Using Navios Software
Plots Menu
Navios software cannot display Prism using listmode files saved from COULTER XL SYSTEM II
software however, Navios software can generate Prism plots from XL SYSTEM II files.
NOTE
Reanalysis of listmode files overrides the analysis protocol's Prism dividers. You have to adjust the
dividers when this occurs.
Third party software may not display Prism data correctly since a special Prism data display
algorithm is involved to display Prism in Navios software.

Legend

Use this option to view the population colors and population names,
1
Plots > Legend Plot
When a Plot is displayed, click the right mouse button within the plot to display further menu
options.
2
Every time the population names or colors are edited Navios software updates the Legend
Window.
If Navios software is in Dot Plot Mode-Color Blend mode, Legend displays the names, colors and
associated statistics of the color Gate combinations.
3
If Navios software is in Dot Plot Mode-Color Precedence mode, Legend displays the names,
colors and associated statistics of the Gates with the highest precedence at the top.
See also:
Data Source (Legend)
Legend - Options Tab
Color Blend Mode - Introduction
Modify Color Precedence
Advanced Precedence
10-108
to create a legend plot.
773232AH
