- Page 1 Con guration-, Parameterization Instruction COI/TZIDC/TZIDC-200-EN TZIDC, TZIDC-200 Digital Positioner Software revision 5.0 VALVE ACCESSORIES & CONTROLS...
- Page 2 Short product description Digital positioner for the positioning of pneumatically controlled actuators. Device firmware version: 05.00.00 Further information Additional documentation on TZIDC, TZIDC-200 is available to download free of charge at www.abb.com/positioners. Alternatively simply scan this code: Manufacturer ABB Automation Products GmbH Process Automation Schillerstr.
-
Page 3: Table Of Contents
MAX_RGE – Operatin g range ma x..... 17 3.12.9 EXIT – Return to op erating level......28 3.7.3 ZERO_POS – Zero position ........ 18 3.7.4 EXIT – Return to op erating level ......18 TZIDC, TZIDC-200 | COI/TZIDC/TZIDC-200-EN 3... - Page 4 Alarm co des ............35 Message co des ..........36 Error hand ling ............ 37 4.4.1 Positioner vibrates ..........37 4.4.2 Positioner without function ......... 38 4 COI/TZIDC/TZIDC-200-EN | TZIDC, TZIDC-200...
-
Page 5: Safety
The signal word "NOTE" in dicates useful or important information about the product. The signal word "NOTE" is n ot a signal word indicating a danger to personnel. The signal word "NOTE" can also refer to material damage. TZIDC, TZIDC-200 | COI/TZIDC/TZIDC-200-EN 5... -
Page 6: Operation
For values, the physical unit (°C, %, mA) is also displayed. Designator display This 14-segment display with eight digits indicates the designators of the parameters with their status, of the parameter groups, and of the operating modes. 6 COI/TZIDC/TZIDC-200-EN | TZIDC, TZIDC-200... -
Page 7: Menu Levels
The valve position is indicated as a percentage of the operating range (from 0 ... 100%). 1. Press and hold the button. The control deviation is displayed as a percentage (%) of the stroke range. TZIDC, TZIDC-200 | COI/TZIDC/TZIDC-200-EN 7... -
Page 8: Operating Mode 1.2: Manual Adjustment In The Stroke Range
In this mode, the valve position is indicated in angular degrees with respect to the sensor range (i.e.,0 ... 140 °). 8 COI/TZIDC/TZIDC-200-EN | TZIDC, TZIDC-200... -
Page 9: Configuration
Autoadjust Command / Function is being P1.2 ADJ_MODE Automatic adjustment mode FULL, STROKE, CTRL, PAR, FULL ZERO_POS, LOCKED P1.3 TEST INACTIV P1.4 EXIT Return to operating level Command / Function is being NV_SAVE P2._ SETPOINT TZIDC, TZIDC-200 | COI/TZIDC/TZIDC-200-EN 9... -
Page 10: Hart Parameter Description
. n i . n i … P6.1 MAX_VR … P6.2 ACTUATOR P6.3 SPRNG_Y2 Spring action (Y2) Spring action (Y2) CL OCKWISE, CTCLOCKWISE CTCLOCKWISE P6.4 DANG_DN … P6.5 DANG_UP … P6.6 BOLT_POS t i s P6.7 EXIT 10 COI/TZIDC/TZIDC-200-EN | TZIDC, TZIDC-200... - Page 11 FS / IP P11.0 FAIL_POS t i s P11.1 FACT_SET P11.2 IP-TYP I/P module type Type of l/P mo dule NO_F_POS,F_SAFE_1,F_SAFE_2, [CUSTOM] F_FREEZE1, F_FREEZE2 P11.3 IP_COMP P11.4 HART_REV P11.5 EXIT 1) Activation only by ABB Service TZIDC, TZIDC-200 | COI/TZIDC/TZIDC-200-EN 11...
