Automatic Maximum Threshold
This option allows automatic configuration of the maximum value that is used to calculate the
Density Color Levels. If this option is not selected you may manually enter the value which is used
to calculate the Density Color Levels.

Maximum Density Level

Configure the Density Plot to manually enter the value that is used to calculate the Density Color
Levels. This option is only active when the

Logarithmic Threshold Calculation

Density color thresholds may be calculated in one of two ways:
• Linear threshold calculation - option toggled off
The maximum value is used to determine the threshold value for each color. The actual
threshold value is calculated as follows: -
Value = (Level No) x (Maximum In Plot /5) - 1
• Logarithmic threshold calculation - option toggled on
The maximum value is used to determine the threshold value for each color. The actual
threshold value is calculated as follows: -
Value = 10(Level No) x (log10 (Maximum In Plot /5)) - 1

Smooth Density Plot

Choose this option to smooth the Density plot. Clear it to display raw unsmoothed data.

Use Gate Color

Creates a single color density range based on the currently assigned gate color.

Use Single Color Range

Creates a range of density level colors based on the selected Level 1 and Level 5 colors.
10-102
( )
or press to exit the dialog box without saving the changes.
Esc
Automatic Maximum Threshold
to accept all
button is cleared.
