Dermalux Tri-Wave User Manual page 21

STEP 2. POSITIONING the LED Treatment Head
4. Using the LED head positioning buttons position the treatment head
5. Press the LED head positioning button
or down to lower the LED treatment head.
6. Position the LED treatment head 4 cm from the treatment area
Do NOT Position the treatment head less than the recommended distance
from the treatment area. Over extension of the lift arm may cause
temporary disconnection of the treatment head
STEP 3. ACTIVATING the Dermalux
7. Press the START/STOP button, the selected
LEDs will illuminate
8. The timer will count down in 1 minute intervals
showing the time remaining for each selected
wavelength
When using Near Infrared (NIR) the NIR indicator diodes will illuminate
yellow. The NIR indicator diodes are positioned at the top of each LED
panel.
END of Treatment
9. At the end of the treatment the LEDs will switch OFF.
10. The display
indicating the wavelengths delivered and the
treatment time for each wavelength.
11. Using the LED head positioning button raise the
treatment head away from the treatment area.
12. Press the LED head positioning button up to raise
the LED treatment head away from the treatment area
13. Remove the client's safety goggles
Dermalux Triwave User Guide 2015
®
Tri-Wave System
shows a treatment
up to raise the LED treatment head
summary
