Alden 54" Fireplace Console
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our toll-free customer service number and have your
instructions and parts list ready to provide the model name, part name or factory number:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
Model # WSF54AL30R-AG
#
#
ADULT ASSEMBLY REQUIRED
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
Or visit our website www.whalenfurniture.com
Or e-mail your request to:
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Date 2017-06-15 Rev. 0001-A Factory: GOCRFU
WSF54AL30R-DB
WSF54AL30R-WA
1-866-942-5362
parts@whalenfurniture.com
LOT NUMBER:
DATE PURCHASED: /
/
Advertisement
Related Manuals for Whalen WSF54AL30R-AG
Summary of Contents for Whalen WSF54AL30R-AG
- Page 1 LOT NUMBER: DATE PURCHASED: / Alden 54" Fireplace Console Model # WSF54AL30R-AG WSF54AL30R-DB WSF54AL30R-WA ADULT ASSEMBLY REQUIRED If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased. Please call our toll-free customer service number and have your...
-
Page 2: Special Note
M A X I M U M R E C O M M E N D E D W E I G H T L O A D S MANUFACTURER: Whalen Furniture Manufacturing CATALOG: Alden 54" Fireplace Console MODEL # WSF54AL30R-AG/WSF54AL30R-DB/WSF54AL30R-WA MADE IN CHINA FITS UP TO MOST 165.1 cm / 65 in. - Page 3 IMPORTANT Before you begin: Open, identify and count all parts prior to assembly. Lay out parts on a flat and non- abrasive surface. You will need the parts identified on page 4 and 5 of this instruction manual. NOTE: IT IS VERY IMPORTANT TO USE GLUE WITH THE DOWELS. EXCESS GLUE CAN BE WIPED OFF WITH A DAMP CLOTH.
- Page 4 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. A- Top Panel (Qty. 1) B- Fixed Shelf (Qty. 1) C- Base (Qty. 1) D- Left Front Panel Assembly E- Right Front Panel Assembly (Qty.
- Page 5 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. Fireplace Insert (Qty. 1) Remote Control with Battery (Qty. 1) (1) Cam Lock (2) Cam Bolt (3) M8 x 30 mm Wood Dowel (Qty.
-
Page 6: Assembly Instructions
Assembly Instructions 1. Unpack the unit and confirm that you have all the hardware and required parts. Assemble the unit on a carpeted floor or the empty carton to avoid any scratch. 2. Securely screw the Cam Bolts (2) into the designated small holes on the Top Panel (A) and the Base (C) using a Phillips screwdriver. - Page 7 Assembly Instructions 4. Insert two 30 mm Wood Dowels (3) into the inner holes of the Middle Crossbar (M). Tap in with a rubber mallet, if necessary. Make sure that you use a small amount of glue with both ends of all dowels. 5.
- Page 8 Assembly Instructions 7. Attach two Firebox Supports (T) to the Base (C) with four 30 mm Wood Dowels (3) and four Cam Locks (1) as shown. 8. Align two Push Magnetic Catches (11) to the pilot holes on the Top Panel (A) with the magnet facing the side molding, then using two 15 mm Pan Head Screws (7) to attach each catch to the Top Panel.
- Page 9 Assembly Instructions 9. Attach one Side Panel (H) to the Left Front Panel Assembly (D) with two 30 mm Wood Dowels (3) and three Cam Locks (1). 10. Repeat the same procedure to combine the other Side Panel (H) with the Right Front Panel Assembly (E).
- Page 10 Assembly Instructions 12. Securely screw four Cam Bolts (2) into the designated small holes on the top of the Fixed Shelf (B). 13. Align the Magnetic Catch (10) on the pilot holes on the Barrister Door Left Support (K) with the magnetic plates facing the against edge, then use two 15 mm Pan Head Screws (7) to attach the catch in place.
- Page 11 Assembly Instructions 15. Align and attach the Barrister Door Left and Right Supports (K and L) to the Fixed Shelf (B) with two 30 mm Wood Dowels (3) and two Cam Locks (1) in each. 16. Attach the Left Back Panel (F) to the Panels (B, H and K) with two 30 mm Wood Dowels (3) and six 32 mm Screws (5).
- Page 12 Assembly Instructions 18. Attach the Base (C) to the previous assembly with ten 30 mm Wood Dowels (3) and twelve Cam Locks (1). 19. Using the pilot holes as a guide, fasten two Hooks (13) to the upper corners of the Barrister Door (O) with two 14 mm Flat Head Screws (4) in each.
- Page 13 Assembly Instructions 20. The Barrister Door (O) is shipped with the Wood Panel (P). You can keep the door as it is, or interchange the insert panel with the Speaker Grill (Q) or the Glass Panel (R), depending on the desired configuration.
- Page 14 Assembly Instructions 24. Attach the Top Panel (A) to the top edge of the assembled unit with ten 30 mm Wood Dowels (3) and twelve Cam Locks (1). 25. With the pilot holes as a guide, fasten six Straight Metal Brackets (9) at the joints between the Upper and Bottom Crossbars (M and N) and the Front Panels (D and E), using two 12 mm Flat Head Screws (17) per bracket.
- Page 15 Assembly Instructions 26. Now, go back and securely tighten all the Cam Locks and the Screws. Make sure that all the parts are tight and there are no gaps between the parts. This will help keep the unit square. 27. Pick up the Middle Back Panel (S) and align the pre-drilled holes against the upper long edge with the pilot holes on the back stretcher of the Top Panel (A).
- Page 16 Assembly Instructions 30. Tilt and insert the pivot pin under the Left Door (I) into the plastic bushing pre-attached on the Base (C). 31. Attach the Left Upper Pivot Hinge (15) to the plastic bushing pre-attached on the Top Panel (A) as shown.
- Page 17 Assembly Instructions 34. Insert the Shelf Supports (16) into the desired holes in the sides of the side compartments. Make sure you place the four Shelf Supports in the same level so the shelf is not tilted. Tilt and rest the Adjustable Shelves (U) onto the Shelf Supports (16) and fasten them in place with the 12 mm Flat Head Screws (17).
- Page 18 Assembly Instructions 37. Lift the fireplace insert carefully into the back of the assembled mantel and center it in the opening. DO NOT drag the insert across the Supports as it may scratch the unit. 38. Using the pilot holes as a guide, align and attach two L-shaped Metal Braces (12) to the Firebox Supports (T) by screwing one Washer Head Screw (8) in each.
- Page 19 Assembly Instructions NOTE: You must install the Acrylic TV Stopper to prevent the TV from tipping when placing your flat panel television directly on the console. 39. Remove the paper backing from the Acrylic Stopper (19), then properly align the acrylic stopper into the cut- out on the acrylic stopper template on the Top Panel (A).
-
Page 20: Quality Guarantee
Should this product be defective in workmanship or materials or fail under normal use, we will repair or replace it for up to one (1) year from date of purchase. Every Whalen Furniture product is designed to meet your highest expectations. We guarantee that you will immediately see the value of our fine furniture.