-
Page 12: Hart Parameter Overview (Graphic)
The mode and scope of the automatic adjustment function NOTE can be selected using parameter ADJ_MODE . After changing the actuator type , it is recommended that you run automatic adjustment to prevent linearity errors. Selection LINEAR Linear actuator ROTARY Part-turn actuator 12 COI/TZIDC/TZIDC-200-EN | TZIDC, TZIDC-200... -
Page 13: Adj_Mode - Automatic Adjustment Mode
Use this parameter to define the mode or scope of the Auto Adjust function. FULL Complete Autoadjust STROKE Stops only CTRL_PAR Control parameters only ZERO_POS Zero position only (con figured stops required) LOCKED No Autoadjust TZIDC, TZIDC-200 | COI/TZIDC/TZIDC-200-EN 13... -
Page 14: Test - Test
This function is only possible with HART 7 and enables identification of the affected device in the system. Following activation, the device sends a signal on request under HART 7. The following signals are available: — Disable — One time — Continuous 14 COI/TZIDC/TZIDC-200-EN | TZIDC, TZIDC-200... -
Page 15: Parameter Group 2: Setpoint
Min. = 8.3 mA, Max. = 15.6 mA REVERSE Decreasing Split range configuration between Min. = 12.0 mA, Max. = 20.0 mA Control signal 20 ... 4 mA, and setpoint 100 ... 0 % = position 0 ... 100 % TZIDC, TZIDC-200 | COI/TZIDC/TZIDC-200-EN 15... -
Page 16: Shut_Cls - Shut-Off Value 0
The setpoint ramp is deactivated in the case of any functions which involve approaching th e safe position. This even applies in the case of errors. The actuator will therefore move without delay. — Do not reach into the adjustment mechanism. 16 COI/TZIDC/TZIDC-200-EN | TZIDC, TZIDC-200... -
Page 17: Exit - Return To Operating Level
The display of the positioner in operating modes 1.0 through range. Use this parameter to specify the lower limit of the 1.2 always refers to the co nfigured working range and operating range. indicates the position in %. TZIDC, TZIDC-200 | COI/TZIDC/TZIDC-200-EN 17... -
Page 18: Zero_Pos - Zero Position
(see also parameter group DIG_OUT on page 29). NOTE Changing the operating range also changes the positions of the switching points with respect to the position of the valves and fittings. 18 COI/TZIDC/TZIDC-200-EN | TZIDC, TZIDC-200... -
Page 19: Pos_Sw2 - Switching Point Sw2
With this parameter you define whether a message is to be triggered for exceeding or fallin g below switching point SW2. EXCEED Message when exceeding switching point SW2. FALL_BEL Message when falling below switching point SW2. TZIDC, TZIDC-200 | COI/TZIDC/TZIDC-200-EN 19... -
Page 20: Parameter Group 5: Alarms
The limit value is edited remotely via PC. This may indicate improperly ad justed mounting or mechanical wear in a limit stop. ACTIVE Alarm for exceeding travel counter limit value INACTIVE No Alarm ACTIVE Alarm active. INACTIVE Alarm not active. 20 COI/TZIDC/TZIDC-200-EN | TZIDC, TZIDC-200... -
Page 21: Travel - Travel Counter
Press in order to travel to the desired position. ENTER Press and hold until the countdown has completed (MIN_SET). The position is saved as the minimum limit value. ENTER Press briefly. The set limit value is displayed for 2 seconds (MIN_SAVE). . TZIDC, TZIDC-200 | COI/TZIDC/TZIDC-200-EN 21... -
Page 22: Max_Vr - Operating Range Max
(actuator exhausts via OUT1 ). For double-acting actuators, the spri ng action has the same effect as ventilating the pneumatic output OUT2 . CLOCKW Stop reached turning clockwise CTCLOCKW Stop reached turning counterclockwise 22 COI/TZIDC/TZIDC-200-EN | TZIDC, TZIDC-200... -
Page 23: Dang_Dn - Dead Angle Close
The following options can be selected: — STEM (actuator bolt on the valve spindle) — LEVER (actuator bolt on the potentiometer lever) For detailed information about the position of the actuator bolt, see the operat ing instructions. TZIDC, TZIDC-200 | COI/TZIDC/TZIDC-200-EN 23... -
Page 24: Parameter Group 7: Control Parameters
NOTE In the case of most actuators, all control parameters can be optimized by using Auto Adjust. Changes should only be made when auto adjust cannot be executed or control stability cannot be achieved. 24 COI/TZIDC/TZIDC-200-EN | TZIDC, TZIDC-200... -
Page 25: Tv Dn - Tv Value (Down)
To compensate for existing as ymmetries in the controlled Use the parameter Y-OFS DN to adjust the Y offset for the system, the offset should be co nfigured separately for both downward positioning direction (towards 0 %). positioning directions (up / down). TZIDC, TZIDC-200 | COI/TZIDC/TZIDC-200-EN 25... -
