INSTRUCTION MANUAL
Cordless Impact Wrench
DTW284
DTW285
Read before use.

Advertisement

Table of Contents
loading

Related Manuals for Makita DTW284

Summary of Contents for Makita DTW284

  • Page 1 INSTRUCTION MANUAL Cordless Impact Wrench DTW284 DTW285 Read before use.

  • Page 2: Specifications

    1.5 kg 1.7 kg without notice. Symbols Vibration ment. Be sure that you understand their meaning before use. Model DTW284 Read instruction manual. mum capacity of the tool Vibration emission (a Model DTW285 Ni-MH Do not dispose of electric equipment or...

  • Page 3: Ec Declaration Of Conformity

    of inattention while operating power tools may result in EC Declaration of Conformity Use personal protective equipment. Always For European countries only wear eye protection. as dust mask, non-skid safety shoes, hard hat, or to this instruction manual. hearing protection used for appropriate conditions Prevent unintentional starting.
  • Page 4 Check the torque with a torque wrench. also void the Makita warranty for the Makita tool and SAVE THESE INSTRUCTIONS. charger. WARNING:...

  • Page 5: Functional Description

    Battery protection system FUNCTIONAL DESCRIPTION Lithium-ion battery with star marking CAUTION: Always be sure that the tool is switched off and the battery cartridge is removed before adjusting or checking function on the tool. Installing or removing battery cartridge CAUTION: Always switch off the tool before installing or removing of the battery cartridge.
  • Page 6 If the status will not change, stop using and have the tool repaired by a Makita local service center. NOTE: NOTE: Depending on the conditions of use and the ambient temperature, the indication may differ slightly this case, cool down the tool before operating again.
  • Page 7 Lighting up the front lamp Reversing switch action CAUTION: Do not look in the light or see the source of light directly. 1. Reversing switch lever CAUTION: Always check the direction of 1. Lamp rotation before operation. CAUTION: Use the reversing switch only after the tool comes to a complete stop.
  • Page 8 Changing the impact force/mode medium, soft, and reverse rotation auto stop mode. trigger, the impact force can be changed. Hard, Medium, and Soft impact mode allows a tighten- ing suitable to the work. only with pulling the trigger fully in counterclockwise tool tool stops the impact and rotation.

  • Page 9: Operation

    Installing or removing impact socket Installing hook CAUTION: Make sure that the impact socket and the mounting portion are not damaged before installing the impact socket. CAUTION: After inserting the impact socket, do not use it. For impact socket without O-ring and pin 1.
  • Page 10 Model DTW284 Proper fastening torque for high tensile bolt Proper fastening torque for standard bolt M16H M16H M14H M14H M 20 M 20 M12H M12H M 16 M 16 M 12 M 12 1. Fastening time (second) 2. Fastening torque 1.

  • Page 11: Maintenance

    OPTIONAL ACCESSORIES CAUTION: These accessories or attachments are recommended for use with your Makita tool accessories or attachments might present a risk of for its stated purpose. If you need any assistance for more details regard- ing these accessories, ask your local Makita Service Center.
  • Page 12 Jan-Baptist Vinkstraat 2, Makita Europe N.V. 3070 Kortenberg, Belgium 3-11-8, Sumiyoshi-cho, Makita Corporation Anjo, Aichi 446-8502 Japan 885531-224 www.makita.com 20160615...
