AXIS T90D Illuminator Series

Setup

Setup

About the factory default settings

When you buy the product, the telemetry wires (see Product overview on page 5 ) are soldered together. This makes the illuminator
turn on automatically when the photocell detects low-light conditions.
When you connect the product for the first time, it has the following settings:
• Light intensity: 100%
• Photocell sensitivity: 10 Lux on, 30 Lux off
• LED indicators: on
• PIN set: no
• Control buttons: enabled
• Mode: programming mode (changes to operating mode seven days after start-up if you don't press any control buttons)

About operating and programming mode

The product has two different modes, operating and programming. You can access different settings depending on which mode the
product is in.
Setting
Adjust light
intensity
Adjust photocell
sensitivity
Enable or disable
LED indicators
Disable control
buttons
To minimize the risk of tampering, we recommend you to set the product to operating mode when the illuminator has been set up
and is delivering the required operating performance.
How to change from operating to programming mode
With a preset PIN
• Enter the PIN. See How to enter a PIN on page 9 .
• Do a full reset. See How to reset to factory default settings on page 14.
Without a preset PIN
• Disconnect and reconnect the product to power.
• With the control buttons:
1. Press and hold the left control button for 4 seconds until the left hand side LED flashes red.
2. Press the left control button once more so that the left hand side LED flashes green.
Remote control
Operating mode Programming mode
x
x
x x
x
Control buttons
Operating mode Programming mode
x x
x x
x x
x x
8
More information
See page 11 .
See page 12.
See page 13.
See page 10.
