STEP 2. Connecting the LED Treatment Head
9. Connect the LED treatment head to the height control arm.
10. Align the holes in LED head and height
control arm.
11. Secure with the black locking bolt.
12. Attach the white cable to the LED treatment head with
the 4 pin connector.
STEP 3. Connecting the Dermalux
13. Plug the black Power Cable into the 3 pin input socket in the rear of the Base unit
14. Plug the Power Cable into a suitable wall socket.
Dermalux Triwave User Guide 2015
®
Tri-Wave LED system to the mains
