- Page 1 Part A, Section 2 Overview This section covers the following unit configurations. Model 3100 Voltage Pump AC Gear (k or L) Manifold 2-Port (J) Control E 2000 Nordson Corporation A2EN-02-[3-OVER]–2 41-3000 All rights reserved Issued 11/00...
- Page 2 A 2-0 Overview E 2000 Nordson Corporation A2EN-02-[3-OVER]–2 41-3000 All rights reserved Issued 11/00...
- Page 3 Overview Section A 2 Overview The Series 3100 melter is the main component of the hot melt system. 1. Introduction The melter liquefies the adhesive, maintains it at the setpoint (operating) temperatures, and pumps it through hoses to dispensing guns. The guns apply the adhesive to the surface of the product or package.
- Page 4 The gun applies the adhesive to the product or package surface. Figure A 2-2 shows the path that melted adhesive follows as it flows through the system. E 2000 Nordson Corporation A2EN-02-[3-OVER]–2 41-3000 All rights reserved...
- Page 5 Adhesive Flow Path of a Typical Gear Pump System 1. Typical motor 5. Manifold 8. Hose 2. Tank 6. Filter 9. Drain valve 3. Gear pump 7. Gun 10. Pressure control valve 4. Pressure relief valve E 2000 Nordson Corporation A2EN-02-[3-OVER]–2 41-3000 All rights reserved Issued 11/00...
- Page 6 The tank holds a large supply of adhesive and melts it before it is pumped to the hoses and guns. Series 3100 melters have a tank only. The term “tank” is used to mean the tank strainer, and the melting fins collectively, including the location of the tank and grid heater connectors.
- Page 7 1. Pressure relief valve 4. Hose ports 7. Circulation control valve 2. Standard manifold filter 5. Reverse-flush filter 8. Air-piloted pressure control valve 3. Drain valve 6. Pressure control valve E 2000 Nordson Corporation A2EN-02-[3-OVER]–2 41-3000 All rights reserved Issued 11/00...
- Page 8 NOTE: The Installation section provides detailed procedures for customizing the control system, and the Operation section provides detailed procedures for operating and monitoring the control panel. 4131146A Fig. A 2-6 MultiScan Control Panel E 2000 Nordson Corporation A2EN-02-[3-OVER]–2 41-3000 All rights reserved Issued 11/00...
- Page 9 Melters with a digital readout have a numerical light-emitting diode (LED) display of the temperature of the heated zones. Temperature can be displayed in either °C or °F. A STEP/HOLD/SCAN switch is used to set how the temperatures are displayed. E 2000 Nordson Corporation A2EN-02-[3-OVER]–2 41-3000 All rights reserved...
- Page 10 Electric Line Filter The electric line filter reduces electrical noise conducted by the input power source. Refer to Electric Line Filter in the Options section for more information about the electric line filter. E 2000 Nordson Corporation A2EN-02-[3-OVER]–2 41-3000 All rights reserved...
- Page 11 The melter configuration code appears on the identification plate on the melter. This code indicates the type of melter and the features of the melter, and must be provided to Nordson in order to receive correct service information or parts.
- Page 12 A 2-10 Overview Understanding the Melter Configuration Code (contd.) 4130667A Fig. A 2-7 Location of Melter Configuration Code E 2000 Nordson Corporation A2EN-02-[3-OVER]–2 41-3000 All rights reserved Issued 11/00...
- Page 13 DC gear pump, 24.5 kg/hr (54 lb/hr) DC gear pump, 11 kg/hr (24 lb/hr) DC gear pump, 24.5 kg/hr (54 lb/hr) DC gear pump, 3.6 kg/hr (8 lb/hr) DC gear pump, 1.8 kg/hr (4 lb/hr) E 2000 Nordson Corporation A2EN-02-[3-OVER]–2 41-3000 All rights reserved Issued 11/00...
- Page 14 I/O board, gear pump melters (MultiScan only) English/Japanese language tags Pressure dump (motor and pressure control only) Motor and pressure control (MultiScan only) CE certification Key-to-line control (MultiScan only) Electric line filter E 2000 Nordson Corporation A2EN-02-[3-OVER]–2 41-3000 All rights reserved Issued 11/00...
- Page 15 2-port U 2-port R 2-port NOTE An X is a placeholder in the the manual configuration code used to denote data that is not pertinent to the manual configuration. E 2000 Nordson Corporation A2EN-02-[3-OVER]–2 41-3000 All rights reserved Issued 11/00...
- Page 16 A 2-14 Overview E 2000 Nordson Corporation A2EN-02-[3-OVER]–2 41-3000 All rights reserved Issued 11/00...
