Command #165: Get Set Up Information

Request Data Bytes
Byte Format
None N/A
Response Data Bytes
Byte Format
0 Unsigned-8
1 Enumerated
2- 5 Unsigned-32
6 Unsigned-8
7 Unsigned-8
8 Unsigned-8
9 Unsigned-8
10 Unsigned-8
11 Unsigned-8
12 Unsigned-8
13 Unsigned-8
14 Unsigned-8
15 Unsigned-8
16 Unsigned-8
17 Unsigned-8
18-19 Unsigned-8
20 Unsigned-16
21 Unsigned-8
22 Unsigned-8
23 Unsigned-8
24 Unsigned-8
Command-Specific Response Codes
Code Class
0 Success
1-127
Description
N/A
Description
Gas ID
Measured Units
Full Scale
Alarm level, % of FS
Reserved = 0
Reserved = 0
Warn level, % of FS
Reserved = 0
Reserved = 0
Reserved = 0
Reserved = 0
Reserved = 0
Reserved = 0
Reserved = 0
Cal IO type: 0 – zero switch, 1 – manual solenoid, 2 – automatic
solenoid
Reserved = 0
Reserved = 0
Reserved = 0
Cal level, % of FS.
Reserved = 0
Current Range: 0 = 3.5 – 20mA, 1 = 1.25 – 20mA
Description
No Command-Specific Errors
Undefined
18
