Disassemble soap dispenser...
  • Page 26 Step 2 Install dispenser base (b) with rubber washer A (c) attached into the hole in the countertop. Re-install rubber washer B (d) and mounting nut (e) on the dispenser base (b) from underneath the countertop. Tighten mounting nut (e) with adjustable wrench until snug...
  • Page 27 Step 3 Screw the dispenser bottle (f ) to the dispenser base (b) from underneath the countertop. Tighten as required. Fill the dispenser bottle (f ) from the top with 12 ounces of soap...
  • Page 28 Step 4 Insert pump (a) into dispenser base (b) from the top. Press the pump several times to make sure soap is evenly distributed Press...
