  • Page 1 Stanley Access Technologies Quick-Reference Guide MC521 Pro Controller Installation and Operation Manual 204066 Includes instructions for: DuraGlide™ 2000/3000, 5200/5300, DuraGuard™, and DuraStorm™ Automatic Slide Door Systems Rev. A, 11/23/10 Prohibition on Copying Any unauthorized reproduction, disclosure or distribution of copies by any person of any...

  • Page 2: Table Of Contents

    Connecting Main Power Wiring ........................3 Connecting Accessories (As Applicable) ....................3 TUNE-IN INSTRUCTIONS ......................... 4 Tuning In the MC521 Pro Controller Using the Palm Handheld ..............5 Tuning In the MC521 Pro Controller Using the Controller Pushbuttons ............ 8 Final Tune-In Adjustments ........................12 Spare Parts List ............................

  • Page 3: Purpose

    MC521 Pro Controller. It includes instructions for DuraGlide™ 2000/3000, 5200/5300, DuraGuard™, and DuraStorm™ Automatic Slide door systems. On Dura-Glide sliding doors, the MC521 Pro Controller replaces the MC521 or both the microprocessor control box and the interface board on older models. The door activation devices (SU-100 motion sensors, carpets, push plates, etc.), lock, function switch, doorway...

  • Page 4: Precautions

    Refer to Attachments 2 and 3, and CONNECT any of the following subsystems to the MC521 Pro Controller:  Function switch (rotary, rocker and “POWER” switch wiring)  Stanguard threshold sensor  Doorway holding beam  Cycle counter 204066 © 2010, THE STANLEY WORKS. ALL RIGHTS RESERVED. Rev. A, 11/23/10 3 of 27...

  • Page 5: Tune-In Instructions

    NOTE 1. The MC521 Pro Controller can be tuned-in using a PDA or using the pushbutton switches located on the controller. Tune-in using the PDA is the preferred method. 2. During normal operation, the digital display indicates status codes. The “UP” and “DOWN”...

  • Page 6: Tuning In The Mc521 Pro Controller Using The Palm Handheld

    Tuning In the MC521 Pro Controller Using the Palm Handheld NOTE The following steps provide instructions for tuning the MC521 Pro Controller using the Palm handheld. MC521 application software is required. Connect Palm to MC521 Pro Controller, turn on header POWER switch, and perform the following steps.
  • Page 7 Open fully at check speed.  Close fully at check speed. Step 12: If the door is not operating correctly select Trouble Shoot to enter the Trouble Shooting menu. 204066 © 2010, THE STANLEY WORKS. ALL RIGHTS RESERVED. Rev. A, 11/23/10 6 of 27...
  • Page 8 Light indicates input/output contact is open. Gray never changes. Step 16: Review the information on the Step 15: Press Summary Listing to view all summary listing. current settings. 204066 © 2010, THE STANLEY WORKS. ALL RIGHTS RESERVED. Rev. A, 11/23/10 7 of 27...

  • Page 9: Tuning In The Mc521 Pro Controller Using The Controller Pushbuttons

    Tuning In the MC521 Pro Controller Using the Controller Pushbuttons NOTE 1. To change the INDEX: Hold ENTER switch while pressing UP or DOWN to get to desired INDEX 2. To change a VALUE: Unlock the keypad by setting index 99 to value 00.
  • Page 10 Command – Lock. Entering “01” will lock all value inputs except this index. This prevents inadvertent changes to input values. Values may be unlocked by entering “00” in this index. 204066 © 2010, THE STANLEY WORKS. ALL RIGHTS RESERVED. Rev. A, 11/23/10 9 of 27...
  • Page 11 02 = 30 sec delay 00 = Standard Monitor 01 = StanVision Monitor 02 = Wizard Monitor 03 = Active Eight Monitor 04 = Standard No Monitor 204066 © 2010, THE STANLEY WORKS. ALL RIGHTS RESERVED. Rev. A, 11/23/10 10 of 27...
  • Page 12 Inside presence sensor error Outside presence sensor error Inside Active8 sensor failure Outside Active8 sensor failure Upper Telco hold beam sensor failure Lower Telco hold beam sensor failure 204066 © 2010, THE STANLEY WORKS. ALL RIGHTS RESERVED. Rev. A, 11/23/10 11 of 27...

  • Page 13: Final Tune-In Adjustments

    Door State is in Close Press NOTE: If the current status code is “Normal operation—All OK”, the MC521 Pro will show the current door state. Otherwise, the MC521 Pro alternates between showing the current status code and the door state.

  • Page 14: Spare Parts List

    Spare Parts List Description Part Number MC521 Pro Controller, includes 4 terminal blocks 314117 MC521 Pro Controller Manual 204066 Harness, Rocker Switch to Control Box, 98 inches 414098 Harness, Rocker Switch to Control Box, 180 inches 414099 Harness, Holding Beam to Control Box, 24 inches...

  • Page 15: Attachment 1, Mc521 Pro Controls And Indicators

    Attachment 1 MC521 Pro Controls and Indicators (Sheet 1 of 2) SEE DETAIL A 204066 DETAIL A Rev. A, 11/23/10 UC 001D Page 14 of 27 © 2010, THE STANLEY WORKS. ALL RIGHTS RESERVED.
  • Page 16 Connection point for Stanguard, doorway holding beam, and breakout switch. Using jumper wires across TB3 terminals 1 to 5 and 2 to 6, internal transformer supplies power to multiple external sensors. 204066 Rev. A, 11/23/10 Page 15 of 27 © 2010, THE STANLEY WORKS. ALL RIGHTS RESERVED.

