- Page 1 Installation manual Skive 40011134-2010...
- Page 2 Installation manual Skive 1 < < < <...
- Page 3 Installation manual Skive 2 < < < <...
- Page 4 Installation manual Skive 1.3a 1.3b 3 < < < <...
- Page 5 Installation manual Skive 4 < < < <...
- Page 6 Installation manual Skive 5 < < < <...
- Page 7 Safety instructions Dear user Please note! Congratulations on your purchase of a Faber fire! A quality product from which you will experience It is advisable to always install a screen for the warmth and atmosphere for many years. We...
-
Page 8: Installation Requirements
A = Adapter (6 V) B = Gas valve C31, outlet via roof C = Receiver For a (flat) roof, use a Faber roof outlet with a D = Ignition pin diameter of 100/150mm. C91, existing chimney For an existing chimney, use a Faber chimney outlet with a diameter of 100/150mm. - Page 9 The controller can be connected to an external Removing glass source, such as a Domotica system, by using a Faber Interface Unit (article number A9323000). Front glass Remove the cast iron frame. To do this, Preparing the fireplace push the frame upwards and pull the ...
- Page 10 Installation manual Skive Checking the flame image Divide the ash material between the logs, don’t cover the air intake (perforated Let the fireplace burn for at least 20 minutes at parts) at the back. highest setting and check the flame for: ...
- Page 11 Remove the front glass (see chapter 5). fireplace and represents a certain value You can clean the glass with Faber glass polish. (fig. 12.1, 12.2 and 12.3 A, N and F). You This is a specially formulated cleaning agent that can find this value in the upper row of the can be ordered at authorized Faber dealers.
- Page 12 Installation manual Skive In case of an “X” or if the values are outside the restrictor table, the combination is not permitted. Pipes at an angle of inclination: Then adjust TVH or THL. These are pipes vertically ascending at an If a value is indicated, check that the calculated STL angle of 30°...
- Page 13 Installation manual Skive 11.1 Restrictor table (100/150) Start length (STL) Vertical (TVH) and Horizontal (THL) 30.00 0.00 0.00 30.00 30.00 0.00 0.00 0.00 30.00 30.00 30.00 0.00 0.00 0.00 0.00 40.00 30.00 30.00 30.00 0.00 0.00 0.00 40.00 40.00 30.00 30.00...
- Page 14 Installation manual Skive 12 Examples flue materials 13 < < < <...
- Page 15 Installation manual Skive 13 Calculation sheet Starter length (STL) First part on top of the appliance Value Flue length from 0,1m till 0,45m Flue length from 0,5m till 0,90m Flue length from 1m till 1,4m Flue length from 1,5m till 2m Flue length 2m or more Bend 90°...
- Page 16 Installation manual Skive found value Search in the table at TVH and THL and enter the value that is found. ……………………………… If the detected value is a number, check whether the completed STL is higher or equal to the value in the table.
-
Page 17: Technical Data
Installation manual Skive 14 Technical data Technical data Type indication(s) Skive Type appliance C11/C31/C91 Diameter outlet/inlet 100/150 Gas connection 3/8" Indirect heating functionality Category II2H3+ Symbol Unit Reference gas/inlet pressure G20-20 G30-30 G31-37 mbar Emissions in space heating mg/kWh (GVC) - Page 18 Installation manual Skive Outlet position Please note! These rules apply only for the proper functioning of the unit, for ventilation and environmental protection you need to comply with the applicable rules as defined in the building regulations. Short roof terminal.
-
Page 19: Troubleshooting Guide
Installation manual Skive 16 Troubleshooting guide 18 < < < <... - Page 20 Installation manual Skive 19 < < < <...
- Page 21 Installation manual Skive 20 < < < <...
- Page 22 Installation manual Skive 17 Dimensional drawings 17.1 Skive 21 < < < <...
- Page 23 Installation manual Skive 17.2 Position gas connection 22 < < < <...
- Page 24 Installation manual Skive 17.3 Wall bracket 23 < < < <...
- Page 25 Installation manual Skive 18 Decoration instruction card 24 < < < <...
- Page 28 www.faberfires.com contact@faberfires.com Saturnus 8 NL 8448 CC Heerenveen Postbus 219 NL 8440 AE Heerenveen...
