Troubleshooting

The most important principle in troubleshooting the SMART System
each component of the system separately and trace any malfunction to its source.
Verify each of these factors:
• Balance Calibration
• Microwave Power Measurement

• Standard Solution Test

• Analytical Method (verify analysis method) – If necessary, contact the CEM
Applications Department or the nearest subsidiary or distributor.
A qualified service technician, using standard troubleshooting techniques, should
be able to identify and resolve operational problems. If a problem persists, call the
CEM Service Department or the nearest subsidiary or distributor.
Troubleshooting Guide
Symptom
Instrument Inoperative
Balance Will Not Tare
Balance Not Operating
No Microwave Drying
Sample Burning
Results Not
Reproducible
Incorrect Results
"Data Results Invalid"
Displayed at End of Test
"Cover Open" Message
Low Power
Improper Heating
Discoloration or Oil
Buildup on Air Shield
Possible Cause/Remedy
Ensure that instrument is properly connected to
power outlet and that the power switch is in the
"on" position. Check fuses and replace if
necessary.
Balance overloaded. Use less sample.
Ensure that balance stem is installed and centered.
Instrument cover not closed and latched properly.
Check dual voltage supply and fuses (10A fuses
for 60 Hz and 5A for 50 Hz) and correct dual
voltage supply and/or replace fuses, if required.
Sample too large and/or unevenly applied to pad.
Sample not homogeneous. Sample not positioned
under temperature sensor. Power level too high.
Sample applied unevenly to pad. Sample not
homogeneous and absorbs microwaves unevenly.
Keep sample container closed when not extracting
sample. Work quickly when applying sample to
pads and placing pads on balance pan.
Verify proper sample handling, spread techniques
and method parameters.
Final weight greater than initial weight. Repeat
test. Check balance calibration.
Ensure that the instrument cover is properly
closed.
Check for faulty relay and replace if required.
Ensure that the air shield is installed and not
clogged.
Replace the air shield.
