Datamax OC2 BT Technical Manual And User Manual

Direct thermal portable printer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Index
Introduction ...........................................................................................................1
Technical Description ............................................................................................2
Photographs ......................................................................................................... 3
Schematic Diagrams ............................................................................................. 4
User's Guide ......................................................................................................... 5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OC2 BT and is the answer not in the manual?

Questions and answers

Related Manuals for Datamax OC2 BT

Summary of Contents for Datamax OC2 BT

  • Page 1: Table Of Contents

    Index Introduction ......................1 Technical Description ....................2 Photographs ......................3 Schematic Diagrams ..................... 4 User’s Guide ......................5...
  • Page 2 Datamax-O’Neil Corporation Type Approval Application (E) OC2 BT...

  • Page 3: Introduction

    Introduction Model: OC2 BT Type: Bluetooth Printer Technology: Bluetooth (Class I) No other radios. Fabricante: Datamax‐O'Neil Corporation 4501 Parkway Commerce Blvd. Orlando, FL 32808 Factory: KEYTRONIC EMS MAGNETO 7824, KEY TRONIC JUAREZ PARQUE INDUSTRIAL "GEMA", 32380 JUAREZ CHIH MEXICO Solicitante/Local Holder: DAMKTECH Ltda.

  • Page 4: Technical Description

    Section 2 Technical Description OC2 BT 4 pages Technical Description...
  • Page 5 And when it’s time to replace the Using quality labels and paper can significantly prolong the life of your battery, the OC printers use economical printhead. Datamax‐O’Neil offers a wide replacement batteries variety of high quality media for Mobile POS...
  • Page 6 • Receipts compatibility... labels and receipts, ticketing Guaranteed. media, and cleaning products. When you choose Healthcare Rain Checks • Datamax‐O’Neil, Patient ID Wristbands • you receive a proven Asset Identification • Coupons Specimen Tracking Records Labeling • • • commitment to...
  • Page 7 Media Roll Width Media I.D. Core Endurance...
  • Page 8 • applications. With its durable latex‐free – Supports storage of graphics/logos in Inputs: polypropylene face stock and polyethylene Flash memory and transient “print once” liner, Datamax‐O’Neil SafeD‐Bands provide – External DC jack, 12‐15V, built‐ graphics unmatched image quality and durability.
  • Page 9 – Windows Desktop • Compatible label • Protocol: • Wireless communication design software: – ® – Line Printer Mode, Easy Print • Magnetic stripe card NiceLabel, BarTender , DP Designer • • Device management (for ® reader Software development 802.11 models only): kit:...

  • Page 10: Photographs

    (1) battery, (1) roll of media, and (1) swivel belt clip required recommended Cleaning Cards & Kits Use of cleaning cards is recommended to extend the life of the printhead (visit www.datamax‐oneil.com/supplies for more information) optional to learn more, visit www.datamax-oneil.com Specifications subject...
  • Page 11 Datamax-O’Neil Corporation 1 page OC2 BT External Top View – Open Datamax-O’Neil Corporation 1 page OC2 BT External Rear View Datamax-O’Neil Corporation 1 page OC2 BT Side Views Datamax-O’Neil Corporation 1 page OC2 BT Motherboard Top View Datamax-O’Neil Corporation 1 page...
  • Page 12 Datamax-O’Neil Corporation 1 page OC2 BT Bluetooth Module Top View – with RF Shield in place Datamax-O’Neil Corporation 1 page OC2 BT Bluetooth Module Top View – with RF Shield removed Datamax-O’Neil Corporation 1 page OC2 BT Bluetooth Module Rear View...
  • Page 13 Datamax-O’Neil Corporation Type Approval Application (E) OC2 BT Datamax-O'Neil Corporation OC2 External Top View - Closed External Top View - Open...
  • Page 14 Datamax-O’Neil Corporation OC2 BT Datamax-O’Neil Corporation OC2 External Rear View...
  • Page 15 Side Views...
  • Page 16 Datamax-O’Neil Corporation OC2 BT Datamax-O’Neil Corporation OC2 Motherboard Top View...
  • Page 17 Motherboard Bottom View...
  • Page 18 Datamax-O’Neil Corporation OC2 BT...
  • Page 19 Datamax-O’Neil Corporation OC2 BT Bluetooth Module Top View – with RF Shield in place...
  • Page 20 Datamax-O’Neil Corporation OC2 BT Bluetooth Module Top View – with RF Shield removed Bluetooth Module Rear View...
  • Page 21 Datamax-O’Neil Corporation OC2 BT...

