Delwood 61" Fireplace Console
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our toll-free customer service number and have your
instructions and parts list ready to provide the model name, part name or factory number:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
Model # WSF61DL26C-AC
# WSF61DL26C-DA
ADULT ASSEMBLY REQUIRED
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
Or visit our website www.whalenfurniture.com
Or e-mail your request to:
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Date 2017-06-16 Rev. 0001-A Factory: DGSFCL
1-866-942-5362
parts@whalenfurniture.com
LOT NUMBER:
DATE PURCHASED: /
/
Advertisement
Related Manuals for Whalen WSF61DL26C-AC
Summary of Contents for Whalen WSF61DL26C-AC
- Page 1 LOT NUMBER: DATE PURCHASED: / Delwood 61" Fireplace Console Model # WSF61DL26C-AC # WSF61DL26C-DA ADULT ASSEMBLY REQUIRED If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased. Please call our toll-free customer service number and have your...
-
Page 2: Special Note
M A X I M U M R E C O M M E N D E D W E I G H T L O A D S MANUFACTURER: Whalen Furniture Manufacturing CATALOG: Delwood 61" Fireplace Console MODEL # WSF61DL26C-AC / WSF61DL26C-DA MADE IN CHINA FITS UP TO MOST 177.8 cm / 70 in. - Page 3 IMPORTANT Before you begin: Open, identify and count all parts prior to assembly. Lay out parts on a flat and non- abrasive surface. You will need the parts identified on page 4 and 5 of this instruction manual. NOTE: IT IS VERY IMPORTANT TO USE GLUE WITH THE DOWELS. EXCESS GLUE CAN BE WIPED OFF WITH A DAMP CLOTH.
- Page 4 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. A- Top Panel (Qty. 1) B-Top Front Stretcher (Qty. 1) C- Side Panel (Qty. 2) D- Left Partition Panel (Qty. 1) E- Right Partition Panel (Qty.
- Page 5 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. (1) Cam Lock (2) Cam Bolt (3) M8 x 30 mm Wood Dowel (Qty. 24+1 extra) (Qty. 24+1 extra) (Qty.
-
Page 6: Assembly Instructions
Assembly Instructions 1. Unpack the unit and confirm that you have all the hardware and required parts. Assembly the unit on a carpeted floor or the empty carton to avoid any scratch. 2. Insert two Wood Dowels (3) into the large holes on the Left Partition Panel (D). Tap in with a rubber mallet, if necessary. - Page 7 Assembly Instructions 5. Securely screw the Cam Bolts (2) into the designated small holes on the Top Panel (A) and the both Partition Panels (D and E) using a Phillips screwdriver. 6. Securely screw the Cam Bolts (2) into the designated small holes on the Base (H). 7.
- Page 8 Assembly Instructions 8. Attach the Middle Crossbar (G) to the Center Shelf (F) with two Wood Dowels (3) and three 35 Screws (6) making sure the pilot holes will face the back of the unit. 9. Glue four 30 mm Wood Dowels (3) into the inner holes of the Top Front Stretcher (B) and attach it to the Top Panel (A) by engaging four Cam Locks (1) (Refer to page 3 on Cam Lock system operation supplement).
- Page 9 Assembly Instructions 10. Align and attach the Center Shelf (F) between the Partition Panels (D and E) with four Wood Dowels (3) and four Cam Locks (1). 11. Attach the assembled Partition Panels (D and E) to the Top Panel (A) with four Wood Dowels (3) and four Cam Locks (1).
- Page 10 Assembly Instructions 12. Attach the Side Panels (C) to the Top Panel (A) with four Wood Dowels (3) and four Cam Locks (1). 13. Attach the Base (H) to the bottom of the vertical panels (C, D and E) with eight Wood Dowels (3) and eight Cam Locks (1).
- Page 11 Assembly Instructions 14. Flip the assembled unit around at its front edges. 15. With the pilot holes as a guide, fasten two Straight Metal Brackets (7) at the joints between the Middle Crossbar (G) and the both Middle Stiles (P), using two 12 mm Flat Head Screws (4) per bracket. 16.
- Page 12 Assembly Instructions 18. Now, go back and securely tighten all the Cam Locks and the Screws. Make sure that all the parts are tight and there are no gaps between the parts. This will help keep the unit square. 19. Pick up the Middle Back Panel (M) and align the pre-drilled holes against the upper long edge with the pilot holes on the back stretcher of the Top Panel (A).
- Page 13 Assembly Instructions 22. The Doors (J and K) of this unit are shipped with the glass insert panel. You can keep the doors as they are, or interchange the insert panel with the wood panel (N), depending on the desired configuration. 23.
- Page 14 Assembly Instructions 25. Hang the four Door Rollers (11) onto the pre-attached hanging bar on the Top Front Stretcher (B) and fasten to the both Doors (J and K) with the provided 15 mm Bolts (12). 26. Stand the unit upright. 27.
- Page 15 Assembly Instructions 29. Lift the fireplace insert carefully into the back of the assembled mantel and center it in the opening. drag the insert across the Base (H) as it may scratch the unit. Electric Firebox 30. Using the pilot holes as a guide, align and attach two L-shaped Metal Braces (17) to the Base (H) by screwing one Washer Head Screw (5) in each.
- Page 16 Assembly Instructions Electric Firebox NOTE: You must install the Acrylic TV Stopper to prevent the TV from tipping when placing your flat panel television directly on the console. 31. Remove the paper backing from the Acrylic Stopper (15), then properly align the Acrylic Stopper into the cut-out on the acrylic stopper template on the Top Panel (A).
-
Page 17: Quality Guarantee
Should this product be defective in workmanship or materials or fail under normal use, we will repair or replace it for up to one (1) year from date of purchase. Every Whalen Furniture product is designed to meet your highest expectations. We guarantee that you will immediately see the value of our fine furniture.