Page 26: Tol_Band - Tolerance Band
The DB_APPR parameter specifies the speed at which the dead band is approached. In rare cases, overshooting can occur when the valve position is being compensated. This can be prevented by reducing the speed of the dead -band approach. 26 COI/TZIDC/TZIDC-200-EN | TZIDC, TZIDC-200... -
Page 27: Leak_Sen - Leakage Sensitivity
Use this parameter to specify th e characteristic curve for the analog feedback. Increasing Position 0 ... 100 % = Signal 4 ... 20 mA Decreasing Position 0 ... 100 % = Signal 20 ... 4 mA TZIDC, TZIDC-200 | COI/TZIDC/TZIDC-200-EN 27... -
Page 28: Alarm - Alarm
Simulation of an alarm curr ent < 3.8 mA or I > 20.5 mA CURRENT Output of the current setpoint as current value via analog output. All configurations and settings of the analog input and / or output must be taken into consideration. 28 COI/TZIDC/TZIDC-200-EN | TZIDC, TZIDC-200... -
Page 29: Parameter Group 9: Digital Output
Saves settings in the non-volatile memory. CANCEL Discards all changes made since the last Selection permanent save operation. ACTIV_HI active = output current I > 2 mA ACTIV_LO active = output current I < 1 mA TZIDC, TZIDC-200 | COI/TZIDC/TZIDC-200-EN 29... -
Page 30: Parameter Group 10: Digital Input
The operation lock CNF_LOCK , OP_LOCK or ALL_LOCK is Selection displayed only if the voltage is connected to the digital input. NV_SAVE Saves settings in the non-volatile memory. CANCEL Discards all changes made since the last permanent save operation. 30 COI/TZIDC/TZIDC-200-EN | TZIDC, TZIDC-200... -
Page 31: Parameter Group 11: Safe Position
Press and hold ENTER until the displayed countdown from 3 to 0 is finished. The positioner is reset to th e factory settings. The message COMPLETE is displayed. Press ENTER to acknowledge the message. Selection FS_LOAD Loads the factory settings TZIDC, TZIDC-200 | COI/TZIDC/TZIDC-200-EN 31... -
Page 32: Ip-Typ - Type Of The I/P Module
(see Chapter "Error codes" on page 33). Selection NV_SAVE Saves settings in the non-volatile memory. CANCEL Discards all changes made since the last permanent save operation. Change from two to one column 32 COI/TZIDC/TZIDC-200-EN | TZIDC, TZIDC-200... -
Page 33: Diagnosis / Error Messages
If the error still persists, Attempts are made to restore the data. the device must be returned for repair to This compensates for intermittent errors the manufacturer. in the communication environment with the EEPROM. TZIDC, TZIDC-200 | COI/TZIDC/TZIDC-200-EN 33... - Page 34 If the error can be reproduced and position. After approx. 5 seconds, the occurs in the same position after positioner is automatically reset. resetting, the device must be returned for repair to the manufacturer. 34 COI/TZIDC/TZIDC-200-EN | TZIDC, TZIDC-200...
-
Page 35: Alarm Codes
The defined limit value for the stroke counter has been exceeded. connected PC with suitable software). The specified limit value for the travel counter has been exceeded. connected PC with suitable software). TZIDC, TZIDC-200 | COI/TZIDC/TZIDC-200-EN 35... -
Page 36: Message Codes
Simulation has been started externally from a PC via HART‚ Protocol; switching outputs, alarm output and analog position feedback are no longer influenced by the process. Actual spring action is different from the adjusted one. Time-out; parameter could not be de termined within two minutes; Autoadjust was automatically stopped. 36 COI/TZIDC/TZIDC-200-EN | TZIDC, TZIDC-200... -
Page 37: Error Handling
Is the positioner function stable? Increase the dead band (DEADBAND) . Good job! The work activities are completed. Is the valve function stable? The friction of the valve is too grea t or Slipstic effect. Check the valve. TZIDC, TZIDC-200 | COI/TZIDC/TZIDC-200-EN 37... -
Page 38: Positioner Without Function
(FAIL_POS ) before the parameter activities are over can be changed. Save parameters. after starting Now is it working? Autoadjust! Return the defective positioner for Switch the function for the digital input ( FUNCTION ) to repair. none . 38 COI/TZIDC/TZIDC-200-EN | TZIDC, TZIDC-200... -
Page 39: Coi/Tzidc/Tzidc-200-En | Tzidc, Tzidc
Notes Notes TZIDC, TZIDC-200 | COI/TZIDC/TZIDC-200-EN 39... - Page 40 Contact us Note We reserve the right to make technical changes or modify the contents of this document without prior notice. With regard to purchase orders, the agreed particulars shall prevail. ABB does not accept any responsibility whatsoever for potential errors or possible lack of information in this document.
