3.Setting of Wireless System
1) Put the relevant batteries inside the handset & door station
2) Battery pack for handset is provided. Simply plug the battery pack inside the socket near the battery
door. ( See fig.7-2 )
You could select one out of 3 available channels to use.
Make sure the channel between door station and handset is the same.
Handset
Dip switch
1. 2-ON 3-ON
2. 2-ON 3-OFF
3. 2-OFF 3-ON
Door station
Dip Switch
1. 2-ON 3-ON
2. 2-ON 3-OFF
3. 2-OFF 3-ON
4. should be in " Off " position in normal condition
5. should be in " Off " position in normal condition
For example, the user choose channel 1 for setting:
The setting procedure is as below:
3) Put the DIP switch 1 to " ON " position from the handset.
4) Put the DIP switch 4 to " ON " position from the door station. ( For program setting
purpose )
5) Press the call button from the door station.
6) If the identification is done, the LED on the door station would be red & green blinking.
7) Put the DIP switch 4 to " OFF " position from the door station
8) Put the DIP switch 1 to " OFF " position from the handset
9) Press the call button from the door station to ensure the product is in function.
For setting wireless audio door phone for family two, the procedure is same as
above except the user needs to press the appropriate call button from the door
station during identification.
Channel selection
Channel 1
Channel 2
Channel 3
Channel selection
Channel 1
Channel 2
Channel 3
