- Page 1 AR6MX- Series Quick Start Guide Ver 0.1 This Quick Start Guide is for BCM AR6MXQ (Quad Core) and AR6MXS (Solo Core) ARM motherboards based on Freescale i.MX6 Cortex A9 platform.
- Page 2 1. Mainboard illustration: Locations of IO ports & Jumper settings definition Board Top view： AR6MXQ / AR6MXS Quick Start Guide Page 2...
- Page 3 1.1 Getting started 1. Insert the SD card into slot CN24. Note: do not force the card into the slot; it should go in with moderate pressure 2. Connect an HDMI monitor to CN21 AR6MXQ / AR6MXS Quick Start Guide Page 3...
- Page 4 3. Connect a USB mouse/keyboard either to the rear I/O USB connectors (CN18), or through the onboard header CN6 (USB cable not included) AR6MXQ / AR6MXS Quick Start Guide Page 4...
- Page 5 Set your terminal settings to the following: 115200 bps, 8bits, no parity, 1 stop bit, and no flow control 5. Connect the power adapter to CN20 6. Plug in the power adapter to an outlet and the board will boot up AR6MXQ / AR6MXS Quick Start Guide Page 5...
- Page 6 Jumper selector BOOT MODES 00(JP3:2－3、JP7:2 －3) Boot from fuses 01(JP3:1－2、JP7:2 －3) Serial downloader 10(JP3:2－3、JP7:1 Boot from board －2) settings Connector type：HDR 1X3 2.0mm Connector type：HDR 1X3 2.0mm Definition Definition D12V L0_PWR BL0_PWR D3V3 AR6MXQ / AR6MXS Quick Start Guide Page 6...
- Page 7 USBDOM RESET BUTTON 3－5、4－6 USBPCI CN1 : LVDS1 LVDS CONN. Connector type：HIROSE DF13A-30DP-1.25 Definition Definition Definition LBL1_PWR LVDS _TX3_P LBL1_PWR LVDS1_TX2_P LVDS1_TX3_N LVDS1_SDA LVDS1_TX2_N LVDS1_TX0_P BL1EN LVDS1_SCL LVDS1_CLK_P LVDS1_TX0_N LBL1_PWM LVDS1_CLK_N LVDS1_TX1_P AR6MXQ / AR6MXS Quick Start Guide Page 7...
- Page 8 DSI0_SCL DSI_CLK0P DSI_D0P DSI_PWM DISP_RST_B DSI_CLK0M DSI_D1P DSI_MCLK CSO_PWR2 DSI_D1M CSO_PWR2 CN4：MIPI CSI Conn Connector type：HIROSE DF13A-30DP-1.25 Definition Definition Definition CSI_PWR1 CSI_D3M CSI_PWR3 CSI_PWR1 CSI_D2P CSI_D3P CSI0_SDA CSI_D2M CSI_D0P BL3EN# CS 0_SCL AR6MXQ / AR6MXS Quick Start Guide Page 8...
- Page 9 HDMI_D2P HDMI_CEC_OUT NDCDA NRTSA NRXA NCTSA HDMI_D2M H_CLK_OUT NTXA NRIA HDMI_D1P H_DAT_OUT NDTRA HDMI_D1M HDMI_5V_OUT NDSRA HDMI_D0P HP_DET_OUT HDMI_D0M HDMI_CLKP HDMI_CLKM CN19：LAN Conn CN22：SPK OUT Connector type：RTA-164AAK1A Connector type：3.5mm Phone Jack Green AR6MXQ / AR6MXS Quick Start Guide Page 9...
- Page 10 CN5：DIGITAL IO CONN Connector type：HDR Wafer 1x4 2.5mm Connector type：HDR 2x5 2.0mm DIP Definition Definition Definition DIO0 DIO6 D12V DIO3 DIO1 DIO5 D3V3 DIO7 DIO2 DIO4 CN11：USB-0 FOR USB DOM CN16：SIM Card Slot AR6MXQ / AR6MXS Quick Start Guide Page 10...
- Page 11 PCIE_3V3 PCIE_3V3 CCIO PCIE_RXP CLK1_N PCIE_3V3 CCCLK CLK1_P D1V5 CCRST MPCIE_SCL CN12：JTAG Connector type：HDR 2x10 2.0mm DIP Definition Definition Definition Definition JTAG_VREF JTAG_RTCK JTAG_PWR JTAG_TMS JTAG_DE JTAG_nTRST JTAG_TDO JTAG_TCK JTAG_DACK JTAG_TDI JTAG_nSRST AR6MXQ / AR6MXS Quick Start Guide Page 11...
