Technical Specification

®
DERMALUX TRI-WAVE
Weight: 24kg
Total Device Dimensions: H 1750mm x W (widest point at base) 520mm x D 720mm
Dimension from to front to back at the widest point: 820mm
Dimensions of LED head: H 460mm x W 500mm x D 340mm
Dimensions of LED Body panel:
Program time range: 1 to 30 minutes
Operating Temperature 0°C to 85°C
Storage and Transport Temperature -40°C to 70°C
Operating Humidity: 5% to 95% without condensation
Storage and Transport Humidity: 5% to 95% without condensation
Mains Electrical Input: 85-264Vac/47-63Hz
Electrical Output: 24V

General Safety

The Dermalux
certain circumstances could present an electrical shock hazard to the
user.
Please read the accompanying user manual thoroughly and follow
directions stated in the manual to assure maximum safety during
operation.
Dermalux Triwave User Guide 2015
L 690mm x W 333mm x H 80mm
®
Tri-Wave system is an electrical device, which under
