Leland 42" Fireplace Console
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our toll-free customer service number and have your
instructions and parts list ready to provide the model name, part name or factory number:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
Model # WSF42OW23W
ADULT ASSEMBLY REQUIRED
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
Or visit our website www.whalenfurniture.com
Or e-mail your request to:
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Date 2016-05-27 Rev. 0001-A Factory: DOCHDI
1-866-942-5362
parts@whalenfurniture.com
LOT NUMBER:
DATE PURCHASED: /
/
Advertisement
Related Manuals for Whalen WSF42OW23W
Summary of Contents for Whalen WSF42OW23W
- Page 1 LOT NUMBER: DATE PURCHASED: / Leland 42" Fireplace Console Model # WSF42OW23W ADULT ASSEMBLY REQUIRED If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased. Please call our toll-free customer service number and have your...
- Page 2 M A X I M U M R E C O M M E N D E D W E I G H T L O A D S MANUFACTURER: Whalen Furniture Manufacturing CATALOG: Leland 42" Fireplace Console (WSF42OW23W) MADE IN CHINA FITS UP TO MOST 50”...
-
Page 3: Parts And Hardware List
Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. A- Top Panel (Qty. 1) B- Top Corner Extension (Qty. 1) C- Upper Left Side Frame (Qty. 1) D- Upper Right Side Frame (Qty. - Page 4 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. P- Back Panel (Qty. 1) Fireplace Insert (Qty. 1) Remote Control with Battery (Qty. 1) (1) Ø1/4” x 5/8” Bolt (2) Ø1/4”...
-
Page 5: Assembly Instructions
Assembly Instructions 1. Unpack the unit and confirm that you have all the hardware and required parts. Assembly the unit on a carpeted floor or the empty carton to avoid any scratch. 2. Glue two Wood Dowels (5) into the inner holes on one Lower Side Panel (F) and attach it to the Left Front Panel (G) with two 1-1/4”... - Page 6 Assembly Instructions 5. Glue four Wood Dowels (5) into the drilled holes on the Center Crossbar (I) at both ends and attach it between the Left and Right Front Panels (G and H) as shown. Insert two 12 mm Screws (6) through the Small Metal Brackets (9) and screw into the Front Panels (G and H).
- Page 7 Assembly Instructions 8. Glue eight Wood Dowels (5) into the non-threaded holes on the Base (J). 9. Position the previous assembly onto the inserted Wood Dowels (5) on the Base (J) and attach in place with six 1-1/4” Bolts (2) and six Washers (3 and 4). 10.
- Page 8 Assembly Instructions 12. Using the pilot holes as a guide, fasten two Hooks (12) to the upper corners of the Barrister Door (L) with four 12 mm Screws (6) as shown. 13. Attach one Knob (8) to the front side of the Barrister Door (L) with one Knob Bolt (10). NOTE: The Barrister Door is shipped with the Speaker Grill (N).
- Page 9 Assembly Instructions 15. Hook the Barrister Door (L) onto the pre-attached plastic slides on the Upper Side Frames (C and D). 16. Glue six Wood Dowels (5) into the top holes on the Upper Side Frames (C and D). 17. Position the Top Panel (A) onto the inserted Wood Dowels (5) and fasten in place with four 1-1/4” Bolts (2) and four Washers (3 and 4).
- Page 10 Assembly Instructions 18. Now, go back and securely tighten all the Cam Locks and the Screws. Make sure that all the parts are tight and there are no gaps between the parts. This will help keep the unit square. 19. Pick up the Back Panel (H) and align the pre-drilled holes against the upper long edge with the pilot holes on the back stretcher of the Top Panel (A).
- Page 11 Assembly Instructions 21. Using the pilot holes as a guide, fit four Large Metal Brackets (13) to the side plates of the fireplace insert and fasten in place with eight 15 mm Washer Head Screws (7). 21mm 27mm 27mm 21mm 22.
- Page 12 Assembly Instructions 21mm 27mm 23. Attach three Plastic Connectors (14) to the Top Corner Extension (B) with three 5/8” Bolts (1) as shown. 24. Attach the long end of the Corner Support (K) to the Top Corner Extension (B) with one 5/8” Bolt (1).
- Page 13 Assembly Instructions 25. Glue four Wood Dowels (5) into the drilled holes on the back edge of the Top Panel (A). Attach the assembled Corner Extension to the Top Panel (A) and the Base (J) with four 5/8” Bolts (1). NOTE: You must install the Acrylic TV Stopper to prevent the TV from tipping when placing your flat panel television directly on the console.
- Page 14 Assembly Instructions Tools required: Phillips screwdriver, Power Drill, 3/8” Drill Bit and Rubber Mallet. 28. Ask for assistance to position the assembled fireplace at the desired location against a wall. If necessary, adjust the pre-attached Floor Levelers at the bottom of the Base (J) to level the unit. Now, follow the instructions printed on the plastic bag containing the Tipping Restraint Hardware to attach the tip-over restraints to the unit and the wall.
-
Page 15: Quality Guarantee
Should this product be defective in workmanship or materials or fail under normal use, we will repair or replace it for up to one (1) year from date of purchase. Every Whalen Furniture product is designed to meet your highest expectations. We guarantee that you will immediately see the value of our fine furniture.
