Control Techniques FM-3 Reference Manual page 6

Customer Service (Sales)
Email: customer.service@emersonct.com
Authorized Control Techniques distributors may place orders directly with our Customer Service department. Contact the
Customer Service department at this number for the distributor nearest you.
Document Conventions
Manual conventions have been established to help you learn to use this manual quickly and easily. As much as possible, these
conventions correspond to those found in other Microsoft® Windows® compatible software documentation.
Menu names and options are printed in bold type: the File menu.
Dialog box names begin with uppercase letters: the Axis Limits dialog box.
Dialog box field names are in quotes: "Field Name."
Button names are in italic: OK button.
Source code is printed in Courier font: Case ERMS.
In addition, you will find the following typographic conventions throughout this manual.
bold
italic
ALL CAPITALS
SMALL CAPS
KEY1+KEY2
example: (Alt+F)
KEY1,KEY2
example: (Alt,F)
Note
For the purpose of this manual and product, "Note" indicates essential information about the product or the respective part
of the manual.
E
N E Series Only
For the purpose of this manual and product, the "EN" symbol indicates information about the EN drive specifically.
Throughout this manual, the word "drive" refers to an MDS or EN drive.
"Warning" indicates a potentially hazardous situation that, if not avoided, could result in death or serious injury.
"Caution" indicates a potentially hazardous situation that, if not avoided, may result in minor or moderate injury.
"Caution" used without the safety alert symbol indicates a potentially hazardous situation that, if not avoided, may result
in property damage.
iv
This
Characters that you must type exactly as they appear. For example, if you are directed to type
a:setup, you should type all the bold characters exactly as they are printed.
Placeholders for information you must provide. For example, if you are directed to type
filename, you should type the actual name for a file instead of the word shown in italic type.
Directory names, file names, key names, and acronyms.
Non-printable ASCII control characters.
A plus sign (+) between key names means to press and hold down the first key while you press
the second key.
A comma (,) between key names means to press and release the keys one after the other.
(952) 995-8000 or (800) 893-2321
Represents
