Marksman X6 Installation Manual

Extreme series
Hide thumbs
Table of Contents

Advertisement

Quick Links

Installation
Manual
Model: X6
For Technical Assistance, please call (800) 638-3600,
or visit www.magnadyne.com
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference; and
(2) This device must accept any interference received, including interference that may cause undesired operation.
Note: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this
equipment. Such modifications could void the user's authority to operate the equipment.

Advertisement

Table of Contents
loading

Related Manuals for Marksman X6

Summary of Contents for Marksman X6

  • Page 1 Installation Manual Model: X6 For Technical Assistance, please call (800) 638-3600, or visit www.magnadyne.com This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference; and (2) This device must accept any interference received, including interference that may cause undesired operation.

  • Page 2: Table Of Contents

    Table of Contents Installer Warnings ..........3 Component Placement .

  • Page 3: Installer Warnings

    Installer Warnings • Due to the complexity of this system, installation must only be performed by a qualified professional installer. This remote start and alarm system is NOT a “Do It Yourself” product. • This remote starter and alarm system is designed to be installed on fuel injected gasoline or diesel vehicles with an automatic transmission ONLY.

  • Page 4: Component Placement

    Component Placement Windshield Receiver/Antenna • The combination windshield receiver/antenna mounts on the windshield (inside). • We suggest you mount it on the lower or upper left-hand side of the windshield. Warning! Do not mount in such a manner that it obstructs the driver’s view. •...
  • Page 5 Wiring Harness Quick Reference HC2 5-Pin Power Input Harness Red/White Park Light Relay Input White Parking Light Relay Output Black Chassis Ground Brown (-) Programmable Output (Horn - Default) +12VDC Battery Input HC3 3-Pin Door Lock Harness Blue (-) Unlock Output Green (-) Lock Output HC4 9-Pin Accessory Harness...

  • Page 6: Wiring

    Wiring HC1: White 6-Pin High Current Remote Starter Harness The method that the remote starter uses to start the vehicle is a duplicate of the ignition switch function. Below, is an explanation of the 3 basic functions of the ignition switch. Since this installation will require analysis of the ignition switch functions, it is recommended that you make the three connections below at the ignition switch harness directly.

  • Page 7: Wiring

    Wiring (continued) HC1: White 6-Pin High Current Remote Starter Harness (continued) Pink Wire: Ignition 2 Output Some vehicles have 2 ignition wires that must be powered. Connect the “Pink” wire to the ignition 2 wire from the ignition switch. No connection required on vehicles without second ignition. Brown Wire: Accessory Output, Heater/AC Output Connect the Brown wire to the accessory wire that powers the climate control system.

  • Page 8: Door Lock Output Wiring

    Wiring (continued) HC3: Black 3-Pin Door Lock Harness Blue Wire: (-) Door Lock Control If the door lock control system on the vehicle is (-) type, connect the Blue wire to the unlock wire from the door lock switch . If the door lock control system on the vehicle is not (-) type, locate the diagram enclosed that matches your application and follow that diagram.

  • Page 9: Wiring

    Wiring (continued) HC3: Black 3-Pin Door Lock Harness (continued) Newly Installed Power Door Lock Motors Red Wire: Lock Blue Wire Green Wire Black 3-Pin Connector Violet Wire To +12 Volts (Battery +) Black Wire: Unlock ALA-DL1 Relay Pack White Wire Brown Wire To Ground Note: Orange wire from ALA-DL1...

  • Page 10: Wiring

    Wiring (continued) HC3: Black 3-Pin Door Lock Harness (continued) Unlock Driver's Door First Wiring for 3-Wire Positive Door Lock System White 9-Pin Mini Connector Blue Wire Green Wire Light Blue Wire Black 3-Pin To +12 Mini Connector Volts (Battery +) Driver's Door Motor To Power...

  • Page 11: Accessory Alarm And Remote Start Wiring

    Wiring (continued) HC4: White 9-Pin Accessory Harness (continued) Violet/WhiteWire: (-) Tachometer Signal Connection This input provides the remote start system with information about the engine’s revolutions per minute (RPM). It can be connected to the negative side of the coil in vehicle with conventional coils. In multi-coil ignition system, the system can have individual coil wires.

  • Page 12: Wiring

    Wiring (continued) HC4: White 9-Pin Accessory Harness (continued) Brown Wire: Positive Brake Safety Shut Down Input This wire provides instant shutdown for the remote start, when it receives +12 volts. If the brake lights switch in the vehicle switches +12 volts to the brake light circuit, connect this wire to the output side of the brake switch. This will allow the remote start to shut down if an attempt is made to operate the vehicle without the key while running under the control of the remote start.

