Wireless Audio Doorphone
1.Introduction
Thank you for purchasing this SynerTech product.
Wireless ADP is ideal for your home. Features included: communication, 1 or 2 household call buttons,
and Single door/Garage door release. The operating frequency is at 2.4G Hz.
Full set of wireless audio door phone system includes 1 door station and 1 indoor unit with charger.
Accessories include one wall mounting bracket and screws.
The door station has 1 or 2 household call buttons. When pressed, it allows 2 way speech
communications and will ring only one indoor wireless handset corresponding to that call button. The
wireless handset can be carried from floor to floor.
To obtain the best performance from this product, please read through this manual carefully.
Installation and operation manual
(Model: For 1 family & 2 family)
P. 1 of 14

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1 family and is the answer not in the manual?

Questions and answers

Related Manuals for SynerTech 1 family

Summary of Contents for SynerTech 1 family

  • Page 1 Wireless Audio Doorphone Installation and operation manual (Model: For 1 family & 2 family) 1.Introduction Thank you for purchasing this SynerTech product. Wireless ADP is ideal for your home. Features included: communication, 1 or 2 household call buttons, and Single door/Garage door release. The operating frequency is at 2.4G Hz.
  • Page 2 2.Components A. Name of parts, accessories and indicators for full set of wireless ADP Handset (Fig.1) Indoor unit Accessories (Included) 1. DC jack 15. Metal wall mounting Screws 2. Antenna bracket 3. Built-in speaker 4. LED light 17. Charging contact 5.
  • Page 3 Fig. 2 Door station(Fig.2) 1. Antenna 2. Built-in speaker 3. Door Button 4. LED 1: low battery indicator / coding setting indicator 5. Microphone 6. Name plate (two LEDs ( LED 2 & 3 ) under name plate ) 7. DIP switches 8.
  • Page 4 3.Setting of Wireless System 1) Put the relevant batteries inside the handset & door station 2) Battery pack for handset is provided. Simply plug the battery pack inside the socket near the battery door. ( See fig.7-2 ) You could select one out of 3 available channels to use. Make sure the channel between door station and handset is the same.
  • Page 5 Select the other channel if any disturbance occurred. LED indicator from handset: (see fig. 1) a) When the low battery status from door station, the LED would blink in red & green. b) When the low battery status from handset, the LED would be on in red. c) The LED would be in green when battery is charged up.

  • Page 6: System Connection

    4.System Connection Cable connection (Fig.3) See Fig. 4 There are three power sources for this wireless system. Basic mode: (Batteries inside door station only) Function: * “Talk”: full duplex communication * Door open triggering ( Release signal only. If door lock has to be opened, pls connect with access glass ) * Garage open triggering ( Release signal only not opening garage ) 2.
  • Page 7 * 6V power provide to the door station * Garage open triggering Caution: Remove batteries from the door station when using 6V access glass. 3. Basic mode with 12V/24V (through 6V access glass ) (6V access glass not included in the set) See fig.3 Following the wiring diagram (see fig.3), if 12/24V, door opening &...
  • Page 8 Screw the back case on the wall ( see arrows ) Access For connecting garage glass opener & 12V/24V 3 meter cable provided Structure of access glass ( not included in the set ) Fig 5-1 Fig.5-2 Connection of terminal block inside the access glass ( See Fig 5-2 ) 1) Open the battery cover 2) Install external wires into the terminal block inside the access glass 3) “G-”...

  • Page 9: Preparation For Installation

    5. Preparation for Installation Recommended installation height (Fig.6) The above diagram shows the position of the door station and indoor phone unit. Recommended installation height is approximately 165cm from the ground level for both units. It is usually installed near the door.
  • Page 10 Fig. 7-1 Installation of battery pack inside handset After installation, put the battery Insert the plug from battery socket back to the handset pack to battery socket inside the handset Fig.7-2 P. 10 of 14...

  • Page 11: Operating Instructions

    For door station Step 1: Locate and mark screwing positions on the wall. Step 2: Fix the flush in bracket securely onto the wall. Ensure it is leveled against the wall. Step 3: Separate the audio box from the aluminum panel. Step 4: Screwing out the screws between the audio box and flush-in bracket.

  • Page 12: Operation Precautions

    on during the conversation. During the conversation, you can press and hold the “Door open” button OR “Garage open“ button for 5 seconds; the door will then remain open for 1 second. The handset and door station will be activated for 30 seconds. Then the door station will be switched off automatically.

  • Page 13: Specifications

    can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
  • Page 14 a) Handset not on the charge but in stand-by 10hours mode ( after fully charged ) b) Keep “ Talk “ all the time 2hours For door station Standby mode Current : less than 30µA Talk mode Current :170mA Batteries used 4pcs x AA ( Not included in the set ) Batteries life : ( based on Durcell batteries )
