Summary of Contents for Spirit 1622775
- Page 2 WARNING: ALWAYS UNPLUG THE TREADMILL FROM THE ELECTRICAL OUTLET BEFORE SERVICING THE UNIT.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Table of Contents..............1 Table of Figures..............3 Description ................4 ........4 LECTRICAL ONFIGURATION 1. 1622775 Treadmill components........4 ..........5 ENERAL NFORMATION 1. Console ...............5 2. Main controller............5 3. Treadmill motor ............5 4. INCLINE MOTOR .............5 Operation................7 ..........7... - Page 4 1. TREADBELT ADJUSTMENT......... 24 APPENDIX B ..............26 1. TREADMILL LUBRICATION ........ 26 APPENDIX C ..............27 1. RESET SWITCH RESETTING ........ 27 APPENDIX D ..............28 1. FUSE REPLACEMENT ........... 28 APPENDIX E............... 29 1. SPEED SENSOR ADJUSTMENT......29 2.
-
Page 5: Table Of Figures
TABLE OF FIGURES Figure 1 Operational Flowchart..........6 Figure 2 Console Layout ............20 Figure 3 Mechanical Layout..........20 Figure 4 Main Controller information & voltages....21 Figure 5 Function JK1 connector on Main Controller... 21 Figure 6 Wiring Diagram ............. 22 Figure 7 Schematic Diagram .......... -
Page 6: Description
DESCRIPTION LECTRICAL ONFIGURATION Note: Electrical servicing of this treadmill is limited to board level replacement. 1. 1622775 TREADMILL COMPONENTS Safety key: Magnetic key that fits in the Console to activate all functions. b) Console: Interface that controls all functions of the treadmill. -
Page 7: B General Information
ENERAL NFORMATION 1. CONSOLE Contains touch controls and LCD Display. 2. MAIN CONTROLLER Contains power supply and control circuits 3. TREADMILL MOTOR Variable speed reversing 0-90 volt DC motor. b) Has three wires red, black and green. If there is DC voltage on the Red wire (M+) the treadmill motor will turn clockwise. -
Page 8: Figure 1 Operational Flowchart
Figure 1 Operational Flowchart... -
Page 9: Operation
OPERATION INDOW ISPLAY 1. OFF MODE When user doesn’t insert the SAFETY KEY on the console, the treadmill enters the OFF Mode. All windows will appear blank then the LCD display will show “PLEASE INSTAL SAFETY KEY TO START”. 2. READY MODE When the treadmill is ON and SAFETY KEY is inserted in console, the LCD window will show “WEIGHT 150”. -
Page 10: B Function
UNCTION 1. SPEED In RUN Mode, DISPLAY range is 0.0 to 99.9M. b) WORK range is 0.5 to 10.0M. Press “FAST” or ”SLOW” to adjust speed, each increment and decrement is 0.1mph. 2. TIME In RUN Mode, TIME divides into COUNT UP and COUNT DOWN. -
Page 11: Calories
4. CALORIES In RUN Mode, CALORIES preset is COUNT UP. b) DISPLAY range is 0.0 to 999. WORK range is 0.0 to 999. d) In RUN Mode, press the “START” button to save value of distance and entering “RUN Mode” again that value will continue count up time. -
Page 12: C Function Button I N Main Mode
UNCTION UTTON 1. READY MODE In “READY” mode, user could choose any program which include MANUAL, HILL, FATBURN, CARDIO, STRENGTH, INTERVAL, USE1, USE2, HR1, HR2 or press “START” button to execute directly. b) STOP button: Non-function. START button: When press “START” button, there will be 3 warning beep, then machine starts running. -
Page 13: Run Mode
2. RUN MODE START button: Press “START” button to begin into RUN MODE. b) STOP button: When press the “STOP” button once, pause is executed. If press “STOP” button a second time, the program will end and a workout summary will be displayed. FAST button: Press the button to increase your speed and each increase is 0.1mph. -
Page 14: D Auto -Calibration Mode
ALIBRATION When turned on, the console will light on all seven-segment LEDs and all LCD segments. Afterwards, all LEDs and LCD will turn off. When this occurs, press the GRADE UP and GRADE DOWN keys simultaneously to enter Calibration Mode. The console displays “CA:” in the center to indicate it is in Auto-Calibration Mode. - Page 15 variable, press the SELECT key. If the SELECT key is pressed prior to pressing the START key, the edited value will not be saved in NOVRAM. The next variable displayed is HALF MAXIMUM PWM. The lower left window displays “EEP”. The upper window displays “HA”, indicating the variable is half maximum pwm.
