Enttec DMXIS Quick Start Manual

Box Contents

DMXIS (pn: 70570)
•
USB Cable (pn: 79110)
•
This user manual
•
DMXIS App on CD (pn: 79117)
•
Features
Full 512 DMX channel universe of output
•
Fully compliant with USITT DMX512-A
•
USB 2.0 Support on Windows PC and Mac OSX
•
1500 V full isolation (data & power lines to
•
protect your computer from surges)
Supports Windows XP/Vista/7/8 and Mac OSX
•
10.7 or later (drivers released and maintained by
FTDI)
Hardware style user interface is quick to learn and
•
easy to use
Controls any DMX-512 compatible light fixture,
•
including classic dimmer packs, LED fixtures, and
intelligent lighting (e.g. scanners & moving
heads)
Create static looks, dynamic chases & moving
•
effects with smooth cross-fades
Intuitive tempo-based approach, for perfect
•
synchronisation of lighting & music
ENTTEC DMXIS
( P N 7 0 5 7 0 )
Safety
Basic Setup
Runs as a standalone program, VST plug-in, or Audio
•
Unit plug-in (supported Apps
Do not expose the DMXIS unit to rain or moisture,
•
doing this will void the warranty
Do not remove the cover, there are no serviceable
•
parts inside
This unit is intended for indoor use only
•
Wherever possible, use with a DMX Splitter for
•
safety and better reliability with DMX cables.
Install and configure the DMXIS software on your
•
Windows™ or Mac™ computer.
Connect the DMXIS hardware interface box to your
•
computer with a USB cable.
Connect the DMX output (either 3 pin or 5 pin) of
•
the interface box to the "DMX IN" XLR socket on
your first light fixture
Connect "DMX OUT" of the first fixture to "DMX IN"
•
of the next fixture. Continue connecting all
remaining light fixtures together in a daisy-chain
fashion.
Connect a DMX terminator plug to the DMX OUT of
•
the last fixture.
Quick Start Manual
MANUAL-DMXIS
for more information visit:
www.enttec.com/dmxis
only)
1
