Using Navios Software
Cytometer Menu
the Dots field to the number of Dots required. If a zero is entered, an error message displays showing
range of 10 - 9999. The Dots value is stored in the Protocol

QuickCOMP Mode

E QuickCOMP
nabling
Acquisition Setup Tab
slider bars on all dual fluorescence plots.
These sliders are used to intuitively adjust the
compensation coefficients and update the
compensation values in the
Compensation
Clicking the arrows adjusts the settings by
±0.1%, clicking either side of the slider adjusts by
±1.0% or drag the slider to place the cells in the
required position.
When QuickCOMP
not available.
NOTE
Listmode Compensation must be performed
using the runtime protocol or a protocol with
equivalent parameters as the runtime protocol.

QuickSET Mode

QuickSET
Enabling
Acquisition Setup Tab
slider bars on all plots.
These sliders are used to adjust voltages at
the data plots and update the high voltages
in the Cytometer Control Acquisition Setup
Tab.
Clicking the arrows adjusts the voltage by
±0.1 volt, clicking either side of the slider
adjusts by ±1.0 volts or drag the slider to
place the cells in the required position.
When QuickSET
is not available.

Baseline Offset

Enable this checkbox to switch on Baseline Offset. Enabling this checkbox will override the Baseline
Offset selections on the Workspace Preferences - Plot Display tab. Further information concerning
the setting of this option can be found under
10-160
on the Cytometer Control
dialog box displays red
Cytometer Control
Tab.
is enabled QuickSET mode is
on the Cytometer Control
dialog box displays
is enabled QuickCOMP mode
Workspace Preferences - Plot Display.
