Dimensions Of The Appliance - Faber Spectra Frameless Installation Manual

3.2

Dimensions of the appliance

Builders opening
(mm)
A Opening width
B Opening height
C Opening depth
D Min. Height shelf
from top opening
E Shelf depth
Dimensions of the
appliance
F Box width
G Box depth
H Box height
I Frame width
J Frame height
K Frame thickness
L Position flue collar
measured from frame
M Position flue collar
measured from the
back of the box
Wirdum surround
1070
1050
290
N.a.
N.a.
1024
276
990
1440
1100
370
143
147
Jellum surround
1070
1050
410
N.a.
N.a.
1024
396
990
1440
1090
370
263
147
UK IRL
No surround
1070
1050
465
350
150
1024
442
960
N.a.
N.a.
N.a.
313
147
> > > > 4