  • Page 17: Attachment 2, Mc521 Pro System Wiring Diagram

    Attachment 2 MC521 Pro System Wiring Diagram (Sheet 1 of 6) TO SHEET 3 12 VDC 0 VDC 12 VDC 0 VDC UC007_1G 204066 Rev. A, 11/23/10 Page 16 of 27 © 2010, THE STANLEY WORKS. ALL RIGHTS RESERVED.
  • Page 18 MC521 Pro System Wiring Diagram (Sheet 2 of 6) STANGUARD HARNESS 414106 OR 414111 DOORWAY HOLDING BEAM JUMPER 413363-1 JUMPER 413363-2 BREAKOUT SWITCHES BREAKOUT BEAM UC007_2D 204066 Rev. A, 11/23/10 Page 17 of 27 © 2010, THE STANLEY WORKS. ALL RIGHTS RESERVED.
  • Page 19 Attachment 2 MC521 Pro System Wiring Diagram (Sheet 3 of 6) 516922-1 OR 516922-2 516921 TO SHEET 1 204066 UC007_3E Rev. A, 11/23/10 Page 18 of 27 © 2010, THE STANLEY WORKS. ALL RIGHTS RESERVED.
  • Page 20 MC521 Pro System Wiring Diagram (Sheet 4 of 6) 516922-1 OR 516922-2 516921 JUMPER 413363-2 JUMPER 413363-1 12 VDC 0 VDC 12 VDC UC007_4E 0 VDC 204066 Rev. A, 11/23/10 Page 19 of 27 © 2010, THE STANLEY WORKS. ALL RIGHTS RESERVED.
  • Page 21 TERMINAL BLOCK LAYOUT FOR ACTIVE 8 WITH SELF-MONITORING CUT JUMPER 516861 516861 JUMPERS INSIDE SENSOR OUTSIDE SENSOR NOTE: PRESENSE AND ACTIVATION SENSORS SET TO ACTIVE MODE WITH REMOTE. 204066 UC007_6A Rev. A, 11/23/10 Page 20 of 27 © 2010, THE STANLEY WORKS. ALL RIGHTS RESERVED.
  • Page 22 MC521 Pro System Wiring Diagram (Sheet 6 of 6) MC521 PRO MONITORING HOLDING BEAM SELF-CONTAINED TRANSMITTER RECEIVER UPPER BEAM CTRL CTRL JUMPER RECEIVER TRANSMITTER UC007_6B LOWER BEAM 204066 Rev. A, 11/23/10 Page 21 of 27 © 2010, THE STANLEY WORKS. ALL RIGHTS RESERVED.

  • Page 23: Attachment 3, Mc521 Pro Terminal Block Connections -Tb1 Through Tb7

    Attachment 3 MC521 Pro Terminal Block Connections —TB1 through TB7 (Sheet 1 of 1) (ROCKER SWITCH WIRING) (ROTARY SWITCH WIRING) HOLD OPEN POSITION (YL) HOLD OPEN POSITION (BK) EXT + EXT- COMMON (OR) COMMON (YL) EXT - AUTOMATIC POSITION (BN)

  • Page 24: Attachment 4, Ansi/Bhma And Ul Compliance Requirements For Sliding Doors

    Doors activated by a manual switch (Knowing Act switch in ANSI/BHMA terms) must have the switch installed in a location from which operation of the door can be observed by the person operating the switch. 204066 Rev. A, 11/23/10 Page 23 of 27 © 2010, THE STANLEY WORKS. ALL RIGHTS RESERVED.
  • Page 25 160 or less 161 to 180 181 to 200 201 to 220 221 to 240 241 to 260 261 to 280 281 to 300 204066 Rev. A, 11/23/10 Page 24 of 27 © 2010, THE STANLEY WORKS. ALL RIGHTS RESERVED.

  • Page 26: Attachment 5, Palm Troubleshooting Aid

    Rocker Function Switch States for TB2 Hold Closed/ Reduced/ Automatic Oneway Reduced Open Locked Oneway TB2-1 TB2-3 Don’t Don’t TB2-5 care care Don’t Don’t TB2-7 care care 204066 Rev. A, 11/23/10 Page 25 of 27 © 2010, THE STANLEY WORKS. ALL RIGHTS RESERVED.
  • Page 27 Closed-Door Position Switch Input Dark = closed TB5-10 Spare TB6-1 Input Spare 1 TB6-3 Input Spare 2 TB6-5 Output Spare 1 TB6-7 Output Spare 2 204066 Rev. A, 11/23/10 Page 26 of 27 © 2010, THE STANLEY WORKS. ALL RIGHTS RESERVED.

  • Page 28: Attachment 6, Palm Troubleshooting Screen Descriptions

    TB5-3 Swing = Sentrex Operate Sensor Input (Internal, From MicroBoard) Slide = Side Screen Sensor Input TB5-7 Swing = Holding Beam Input Slide = Closed-Door Position Switch Input TB5-10 Spare Output 204066 Rev. A, 11/23/10 Page 27 of 27 © 2010, THE STANLEY WORKS. ALL RIGHTS RESERVED.
