FM-3 Programming Module Reference Manual
Custom Variable
DriveAnalogOutput.#.CustomSourceVariable
The Custom Variable parameter is only available once the user has selected Custom Variable from the Source list box. The
field is used to define what parameter will control the Analog Output. This means that the selected variable parameter will
directly determine the value of the analog output based on the Max and Min scaling values entered on this view. When the
Popup Variables... button is pressed a window will open containing the list of variables that can be dragged into the Custom
Variable text box.
Drive Analog Output Feedback
DriveAnalogOutput.#.Feedback
Displays the Output voltage from one of the two analog outputs found on the drive analog/sync connector.
Analog Output - Maximum Output
DriveAnalogOutput.#.MaxOutputValue
The analog output is a linear interpolation of the selected module variable between the minimum and maximum specified end
points. Each end point is specified as the user value and the corresponding output value at that point. The number of decimal
places for both values is taken from the selected source variable. MaxOutputValue is the maximum analog output value which
corresponds to the maximum user value.
Analog Output - Maximum Value
DriveAnalogOutput.#.MaxUserValue
The analog output is a linear interpolation of the selected module variable between the minimum and maximum specified end
points. Each end point is specified as the user value and the corresponding output value at that point. The number of decimal
places for both values is taken from the selected module variable. MaxUserValue is the maximum user unit value which
corresponds to the maximum analog output value.
Analog Output - Minimum Output
DriveAnalogOutput.#.MinOutputValue
The analog output is a linear interpolation of the selected module variable between the minimum and maximum specified end
points. Each end point is specified as the user value and the corresponding output value at that point. The number of decimal
places for both values is taken from the selected module variable. MinOutputValue is the minimum analog output value which
corresponds to the minimum user value.
Analog Output - Minimum Value
DriveAnalogOutput.#.MinUserValue
The analog output is a linear interpolation of the selected module variable between the minimum and maximum specified end
points. Each end point is specified as the user value and the corresponding output value at that point. The number of decimal
places for both values is taken from the selected module variable. MinUserValue is the minimum user unit value which
corresponds to the minimum analog output value.
Drive Enable Status
DriveEnableStatus
This source is active when the drive is enabled.
Drive Input Debounced
DriveInput.#.Debounced
This displays the state of the input after the debounce is taken into account.