-
Page 16: Troubleshooting
TROUBLESHOOTING WARNING: ALWAYS UNPLUG THE TREADMILL FROM THE ELECTRICAL OUTLET BEFORE SERVICING THE UNIT. 1. GENERAL Do a visual check of all wiring and connections looking for chafed wires or lose connections. b) Make sure any wiring is safely positioned and/or secured away from moving parts. -
Page 17: Troubleshooting Matrix
2. TROUBLESHOOTING MATRIX Condition Reason Solve When turn on power, ON/OFF switch 1. Power cord don’t plug into outlet in right 1.Plug the power cord into outlet. isn’t bright. position. 2.Plug the power cord into unit. 2. Power cord don’t plug into unit. 3. - Page 18 5. Varistor of controller was broken. 5. Replace varistor or controller. 6. Reed switch of console was broken. (open) 6. Replace reed switch or console. 7. Other components are imperfection. 7. Replace console. When console didn’t insert safe key 1. Reed switch of console was broken. (short) 1.Replace reed switch or console.
- Page 19 message after 8 seconds. 3. Computer cables were broken that got damage. 3. Replace the wires. 4. Motor belt was cut off. 4.Replace motor belt. 5. Controller was broken. 5.Replace controller. 6. Motor was broken. 6.Replace motor. 7. Console was broken. 7.Replace console.
- Page 20 2.The connector of HANDPULSE W/WIRE and 2.Connect the wires again. Console don’t connect into position. 3.The wires got damage with connecting the 3.Replace wires. HANDPULSE W/WIRE and Console. Tread belt does not run in center. 1. Tread belt tension not even across tread belt. 1.See treadbelt adjustment (see Appendix A) Tread belt hesitates while being...
- Page 21 The speed of the belt doesn’t match 1.Console is not calibrated. 1.Calibrate the console console display. Error Message 1 Turn off the AC switch and turn on INCLINE window displays “E4”. 1. Reverse Elevation Pot. power again. 2. Calibrate the console. 3.Replace the incline motor.
-
Page 22: Diagrams And Schematics
DIAGRAMS AND SCHEMATICS Figure 2 Console Layout Figure 3 Mechanical Layout... -
Page 23: Figure 4 Main Controller Information & Voltages
Figure 4 Main Controller information & voltages Figure 5 Function JK1 connector on Main Controller... -
Page 24: Figure 6 Wiring Diagram
Input Power 110V/60HZ PLUG Black 12pin male Brown DOWN Orange 12pin female FAST Yellow CONNECTOR BREAKER SLOW Green (FEMALE) Blue Purple AC SWITCH Gray White Light blue Pink White wire Black wire Incline Motor N/L2 AC/L1 12pin female CONTROLLER 12pin male EVL_COM Red wire 12 PIN 1200 mm... -
Page 25: Figure 7 Schematic Diagram
Awaiting from DCI Figure 7 Schematic Diagram... -
Page 26: Treadbelt Adjustment
APPENDIX A 1. TREADBELT ADJUSTMENT The treadbelt has been factory pre-adjusted, however if during the operation: 1 /4 T U R N Figure 8 If Treadbelt slips The treadbelt is too loose: Tighten both rear roller adjusting bolts 1/4 turn clockwise using allen wrench 1/4 TUR N Figure 9 If tread belt shifts too far to the Right a) Set the treadmill speed to 3.5 mph/5.6 km. -
Page 27: Figure 10 If Tread Belt Shifts Too Far To The Left
1/4 TU R N Figure 10 If tread belt shifts too far to the Left a) Set the treadmill speed to 3.5 mph/5.6 km. b) Tighten the left adjusting bolt a 1/4 turn clockwise using allen wrench c) Wait 15 seconds: if no change; turn the right adjusting bolt a 1/4 turn counter-clockwise using allen wrench e) Repeat steps b and c until belt is centered IMPORTANT... -
Page 28: Treadmill Lubrication
APPENDIX B 1. TREADMILL LUBRICATION Your treadmill should require little maintenance other then periodically applying lubricant. Lubricating under the treadbelt will ensure superior performance and extend its life expectancy. HOW TO CHECK TREADBELT FOR PROPER LUBRICATION Lift one side of the treadbelt and feel the top surface of the treadboard If the surface is (slick) to the touch, then no further lubrication is required If the surface is dry to the touch, apply one packet of lubricant HOW TO APPLY LUBRICANT... -
Page 29: Reset Switch Resetting
APPENDIX C Tripped Normal Figure 11 Resetting Reset switch 1. RESET SWITCH RESETTING If the red button of reset switch is tripped, it will protrude out from the face of the switch. b) Press in the red button of the switch. If the red button of reset switch is not tripped, that means normal. -
Page 30: Fuse Replacement
APPENDIX D Figure 12 Fuse replacement 1. FUSE REPLACEMENT If your treadmill loses power or will not start, check the fuse located on the motor controller. DANGER: Turn the power switch off and unplug the treadmill to reduce the risk of an electric shock Remove the motor cover Remove and replace the fuse on the motor controller Replace the motor cover... -
Page 31: Speed Sensor Adjustment
APPENDIX E 1. SPEED SENSOR ADJUSTMENT If the monitor does not display speed or distance the speed sensor and magnet may be misaligned. Follow these steps to check and realign. Remove the motor cover Check the spacing and alignment between the magnet on the right side of the front roller and the speed sensor on the frame.
