General Monitors TL104 Instruction Manual

Test lamp for flame detection
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Model TL104
Test Lamp for Flame Detection
The information and technical data disclosed in
this document may be used and disseminated
only for the purposes and to the extent
specifically authorized in writing by General
Monitors.
Instruction Manual
General Monitors reserves the right to change
published specifications and designs without
prior notice.
Part No.
Revision
10-05
MANTL104
MANTL104
B/10-05

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TL104 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for General Monitors TL104

Summary of Contents for General Monitors TL104

  • Page 1 General Monitors. Instruction Manual 10-05 General Monitors reserves the right to change published specifications and designs without prior notice. MANTL104 Part No. MANTL104...
  • Page 2 TL104 This page is intentionally left blank.

  • Page 3: Table Of Contents

    Red Aluminum Case and Gray Cap...................3 3.0 USE AND OPERATION ......................4 4.0 TEST LAMP MAINTENANCE AND WARRANTY ..............6 Maintenance..........................6 Warranty.............................6 5.0 TROUBLESHOOTING GUIDE ....................7 6.0 CUSTOMER SUPPORT ......................8 General Monitors’ Offices......................8 Other Sources of Help........................8 7.0 APPENDIX..........................9 Specifications ..........................9...

  • Page 4: About This Manual

    TL104 About This Manual This manual provides instructions for operating, and maintaining the General Monitors (GM) TL104 Test Lamp. The intended audience includes installation personnel, field service technicians, and other technical staff involved in using a TL104. Format Conventions Several format conventions are used throughout this manual for Notes, Cautions, and Warnings.

  • Page 5: Introduction

    The TL104 is designed for use in Class I, Division 1, 2, Groups C and D areas. The test lamp functions on internal lead-acid batteries which, when fully charged, allows continuous operation for 20 to 30 minutes.

  • Page 6: Test Lamp Components

    The mode jumper has two positions, one for TL104 mode and another for the TL103 mode. TL104 mode features a higher flash rate and is the mode required for new flame detectors such as the FL4000. Detectors FL3XXX and UV/IR Type VI detectors require the TL103 mode.

  • Page 7: Lead Acid Rechargeable Battery

    TL104 2.6 Lead Acid Rechargeable Battery The TL104 Test Lamp is powered by a 120V, 2.5Ah lead acid rechargeable battery. It is important to keep the test lamp docked with its battery charger when the test lamp is not being used.

  • Page 8: Use And Operation

    GM flame detector used. Table 1 shows the dipswitch configurations for GM flame detectors FL3XXX and UV/IR Type VI. Using a fully charged TL104, stand up to the distance specified in Table 1 from the flame detector to be tested and aim the TL104 directly into the detector window.
  • Page 9 FL3111 triggers into FL3111 TL103 alarm mode FL3112 triggers into FL3112 TL103 alarm mode FL4000 enters test FL4000 TL104 Any dipswitch setting mode FL4000 ignores FL4000 TL103 TL103 mode Table 1: Detector Test Mode Initiation or/Detector Alarm Trigger with TL104...

  • Page 10: Test Lamp Maintenance And Warranty

    4.2 Warranty General Monitors warrants the TL104 Test Lamp and the accessory battery charger to be free from defects in workmanship or material under normal use and service within two (2) years from the date of shipment.

  • Page 11: Troubleshooting Guide

    This section is intended to be a guide in correcting problems, which may arise in the field. General Monitors should be contacted for assistance if the corrective action listed does not eliminate the problem.

  • Page 12: Customer Support

    General Monitors provides extensive documentation, white papers, and product literature for the company’s complete line of safety products, many of which can be used in combination with the TL104. Many of these documents are available online at the General Monitors website at http://www.generalmonitors.com.

  • Page 13: Appendix

    TL104 7.0 Appendix 7.1 Specifications Operating temperature: 5°F to 122°F (-15°C to +50°C) Storage temperature: 5°F to 122°F (-15°C to +50°C) 0 to 90 ± 3% RH, non-condensing Humidity range: Weight: 7.9 lb (about 3.5 kg) Dimensions: 13” L x 5” D (330 mm L x 127 mm D)