  • Page 22: Schematic Diagrams

    Section 4 Schematic Diagrams • OC2 BT 8 pages Schematic Diagrams – System • OC2 BT 1 page Schematic Diagrams – BT Module...
  • Page 23 Datamax-O’Neil Corporation Type Approval Application (E) OC2 BT...
  • Page 26 CS1 [2] OE[2]...
  • Page 28 TP99 3.3V [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2][1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] FLASH 32M(2Mx16) 3.3V .1uF...
  • Page 29 10 Layer 0.062" THICK Layer 1 Signal Horizontal GND FILL Layer2 Signal Vertical Layer 3 Plane 3.3V Layer 4 Plane GND Layer 5 Signal Horizontal Layer 6 Signal Vertical Layer 7 Plane GND Layer 8 Plane 1.5V 2.5V GND Hole/Split? Layer 9 Signal Horizontal Layer 10 Signal Vertical GND FILL...
  • Page 31 3.3 V INT0_SWITCH1 [1] TP15 SLEEP/RESUME...
  • Page 32 PAPER ADV 3.3 V INT1_SWITCH2 TP16 RADIO ON/OFF INT2_SWITCH3 RADIO ON OFF TP17 PAPER FEED .1 uF 3.3V...
  • Page 35 3.3V...
  • Page 38 COMPANY:...
  • Page 39 CHGND 3.3V MS_CLK3 MS_DATA3 MS_CLK1 MS_MD MS_DATA1 MS_CLK2 MS_DATA2...

  • Page 41: User's Guide

    Section 5 User’s Guide OC2 BT 26 pages User Manual...
  • Page 42 Datamax-O’Neil Corporation Type Approval Application (E) OC2 BT...
  • Page 43 110203‐003 OC‐2 SERIES OF PRINTERS User Guide...
  • Page 45 TABLE OF CONTENTS OC-2 printer views ..........1 Front and back view ........1 Side views ........... 1 Setting up your printer ........1 Unpacking your printer ......... 2 Removing the battery isolator ....... 2 Installing/removing the battery ..... 3 Installing the battery ........
  • Page 46 Battery Status LED ........12 Power Button ..........14 Media Function LED ........14 Radio Button/LED .......14 Radio Button ..........14 CardReader Audio Indicators ......15 Using a CardReader ..........15 General guidelines ........16 Maintenance and troubleshooting ......16 TABLE OF CONTENTS Maintenance guidelines ......17 Preventative maintenance ......17 Troubleshooting ........

  • Page 47: Oc-2 Printer Views

    OC-2 PRINTER VIEWS OC-2 printer views Front and back view Magnetic card reader slot Printhead cover Data port Swivel mount Power port Figure1: Front view Figure2: Back view Side views Radio enable Media advance Reset Power Battery status Charge contacts Figure3:Side view Figure4:Side view Setting up your printer...

  • Page 48: Unpacking Your Printer

    If the printer has been damaged: • Contact the shipping company and file a damage report. • Contact Datamax-O’Neil. • Keep all shipping materials. Removing the battery isolator The battery is already installed in new printers. An insulating strip (battery isolator) prevents accidental discharge during shipping.

  • Page 49: Installing/Removing The Battery

    ETTING UP YOUR PRINTER Figure5 Figure6 Figure7 Installing/removing the battery Note: The battery is already installed in new printers. See "Removing the battery isolator" on page 2 for information on enabling the battery in a new printer. Installing the battery 1.

  • Page 50: Removing The Battery

    OC-2 SERIES OF PRINTERS USER'S GUIDE Note: Do not force the battery into the battery cavity. When inserted properly, the battery easily slides and locks into place. If the battery does not easily slide into place, re-insert the battery. 6. Close the printer cover (Figure 13). Figure11 Figure12 Figure13...

  • Page 51: Determining The Battery Condition

    Dispose of used batteries according to the instructions. Caution: The operating temperature of this portable printer is 50° C. However, the operating temperature when used with Datamax-O’Neil power supply for charging the portable printer is...
  • Page 52 OC-2 SERIES OF PRINTERS USER'S GUIDE limited to 40° C. Please charge the printer in a suitable location that meets this temperature requirement. Caution: (For US/Canada) Please only use the Datamax-O’Neil part number 220240-100 power supply with this product.