  • Page 13: Wiring

    The Light Blue wire can be programmed to provide a constant (-) output during the time that the vehicles engine is running under the control of the X6. In this configuration, the Light Blue wire can be used as sensor bypass control.
  • Page 14 Wiring (continued) HC4: White 9 Pin Accessory Harness (continued) Transponder Interfacing Using ALA984 Relay: Can also use optional RS-TIM bypass module. If the vehicle has transponder system installed, you will need to bypass the system while the vehicle is operating under the control of the Remote Start Unit.

  • Page 15: Plug-In Harness Information

    Wiring (continued) HC4: White 9 Pin Accessory Harness (continued) Passkey II Passive Anti-Theft Bypass Trucks: Red/White or Cars: White Trucks: Orange/Black or Cars: Black Yellow Resistor Pink Wire White 9-Pin Mini Connector To Vehicle's Ignition Wire Red/White Wire : Channel 3 (Trunk Release) Output The Red/White will become grounded for 1 second when activated by the remote transmitter.
  • Page 16 (continued) P6 Antenna / Receiver P7 Data Adapter Communication Data Interface Harness: Allows direct communication between Marksman Remote Start and the vehicle’s data bus communication. (Data Interface Modules sold separately) Black Wire No Connection Red Wire No Connection DBI Conection Harness (supplied) Note: The DBI Connection Harness provides power and ground to the Data Interface Module.

  • Page 17: Transmitter Programming

    Programming the Transmitter The transmitters included with this system have been pre-programmed and should not need re-programming. Note: This system will accept codes from 4 transmitters. If more than 4 transmitters are programmed, the system will only operate from the last (4) programmed transmitters. Follow the enclosed procedure to program additional transmitters: Step 1 Step 2...

  • Page 18: Keyless Entry Feature Programming

    Keyless Entry Feature Programming (Group 1) Step 1 Step 2 1X + 1X (Hold) With the ignition switch in the OFF position, turn the Before 15 seconds has passed, push and release the ignition switch On - Off - On - Off - On - Off. valet switch 2 times holding the button down on the 2nd press.

  • Page 19: Keyless Entry Feature Programming

    Keyless Entry Feature Programming (Group 1) (continued) Turn On the Ignition Step 4 Exit Programming 3 long chirps and 3 flashes of the parking lights will confirm exit of the programming mode. Note: Waiting 15 seconds after the last command will also cause the system to automatically exit the programming mode.

  • Page 20: Remote Start Feature Programming

    Remote Start Feature Programming (Group 1) Step 1 Step 2 7X + 1X (Hold) With the ignition switch in the OFF position, turn the Before 15 seconds has passed, push and release the ignition switch On - Off - On - Off - On - Off. valet switch 8 times holding the button down on the 8th press.

  • Page 21: Remote Start Feature Programming

    Remote Start Feature Programming (Group 1) (continued) Button One LED Pulse Two LED Pulses Three LED Pulses (Default Setting) Turbo Timer Control is Active The vehicle has an aftermarket (Default Setting) Press the ( ) buttons before turbo timer installed. The keyless Turbo Timer Control removing the ignition key to activate entry system can lock the doors...

  • Page 22: Engine Crank Detection Programming

    Engine Crank Detection Programming Enter the crank detection programming mode, select the engine checking type, then follow the procedures to test and re-set the cranking parameters as needed. Note: The default detection setting is “Voltage Detection”. Once your wiring is completed, you can press the button (2) times and start the engine to make sure all your connections are good to this point.
  • Page 23 Engine Crank Detection Programming (continued) Step 3A Crank Detection Programming and Procedure Press Chirp/ Checking Test and Adjustment Procedure Buttons Type LED Flash Voltage A. Press the button two times to start the engine. Allow engine to run Type for more than 10 seconds. A1.

  • Page 24: Remote Start Shutdown Diagnostics

    Remote Start Shutdown Diagnostics The unit has the ability to report the cause of the last shutdown of the remote start system. Enter the Vehicle: 1. Turn the Ignition switch to “On” position. 2. Press the button on the transmitter 3.
  • Page 25 Return to Factory Default Settings (Resets All Programmable Features) Step 1 Step 2 Step 3 11X + 1X (Hold) Before 15 seconds has passed, push Turn the ignition switch from the Press and release the (Car) button first. and release the valet switch 12 times OFF position to the ON position 3 holding the button down on the 12th times leaving it in the Off position...

  • Page 26: Safety Testing The Installation

    Safety Testing the Installation Caution! The following procedure must be performed after the installation of the Remote Start Device. It is the responsibility of the installing technician to complete these tests. Failure to test the unit in the following manner may result in personal injury, property damage, or both.

  • Page 27: Wiring Diagram

    Wiring Diagram Transceiver Valet Switch Indicator White 6-Pin Black 3-Pin White Blue 3-Pin 2-Pin Brown White 9-Pin 4-Pin White 5-Pin Data Port © Copyright 2008/ 2009 Magnadyne Corporation X6-IM 9-12-08 Rev. A...
