  • Page 1 Owner's Manual Worldwide Patents Pending...

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Read ALL warning labels posted on the machine. Read and follow the use, care and maintenance instructions provided in this manual for safe use of your Ab WinnerTM. Prior to using this equipment and starting an exercise program, please consult your physician to ensure it is ok for you to exercise using this equipment.
  • Page 3 AB WINNER PARTS LIST Diagram# Part name Diagram# Part name Center bar Screws M8x40 Wheel set Screw M8x50 Right support bar Screw M6x45 Left support bar Screw M6x10 footrest Right arm Nuts M8 Left arm Nut M6 T bar Large pad...
  • Page 4 REMOVABLE PARTS LIST...
  • Page 5 ASSEMBLY INSTRUCTIONS STEP 1 Stickers indicate the direction, (A)matches(A),insert #2 into #1, and fasten with screws 14、15、18.
  • Page 6 ASSEMBLY INSTRUCTIONS STEP 2 Stickers indicate the direction, (B)matches(B), insert #3 and #4, and fasten with screws #12, #17 and #20.
  • Page 7 ASSEMBLY INSTRUCTIONS STEP 3 Stickers indicate the direction, (C)matches(C),pay attention to footrest direction and set the unit upright. Connect #5 footrest with supporting bars #3 and #4.
  • Page 8 ASSEMBLY INSTRUCTIONS STEP 4 Stickers indicate Left(L) and Right(R) directions. Connect #8 T bar and its extension link #1 with screws #13 and #17, and place the pin into the inside and outside hole.
  • Page 9 ASSEMBLY INSTRUCTIONS STEP 5 Stickers indicate Left(L) and Right(R) directions. Look at the stickers and connect bars #6 and #7, left and right arms.
  • Page 10 ASSEMBLY INSTRUCTIONS STEP 6 To adjust the arm angle by changing the pin location.
  • Page 11 ASSEMBLY INSTRUCTIONS STEP 7 Place the knob in one of those holes according to your needs. Make sure the knob is securely fastened before use.
  • Page 12 ASSEMBLY INSTRUCTIONS STEP 8 Folding method and pin location.
  • Page 13 AB Winner, LLC USA, UKing Global INC US and International Patents Pending © 2016 AB Winner, LLC & UKing Global. All rights reserved. Distributed by UKing Global INC.