  • Page 53: Loading Media

    For more information, see "Configuring the printer" on page 10. Load media as follows: 1. Position the printer so that the Datamax-O’Neil logo is facing you (Figure 18). 2. Press the printhead release and open the printer (Figure 19).

  • Page 54: Printing A Self-Test

    OC-2 SERIES OF PRINTERS USER'S GUIDE Figure20 Figure21 Figure 22 6. Close the printer (Figure 22). The printhead cover snaps into place when completely closed. 7. Push the Media Function button 1-2 times to align the media. 8. At either edge of the printer cover are serrated corners. Tear the media by pulling up and away from the printer (Figure 24).

  • Page 55: Connecting The Printer Via A Cable Or Radio

    ETTING UP YOUR PRINTER Connecting the printer via a cable or radio The OC-2 printer is designed to transmit and receive data from a host terminal. The host terminal may be your computer, handheld, or laptop. Communication can occur using one of the following methods: •...

  • Page 56: Configuring The Printer

    OC-2 SERIES OF PRINTERS USER'S GUIDE For proper system operation, set the following parameters on your printer and host computer: 802.11b Parameters • ESS ID • IP Address (if not DHCP) • DHCP • Subnet Mask • WEP Encryption • Port •...

  • Page 57: Using The Belt Clip

    SING THE BELT CLIP Using the belt clip Install the belt clip as follows: 1. Turn the printer so that its back faces you and the belt clip socket is up, as shown in Figure 27. 2. Place the belt clip over the belt clip socket such that the flat side of the belt clip swivel matches the flat side of the belt clip socket (Figure 28).

  • Page 58: Audio Indicators

    OC-2 SERIES OF PRINTERS USER'S GUIDE • Power Button/LED on page 14 • Media Function Button/LED on page 14 • Radio Button/LED on page 15 • Reset Button on page 15 • CardReader Audio Indicators on page 15 Battery Status Power Button/ Media Function Radio Reset...
  • Page 59 Red (solid): • If A/C power is not plugged • Charge the battery. The battery in, the printer will soon turn has less than off. 5% power. • If A/C power is plugged in, • None. Wait for the the LED flashes and charge LED to turn charging is in progress.

  • Page 60: Power Button

    OC-2 SERIES OF PRINTERS USER'S GUIDE Power Button/LED Power Button Short press If printer is asleep, wakes up printer; if printer is awake, enters sleep mode. Long press (press and Prints a self-test. hold for three to five seconds) Power LED Green Printer is awake.

  • Page 61: Cardreader Audio Indicators

    Radio LED* Blue flash - slow* RF power is on and printer is asleep. Blue flash - fast* RF power is on and printer is awake. Blue flash to solid red The printer is out of range of the access point and/or infrastructure and it is not correctly configured for the radio it recognizes.

  • Page 62: General Guidelines

    OC-2 SERIES OF PRINTERS USER'S GUIDE CardReader slot Figure31 Figure32 General guidelines • If you are using a magnetic CardReader, insert a card with the stripe facing toward the printer, then slowly slide the card through the CardReader slot. • To wake up the CardReader, insert a card into the CardReader slot.

  • Page 63: Troubleshooting

    Area Method Interval Printhead/ Use only a Datamax- After every ten (10) roller O’Neilapproved cleaning card. rolls of media. Tear bar Clean thoroughly with 70% After every five (5) isopropyl alcohol on a cotton rolls of media. swab. Exterior Use a soft cloth and mild cleanser As needed.

  • Page 64: Help Desk

    Serial number UPPLIES Supplies Media supplies Datamax-O’Neil offers seven certified grades of paper for use in the printer. Our certified supplies are guaranteed compatible — this important qualification means that rigorous performance and image life testing have been performed. Quality supplies are key to obtaining optimal image quality and print performance.

  • Page 65: For More Information

    Use only supplies certified by the Original Equipment Manufacturer (OEM). For OEM supplies, please contact Datamax-O’Neil at (949) 458-0500. For more information • For more information about using the printer, contact Datamax-O’Neil at (949) 458-0500, or visit our Web site at www.datamax-oneil.com.

  • Page 66: Agency Approvals

    OC-2 SERIES OF PRINTERS USER'S GUIDE Agency Approvals FCC Notice This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 67 Copyright This manual and any examples contained herein are provided “as is” and are subject to change without notice. Datamax-O’Neil makes no warranty of any kind with regard to this manual, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
  • Page 68 Anatel Label:...
  • Page 69 COPYRIGHT © 2010, DATAMAX-O’NEIL...
