Summary of Contents for Advantech MIC-3666
- Page 1 User Manual MIC-3666 Dual 10 Gigabit Ethernet XMC...
- Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
-
Page 3: Declaration Of Conformity
This product has passed the CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This kind of cable is available from Advantech. Please contact your local supplier for ordering information. -
Page 4: Document Feedback
Discard used batteries according to the manufacturer's instructions. Note! Notes provide optional additional information. Document Feedback To assist us in making improvements to this manual, we would welcome comments and constructive criticism. Please send all such - in writing to: support@advan- tech.com. MIC-3666 User Manual... -
Page 5: Safety Instructions
The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein. - Page 6 We Appreciate Your Input Please let us know of any aspect of this product, including the manual, which could use improvement or correction. We appreciate your valuable input in helping make our products better. MIC-3666 User Manual...
-
Page 7: Table Of Contents
Card Installation ..................7 Front Panel LED Indicators ............... 7 Figure 2.1 MIC-3666 front panel LEDs ........7 Driver/Utility Installation................7 Appendix A Pin Assignments .........9 P15 Connector ..................10 Table A.1: MIC-3666 XMC Connector P15 Pin Assignments ..10 MIC-3666 User Manual... - Page 8 MIC-3666 User Manual viii...
-
Page 9: Chapter 1 General Information
Chapter General Information... -
Page 10: Introduction
Introduction The MIC-3666 is a low power, dual-port 10 GbE XMC, with SFP+ pluggable modules for multi-mode and single-mode fiber media and is based on the Intel® 82599ES 10 Gigabit Ethernet controller. The XMC provides a high performance PCIe x8 interface at 5 Gb/s per lane at an outstanding low power dissipation of less than 10 W. -
Page 11: Specifications
Board size: 74 x 149 mm (2.9” x 5.78”) Weight: 0.104 kg (0.23 lb) 1.2.5 Software Support ® ® Drivers from Intel for Windows and Linux 1.2.6 Compliance IEEE Std 1386.1-2001 PMC specification VITA 42.0-2005, 42.3-2006 XMC specifications MIC-3666 User Manual... -
Page 12: Safety Precautions
Keep the board in its antistatic packaging when it is not installed in the chassis, and place it on a static dissipative mat when you are working with it. Wear a grounding wrist strap for continuous protection. MIC-3666 User Manual... -
Page 13: Chapter 2 Hardware And Driver Installation
Chapter Hardware and Driver Installation... -
Page 14: Initial Inspection
It should be free of marks and scratches and in perfect working order on receipt. As you unpack the MIC-3666, check it for signs of shipping damage (dam- aged box, scratches, dents, etc.). If it is damaged or fails to meet specifications, notify our service department or your local sales representative immediately. -
Page 15: Card Installation
Card Installation The MIC-3666 is a PCI Express bus master XMC module. It can be installed only in a CompactPCI board which supports XMC interface. Improper installation of a card can easily damage the backplane of the chassis. The MIC-3666 install guide helps... - Page 16 MIC-3666 User Manual...
-
Page 17: Appendix A Pin Assignments
Appendix Pin Assignments... -
Page 18: P15 Connector
P15 Connector Table A.1: MIC-3666 XMC Connector P15 Pin Assignments VPWR PCIE_TXN1 PCIE_TXP1 VCC3 PCIE_TXN0 PCIE_TXP0 PCIE_RST# VPWR PCIE_TXN3 PCIE_TXNP3 VCC3 PCIE_TXN2 PCIE_TXNP2 VPWR PCIE_TXN5 PCIE_TXP5 VCC3 PCIE_TXN4 PCIE_TXP4 VPWR PCIE_TXN7 PCIE_TXP7 VCC3 PCIE_TXN6 PCIE_TXP6 VPWR VPWR PCIE_RXN1 PCIE_RXP1 PCIE_RXN0... - Page 19 MIC-3666 User Manual...
- Page 20 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2010...
