AXIS T90D Illuminator Series
Setup
How to delete a PIN
1. When the product is in programming mode, press and hold the Status button for 4 seconds.
2. Press the Reset button four times.

How to disable the control buttons

With the remote control
1. Within 5 minutes after you enter operating mode, press and hold the Disable remote control setup button for 4 seconds.
With the control buttons
1. Press and hold the left control button for 4 seconds until the left hand side LED flashes red.
2. Press the left control button twice so that the left hand side LED flashes amber.
3. Press the right control button repeatedly until the right hand side LED turns solid red.
Note
You can reverse this setting with the control buttons within 30 minutes:
1. Press and hold the left control button for 4 seconds until the left hand side LED flashes red.
2. Press the left control button twice so that the left hand side LED flashes amber.
3. Press the right control button repeatedly until the right hand side LED turns solid green.

How to re-enable the control buttons

If the control buttons are disabled, you can re-enable the them temporarily (for 30 minutes) or permanently.
Temporarily with a preset PIN
• Enter the PIN. See How to enter a PIN on page 9 .
Temporarily without a preset PIN
• Disconnect and reconnect the product to power.
Permanently with or without a preset PIN
• Do a full reset. See How to reset to factory default settings on page 14.

How to control the illuminator with an Axis network camera

This use case explains how to:
• connect the illuminator to the I/O connector of an Axis network camera
• set up the camera to make the illuminator turn on when the camera detects motion
Connect the illuminator to an Axis network camera:
1. Snip the end of the telemetry wires (purple and orange) to separate them.
2. Connect the purple wire to pin 1 (DC ground) of the camera's I/O connector. If you need more information about the
camera's I/O connector, see the camera's User Manual.
3. Connect the orange wire to pin 4 (digital output) of the camera's I/O connector.
Configure the I/O port in the camera's webpage:
